Detach the WLAN board from the WLAN socket.
NOTE: When attaching the antennas back to the WLAN board, make sure the cable are routed properly.
Removing the Hard Disk Drive Module 1.
See “Removing the Battery Pack” on page 53.
2.
See “Removing the SD Dummy Card” on page 54.
3.
See “Removing the Express Dummy Card” on page 54.
4.
See “Removing the Lower Cover” on page 55.
5.
Remove the screw (A) securing the HDD assembly to the unit.
6.
Step
Size (Quantity)
Color
Torque
1
M2 x L4 (1)
Black
3 kgf-cm
Pull the HDD module out by pulling on the mylar attached to it, gently slide-out the HDD module from its bay.
NOTE: To prevent damage to device, avoid pressing down on it or placing heavy objects on top of it. 58
