Jumper and Connector Locations Top View
Item
Description
Item
Description
DCIN1
DC-In Jack
1394_1
IEEE 1394 Port
USB2
USB Port
LOUT
Line-Out Jack
USB1
USB Port
MIC1
Mic-In Jack
TV1
S-Vedio Port
USB3
USB Port
CRT1
External Display Port
SD1
Card Reader
LCD1
LCD Coaxial Cable Connector
TPAD1
Touchpad Connector
NB
North Bridge
KB1
Keyboard Connecto
SB
South Bridge
DM2
DIMM Socket 2
INV1
Inverter Cable Connector
U89
VGA chip
RJ1
Modem Jack/LAN Jack
DOCK1
Expansion Port
CBUS1
PCMCIA Slot
