911 GT3 (991) 1.10 Oil supply Compared with the current 911 Carrera models, the new 911 GT3 features classic dry-sump lubrication with a separate engine oil tank. This system ensures a reliable
Engine
Red - Pressure side
01_12_14
Orange - Intake side
Dry-sump lubrication To allow dry-sump lubrication based on the new generation of engines (991), the oil pan had to be completely redeveloped. The basis for this is the oil supply system used in the current 911 Carrera models with four oil extraction pumps for the cylinder heads, an additional oil extraction pump in the oil pan and an oil pressure pump.
1 cardiagn.com
oil supply for street and race circuit use.
There are also two additional oil extraction points in the oil pan at the front and rear so that the oil can be pumped out reliably into the separate oil tank even during heavy acceleration and intensive braking phases.
