8.
Detach it from the system.
9.
Disconnect the power board cable from the touchpad board.
10. Remove the two screws securing the power board. 11. Detach it from the position.
12. Remove the two screws as shown. 13. Be aware of indention positions to unhook the touchpad support. 14. Detach the touchpad support from the system. 15. Gently detach the touchpad board from the system.
Disassemble the Mainboard
62
1.
Disconnect the sub-woofer and speaker cable from mainboard.
2.
Remove the one screw securing the mainboard.
3.
Remove the six henx screws from the rear of the mainboard.
4.
Detach the mainboard from the case.
Chapter 3
