Information PhoenixBIOS Setup Utility . Info.
Main
CPU Type: : CPU Speed :
Advanced
Security
Boot
Exit
AMD Turion (tm) 64 X2 Mobile Technology 1600 MHz
HDD Model Name: ST9120821AS-(PM) HDD Serial Number: 5PL08H08 ATAPI Model Name: MATSHITADVD-RAMUJ-8-(SM) ATAPI Serial Number: System BIOS Version: V0.17A VGA BIOS Version: ATi 009.012.001.005 EC BIOS Version:
V0.17A
Serial Number:
HCW5021012617000C01601
Asset Tag Number: Product Name: Manufacturer Name:
Aspire 5110 Acer
UUID:
37363032313033353761000FB0F34EC7
F1
Help
Esc Exit
↑ ↓ ←→
Select Item
F5/F6 Change Values
F9 Setup Defaults
Select Menu
Enter Select 4 Sub- Menu
F10 Save and Exit
• CPU type: This item will show the CPU information of the system. • CPU speed: This item will show the COU clock speed. • HDD model name: The hard disk model name is automatically detected by the system. If there is no hard disk present or unknown type, “None” should be shown on this field. • HDD serial number: If no hard disk or other devices are installed on primary IDE master, it will display a blank line. • System BIOS version: This field reports BIOS version of the system. • VGA BIOS version: This field reports VGA BIOS version of the system. • Serial Number: This item is the serial number of the system. • Asset Tag Number: This item is the asset tag number of the system. • UUID: It shows only when an internal LAN device is available.
42
Chapter 2
