"CMatic" cartridge Refitting the cartridge – Refit in reverse order to removal while observing the following instructions:
B
Important: Position the sleeve with its pin (A) on the shaft in a position allowing to fit the pin once the cartridge is fitted. – Before refitting the cartridge, clean the parting surface on the casing and cartridge. – Fit centering studs (B) on the gearbox casing (see 'Local manufactured tool').
A
– Apply a uniform layer of Loctite (518) on the sealing surface (see opposite). – Coat the O-rings (C) with miscible grease, to properly position them in the bottom of their respective grooves. Important: Check the presence of the centering pins. 332msm37
If the cab is removed:
Fig. 58
– Use hook n° 00 1139 439 0. Otherwise: – Present carefully the cartridge opposite the gearbox casing using the trolley n° 00 1136 143 0. – Push the cartridge fully without forcing.
C
332msm38
