BMW 012 Marine engine REMOVING AND INSTALLING THE TIMING COVER Removing the: timing cover Remove the water pump Remove the fuel pump
— —
Fig. 7Q Screw out the four socket-head screws (70/1) and
take the crank-handle guide (70/2) out of the timing cover. Screw outthe ten socket-head screws (70/3).
a 70 Fig. 71 Screw on the extractor, special tool No. 74 64 1 333 555, with two timing cover screws and press the timing cover off the intermediate ring (71/2). Remove the seal. Take the shaft seal (71/3) out of the timing cover.
71 Fig. 72 Examine the two bearings (72/1,2) for damage and
exchange them, if necessary. For this purpose, heat the timing cover to approx. 80° C and take out the bearings.
72 33
