BMW Dl 2 Marine engine Install; the bearing cover and measure the crankshaft end clearance. Specified end clearance with crankcase cold: 0,1 0,3 mm; with crankcase warm: 0,3 0,5 mm.
—
ED
—
Fit the large counterweight on the flywheel side. Tighten the socket-head screws of the counterweights with a tightening torque of 65 Nm. JOB SEQUENCE IN ASSEMBLING THE ENGINE — — — — — — — — — — — — — — — — — — — — — — — — — — — —
— — — — — — — — —
Install thecrankshaft Fit the b~aring cover Measure the crankshaft end clearance Install the fuel control system lnsta!l the connecting rod Install the counterweights Install the piston Fit the crankshaft gear Install the rocker levers Install the camshaft assembly Fit the timing cover Fit the hand-crank guide Install the cylinder Measure the piston projection Fit the valves Install the decompression lever Fit the rocker arms Fit the cylinder head Set the valve clearance Set the decompression device Install the injector Fit the temperature pickup Fit the thermostat Install the exhaust manifold Install the water pump Install the injection pump Install the fuel pump ~ith electric engine stop as accessory) Install the electric engine stop Install the air filter Install the stator Fit the flywheel housing ring Install the flywheel with rotor Install the clutch Install the gearbox Install the retaining plate with engine electricals Install the starter Set the injection pump
ED
ED
C 50
