Measurement and control Checking the oil pressure Test conditions: – Engine running idle, empty. – Oil temperature at 93°C.
HYDRO TESTER
101hsm52
Fig. 55
– Connect a hydraulic fitting (1/8 – 16 x 200) onto the pressure tap. – Connect test set n° 00 0178 310 0. The minimum oil pressure must be 1,05 bar.
A1.58
Axion 850-810 – 10.2010 – GB
