21 DISCO 9100 - 8400 10 Electric system main group 38339
Designations Pos
Component
Coordinates
A068
Mower unit control module
-
A091
Control terminal
-
-
-
-
B296
Mower unit pressure sensor
detects the pressure when raising and lowering the mower units. This signal deactivates individual mower unit lifting in automatic mode. When the pressure sensor detects no pressure change for more than 2 hours, the electric system is shut down.
-
-
-
Y407
Left mower unit load relief solenoid coil
Solenoid valve energised: Hydraulic oil flows into the piston top space of the left mower unit load relief hydraulic cylinder (3195) = Increase of mower unit load relief. Solenoid valve not energised: Closed position of left mower unit load relief hydraulic cylinder (3195).
Y408
Right mower unit load relief solenoid coil
Solenoid valve energised: Hydraulic oil flows into the piston top space of the right mower unit load relief hydraulic cylinder (3196) = Increase of mower unit load relief. Solenoid valve not energised: Closed position of right mower unit load relief hydraulic cylinder (3196).
Y412
Left mower unit solenoid coil
is energised for raising and lowering the left mower unit hydraulic cylinder (3132); at the same time, the left mower unit LS priority solenoid valve (Y410) is energised. Solenoid valve not energised: Closed position of left mower unit hydraulic cylinder (3132).
Y413
Right mower unit solenoid coil
is energised for raising and lowering the right mower unit hydraulic cylinder (3133); at the same time, the right mower unit LS priority solenoid valve (Y411) is energised. Solenoid valve not energised: Closed position of right mower unit hydraulic cylinder (3133).
Y414
Left mower unit height block valve solenoid coil
Solenoid valve energised: Hydraulic oil flows into the piston top space of the left mower unit hydraulic cylinder (3132); at the same time, the left mower unit LS priority solenoid valves (Y410) and the left mower unit solenoid valve (Y412) are energised. Solenoid valve not energised: Closed position of left mower unit hydraulic cylinder (3132).
Y415
Right mower unit height block valve solenoid coil
Solenoid valve energised: Hydraulic oil flows into the piston top space of the right mower unit hydraulic cylinder (3133); at the same time, the right mower unit LS priority solenoid valves (Y411) and the right mower unit solenoid valve (Y413) are energised. Solenoid valve not energised: Closed position of right mower unit hydraulic cylinder (3133).
00 0290 120 0 - SYS DISCO - 09/08
183
