BOBCAT INTERLOCK CONTROL SYSTEM (BICS™) (Cont’d)
A
Lift Arm By–Pass Control Use the lift arm by–pass control knob (Item 1)[A] to lower the lift arms if the lift arms can not be lowered during normal operation. Later Model Loaders (See Page v.): With the operator in the seat, seat belt fastened and the seat bar fully lowered, turn the lift arm by–pass control knob (Item 1) [A] clockwise 1/4 turn. Then, pull up and hold the lift arm by–pass control until the lift arms slowly lower.
1
Early Model Loaders (See Page v.): With the operator in the seat, seat belt fastened and the seat bar fully lowered, pull and hold the by–pass control knob (Item 1) [A] up. Push the top (toe) of the left (lift) pedal (or move the left hand control toward the operator). The liftarms will slowly lower.
P–09707
B
There is a traction lock override button (Item 1)[B] on the left hand instrument panel which will allow you to use the steering levers to move the loader forward & backward when using the backhoe attachment or for loaderservice. Press the button once to unlock traction drive (green traction light on BICS controller will be ON). Press the button a second time to lock the traction drive (green traction light on BICS controller will be OFF).
1 P–07674
NOTE: The traction lock override button will unlock the traction drive when the operator is NOT in the seat and the seat bar is raised.
C
The traction lock override button will function if brake pedal is in the engaged or disengaged position.
Dealer Copy -- Not for Resale
Traction Lock Override
1
Auxiliary Hydraulic System Later Model Loaders Only (See Page v.) When the operator is seated and raises the seat bar, the auxiliary hydraulic system will deactivate. Press the auxiliary hydraulics switch (Item 1) [C] to reselect operating mode.(See Auxiliary Hydraulics Page 13.)
P–03272
AVOID INJURY OR DEATH Before you leave the operator’s seat: • Lower the lift arms, put the attachment flat on the ground. • Stop the engine. • Engage the parking brake. • Raise seat bar, move pedals or hand controls until both lock. W–2262–0397
25 of 114
–5–
653 Bobcat Loader Operation & Maintenance Manual
