AIR CLEANER SERVICE
A
Condition Indicator
2 1
Replace the large (outer) filter element only when the red ring shows in the window of the condition indicator (Item 1) [A]. NOTE: Before replacing the filter element, push the button on the condition indicator (Item 2) [A]. Start the engine. If the red ring does not show, do not replace the filter element.
P–05791
Replacing Filter Element
B
Outer Element:
1
Release the two dust cover fasteners (Item 1) [B].
1
P–05795
Remove the large filter element (Item 1) [C].
C
NOTE: Make sure all sealing surfaces are free of dirt and debris. Install the new filter element. Install dust cover. Check the air intake hose for damage. Check the air cleaner housing for damage. Check to make sure all connections are tight.
1
Inner Element: P–05794
Only replace the inner filter element under the following conditions: • Replace the inner filter element every third time the outer filter is replaced. • Press the button to remove the red ring in the condition indicator after the outer element has been replaced. Start the engine and run at full RPM. If the red ring shows again, replace the inner filter element. Remove the inner filter wing nut. Remove the inner filter. Install a new filter and tighten the wing nut.
70 of 114
–50–
653 Bobcat Loader Operation & Maintenance Manual
Dealer Copy -- Not for Resale
Remove the dust cover and latch the fasteners.
