"CMatic" cartridge – Use a hammer with plastic bit. – Extract the clutch housing with the planetary train. Important: Extract the clutch housing carefully to avoid damaging the spans of the piston bushes in the console.
327hsm0x
Fig. 115
327hsm0y
Fig. 116
327hsm0z
Fig. 117
Disassembling clutch "K3/K4" – Remove jonc arrest. – Separate the clutch housing "K3/K4" from the satellite holder "P3/P4".
– Remove jonc arrest. – Remove the hub from the clutch.
Axion 840-810 – CMatic – 09.2010 – GB
B2.49
