Boot PhoenixBIOS Setup Utility Info.
Main
Advanced
Security
Boot
Exit
Item Specific Help
Boot priority order: 1: SATA: ST9120821AS-(S1) 2: IDE 1: 3: IDE 0: MATSHITADVD-RAM UJ-845S-(PM) 4: PCI BEV: Realtek Boot Agent 5: USB HDD: 6: USB CDROM: 7: USB FDD: 8: USB KEY:
Keys used to view or configure devices: Up and Down arrows select a device, then press <F6> to move it up the list, or <F5> to move it down the list. Press <Esc> to exit the menu.
F1 Help
↑↓
Select Item
F5/F6 Change Values
F9 Setup Defaults
Esc Exit
←→
Select Menu
Enter Select 4 Sub-Menu
F10 Save and Exit
This menu allows the users to decide the order of bootable devices to load the operating system. It identifies all the bootable devices in the system and attempts to boot them in the order specified. Bootable devices include the diskette drive in module bay, the hard disk and the CD-ROM/DVD drive in module bay and onboard LAN device.
48
Chapter 2
