BMW Dl 2 Marine engine Fig. 89 Disengage the two circlips (89/1) and pull the rocker lever shaft (89/2) out of the rocker levers (89/3) and out of the rocker lever bracket (89/4). Pay attention to the shim(s) (89/5). Examine the rocker levers for wear and exchange, if necessary.
89 Installing the rocker levers Installation takes place in the reverse sequence to removal. Note: Fit the rocker lever shaft with the longer ridge facing the crankcase. Tighten the socket-head screw (89/6) with a tightening torque of 60 Nm. —
Install the camshaft assembly
REMOVING AND INSTALLING THE FUEL CONTROL SYSTEM Removing the fuel control system — —
Remove the camshaft assembly Remove the rocker levers
Fig. 90 Shift the control lever to the “Stop” position and remove the circlip (90/1) from the governor lever shaft.
90
Fi~
41
