Hardware Specification and Configuration Processor Item
Specification
Type
AMD TurionTM 64 X2 dual-core TL-50/ TL-52/TL-56/TL-60/TL-62 processor or higher
AMD SempronTM 3200+/3400+/3500+ or higher
Package
939 pin lidded micro PGA
754 pin lidded micro PGA
Feature
• Compatible with Existing 32-bit code base • Integrated memory controller: 128-bit DDR SDRAM at 100/133/166/200MHz • Dual-core architecture: discrete L1 and L2 cache structures for each core
• Compatible with Existing 32-bit code base • Integrated memory controller: 64-bit DDR SDRAM at 100/133/166/200MHz • HyperTransportTM Technology to I/O devices: one 16-bit link supporting speed up to 800MHz (1600 MT/s) or 3.2 GB/s in each direction
• HyperTransportTM Technology to I/O devices: one 16-bit link supporting speed up to 1GHz (2000 MT/s) or 4 GB/s in each direction On-die second (L2) cache
1024KB
512KB
System Board Major Chips Item
Specification
Core logic
ATi RS485MC + ATi SB460
Super I/O controller
SMSC SIO1036
Audio controller
Codec ALC883
Video controller
Integrated VGA solution for ATi RS485MC
HDD controller
ATi SB460
Keyboard controller and battery management unit
ENE KB910
Card bus PCMCIA controller
ENE CB714 (used ENE 1410 when without Card reader function)
LAN controller
RTL8110SBL
IEEE 1394
VIA VT6311S
Hard Disk Drive Seagate Model ST9120821A ST9120824A
ST9100824 ST9100825A
ST98823A ST980829A
ST96812A ST960812A
ST9402112A
80
60
40
3
ST96812A: 3 ST960812A: 2
2
Formatted Gbytes (512 bytes/sector) 120
100
Physical read/write head 4
4
Discs
30
Chapter 1
