INSTRUMENT PANEL
A
One Piece The following items are located on the one piece instrument panel [A]:
741,742,743, 743DS 1
6
4
10
8
1. HOURMETER – Records the total operating hours of the loader. 2. KEY SWITCH (741,743DS Only) – Controls preheat operation and starting the engine. 742 Only – Controls starting and stopping the engine.
5
3. VOLTMETER – Shows the condition of the battery and the rate of charge.
2
3
7
9
4. FUSE (ACCESSORIES) – To protect the electrical system from overload. 5. FUSE (IGNITION) – To protect the electrical system from overload.
B–07524
6. ENGINE WARNING LIGHT – Engine oil pressure is low. Stop the engine if this light comes ON.
Dealer Copy -- Not for Resale
7. TRANSMISSION WARNING LIGHT – Low transmission charge pressure, hydraulic filter needs replacement or high fluid temperature. Stop the engine if this light comes ON. 8. LIGHT SWITCH – Controls the work and travel lights. 9. FUEL GAUGE – Shows the amount of fuel in the fuel tank. 10. ENGINE TEMPERATURE GAUGE – Shows the engine coolant temperature.
21 of 102
–3–
741, 742, 743 & 743DS Bobcat Loader Operation & Maintenance Manual
