(6) Tie down the platform so that it is not swung during the transportation. At this time, be sure to allow the clearance between the bottom of the platform and the transport vehicle bed. (7) Do not tighten the tie down chains marked (∗) too much. Tighten them just so that the platform is not swung or bounced during the transportation.
※
Clearance
※
2.
Wooden block
When hoisting Pass the sling chains or wire ropes through the hoisting rings located on the turntable and hoist the machine slowly.
Gravity centerline
Caution: • Use a sling chains or wire ropes strong enough to withstand the weight of the machine. Model Weight SR18AJ / ISR60J 12,900 kg (28,400 LBS) SR21AJ / ISR70J 15,200 kg (33,500 LBS) • Be sure to retract and lower the boom fully before hoisting the machine.
60
