16 DISCO 8500 C-6, 8500 C-8, JAGUAR 8500 C - Electric system Overall circuit diagram 38323 16 DISCO Overall circuit 8500diagram C-6, 8500 C-8, JAGUAR 8500 C - Electric system
Key to diagram Pos.
Designation
Remark
d
Diodes
-
F
Fuse
10A
S2
Switch
Swing Disco in or out
S3
Switch
Raise / lower left Disco
S4
Switch
Raise / lower right Disco
Z
Central terminal compartment
The lines in the grey area are conductor tracks on the board
-
-
-
5
Control light
Power supply
6
Control box
with switches S1, S2, S3 and S4
7
Socket
beneath the operator's platform
12
Relay
for lock-up valve unit 89 and 99
13
Relay
for 4/3-way solenoid valve (item 50A)
14
Relay
for 4/3-way solenoid valve (item 50B)
15
Relay
for lock-up valve unit 109
17
Terminal strip plus
in the central terminal compartment (located above the relays)
19
Terminal strip, left
-
19a
Terminal strip, right
-
50
4/3-way solenoid valve for front attachment
Series
50A
Solenoid
Swing out mower units
50B
Solenoid
Swing in mower units, raise/lower
51
3/3-way solenoid valve
Front attachment raise/lower
70
Solenoid
Swing out right/left Disco
71
Solenoid
Swing in right/left Disco
72
Solenoid
Raise / lower centre Disco
73
Solenoid
Raise/lower left Disco
74
Solenoid
Raise/lower right Disco
75
Reed switch
only in Jaguar 800 series. Is fastened on the solenoid valve 51 (Raise). Caution: Observe installation position = The lettering must make contact with the solenoid
76
Switch and 3/3-way raise solenoid valve
only in Jaguar 6 series.
89
Solenoid
Right lock-up valve unit (closed when de-energised)
93
Oil pressure switch
150 bar (NO contact), actuates the solenoid valve 70
94
Oil pressure switch
85 bar (NO contact), actuates relay 12
00 0290 120 0 - SYS DISCO - 09/08
127
