DISPLAY CONTROLLER PANEL SETUP (CONT’D)
Viewing Service Codes (Keyless)
Viewing Service Codes (Key Switch)
Figure SA-4
Figure SA-3 3
1
1
Stop
2
On
Start
4
Press the enter code button (Item 1) [Figure SA-4] and the display will become lighted and there will be two short beeps. 3 Press and hold the LIGHTS Button (Item 2) for two seconds to view SERVICE CODES in the HOURMETER/ CODE DISPLAY (Item 2) [Figure SA-4]. If more than one SERVICE CODE is present, the codes will scroll on the HOURMETER/CODE DISPLAY. (See Service Codes List on Page SA-3.)
4
2
NOTE: Corroded or loose grounds can cause multiple service codes and/or abnormal symptoms. All instrument panel lights flashing, alarm sounding and lights flashing, could indicate a bad ground. The same symptoms could apply if the voltage is low, such as loose or corroded battery cables. If you observe these symptoms, check grounds and positive leads first.
B-15819E
Turn the key switch (Item 1) [Figure SA-3] to the ON position but do not start the engine. Press and hold the LIGHTS Button (Item 2) for two seconds to view SERVICE CODES in the HOURMETER/ CODE DISPLAY (Item 3) [Figure SA-3]. If more than one SERVICE CODE is present, the codes will scroll on the HOURMETER/CODE DISPLAY. (See Service Codes List on Page SA-3.) NOTE: Corroded or loose grounds can cause multiple service codes and/or abnormal symptoms. All instrument panel lights flashing, alarm sounding and lights flashing, could indicate a bad ground. The same symptoms could apply if the voltage is low, such as loose or corroded battery cables. If you observe these symptoms, check grounds and positive leads first.
SA-6 138 of 177
335 Operation & Maintenance Manual
Dealer Copy -- Not for Resale
P-19199A
