DISPLAY CONTROLLER PANEL SETUP
Figure SA-1
Passwords
1 2
All new machines with Deluxe Instrumentation arrive at Bobcat Dealerships with the panel in locked mode. This means that a password must be used to start the engine. For security purposes, your dealer may change the password and also set it in the locked mode. Your dealer will provide you with the password.
3
Master Password: A permanent, randomly selected password is set at the factory which cannot be changed. This password is used for service by the Bobcat dealer if the Owner Password is not known; or to change the Owner Password.
B-15819
Changing The Owner or Operator Password Owner Password: There is only one Owner Password (CodE 0). It must be used to change the owner or operator passwords. See below for changing the Owner Password.
Press and hold the ENTER CODE button (Item 1) for three seconds. CodE 1 will appear on the LCD (Item 2) [Figure SA-1].
Operator Password: There can be up to three operator Passwords (CodE 1, CodE 2, CodE 3). See below for changing the Operator Password.
Press the ENTER CODE button until the desired Code (CodE 0, CodE 1, CodE 2, CodE 3) appears. CodE 0 is Owner Password, the other codes are Operator passwords.You now have 40 seconds to use the keypad (Item 3) [Figure SA-1] to enter each digit of a new four digit password.
Password Entry (For Starting and Operating the Machine) Press ENTER CODE button (Item 1). The panel will become lighted and there will be two short beeps. CodE will appear on the LCD (Item 2) [Figure SA-1].
Enter the new four digit password. After the fourth digit is entered, there will be two short beeps and rPEAt will appear.
NOTE: After you press ENTER CODE you have 40 seconds to use the keypad (Item 3) [Figure SA-1] to enter the password. (If more than 40 seconds is used, the process will abort and you will need to start over.
Re-enter the new four digit password to verify. If the new passwords match, there will be two short beeps, Code will appear for 1 second and then the LCD will return to HOURMETER function.
Enter the password. For each digit that you enter, a dash will appear on the LCD. If the password was entered correctly, there will be one long beep.
NOTE: If the new passwords do not match, there will be one long beep and Error will appear for 1 second and then the LCD will return to HOURMETER function.
NOTE: If the password was incorrect there will be three short beeps and Error will appear on the LCD. Press the ENTER CODE button again and start over. After three failed attempts, you must wait three minutes to try again. You are now ready to start and operate the machine. If you will be changing the operator password, do not start the engine. (See Changing The Owner or Operator Password on Page SA-4.)
SA-4 136 of 177
335 Operation & Maintenance Manual
Dealer Copy -- Not for Resale
Perform Password Entry at left, but do not start the engine.
