SEAT BAR RESTRAINT SYSTEM (CONT’D) Figure OI-13 SEAT BAR Seat Bar
Interlock Interlock Shield MC-1668B
When the seat bar is raised, spring forces raise the interlocks [Figure OI-13].
Dealer Copy -- Not for Resale
The foot pedals will not pivot when the interlock is up. (See SEAT BAR RESTRAINT SYSTEM on Page PM-11)
