Bottom Side
#
Item
Description
#
Item
Description
1
JP14
USB CONNECTOR
2
JP15
CRT CONNECTOR
3
JP16
TV-OUT CONNECTOR
4
JP17
MINI CARD CONNECTOR
5
JP18
DDRII SODIMM SLOT
6
JP19
DDRII SODIMM SLOT
7
JP20
FAN CONNECTOR
8
JP21
USB CONNECTOR
9
JP22
RJ45 CONNECTOR
10
JP23
CPU SOCKET
11
JP24
ODD CONNECTOR
12
JP25
5-in-1 CONNECTOR
13
JP27
HDD (PATA) CONNECTOR
14
JP28
MINI PCI SLOT
15
JP30
NEW CARD SOCKET
16
JP31
BLUETOOTH CONNECTOR
17
JP32
SPDIF OUT JACK
18
JP33
LINE-IN JACK
