Buttons Application Launch Buttons Launch Keys
Description
Launch Button P
<Launch manager>
Launch Button e
<Launch eManager>
Specific Keys Wireless Button
Wireless enable/disable
E-mail Button
Launch Outlook Express
Bluetooth Button
Enable/disable bluetooth
Internet Button
Launch Internet Explorer
NOTE: Detail description and definition of application Launch Buttons, please reference the External spec.
Wireless LAN & Bluetooth Default Setting Wireless LAN
Bluetooth
ON
OFF
At Logon Screen
Follows user setting in previous OS session (by ePM or Launch Manager)
Follows user setting inprevious OS session (by ePM or Launch Manager).
In OS
Controlled by ePM or Launch Manager.
Controlled by ePM or Launch Manager.
After loading default settings in BIOS
Power Button The activity of the power button is as follows: T T T T
If power button is pressed for less than 1 second then nothing happens. If power button is pressed for more than 1 second but less than 4 seconds then system would execute User Requested OFF before the system entered into OS. If power button is pressed for more than 4 seconds then the notebook will be powered off by power button over-ride feature. If OS is running in ACPI mode, the power button acts as the sleep button, and let OS controls the policy of power button which is defined in Power Option under the OS.
Power Button Over-ride Holding down the Power Button for 4 seconds will cause an unconditional transfer to the Off state without notifying the operating system. If press power button for less than 4 seconds, the system will enter suspend to RAM or OFF state according to OS power option setting.
Lid Switch This section describes the expected behavior of the system when the lid is opened or closed by the user. If the system is running under legacy mode: T
Closing the lid will turn off LCD backlight.
If the system is running under ACPI mode: T T
The operating system will determine what action to take when the lid is closed. (Windows does not define Lid Open action in Power Option control panel) The function of lid close will follow the OS setting in power management (Nothing, standby, Hibernate or
