Skid steers are perhaps the most versatile machines on a jobsite, with capabilities that enable them to tackle a wide range of tasks. Here’s a look at models from all the major suppliers, plus a look at system advances that help to maximize productivity and performance. To learn more, use the URL shown. Also be sure to visit the interactive version of this spec guide at www.ForConstructionPros.com/specguide/skid-steer to sort and compare models and specs based on your specific requirements.
2021
JOHN DEERE
John Deere skid steers feature turbocharged diesel engines that meet emission standards, run smooth and pack plenty of power and torque to take on a variety of different applications. This power system design delivers the tractive effort and leverage needed to handle heavy loads and power through rock or dirt piles, plus enhance productivity during grading or cleanup tasks. A key feature on Large Frame models is the Anti-Stall feature that monitors the engine load to quickly prevent the engine from stalling. This allows the operator to use the maximum horsepower efficiently when pushing large amounts of material.
GEHL
Gehl's hydraulic systems boost productivity by using some of the top technology combined with innovation. Hydraulic component efficiencies have improved through the years, allowing the machines to do more with small engines without sacrificing power. They consume less fuel and operate quieter than machines of the past. For maximum power, the range goes up to what is reported to be the largest skid steer in the market, the V420, which offers 120 hp and a rated operating capacity of 4,200 lbs.
www.forconstructionpros.com/10073086 Model R105 R135 GEN:2 R165 R190 R220 R260 V270 GEN:2 V330 GEN:2 V420
Net HP 34.7 46.6 69.3 69.3 72 72 72 72 120.7
Operating Weight (lbs.) 4,200 5,255 6,165 6,880 7,980 8,200 8,150 9,090 11,665
Rated Operating Capacity (lbs.) 1,050 1,350 1,650 1,900 2,200 2,600 2,700 3,300 4,200
Breakout Force (lbf.) 2,975 3,500 4,591 4,050 5,600 5,600 5,795 5,968 9,040
Height to Hinge Pin (in.) 107.5 110 118.8 120.5 123 123 130.3 131.2 143.8
Std. Hydraulic Flow (gpm) 14.5 16.8 20.4 18.5 23.5 23.5 23.5 23.5 30.1
www.forconstructionpros.com/10073480 Model 312GR 314G 316GR 318G 320G 324G 330G 332G
Net HP 48 48 61 61 66 70 89 97
Operating Weight (lbs.) 5,905 6,140 6,180 6,542 7,150 7,700 9,900 10,000
Rated Operating Capacity (lbs.) 1,550 1,760 1,750 1,945 2,190 2,690 3,000 3,600
Breakout Force (lbs.) 5,000 5,000 5,250 6,000 6,000 8,750 10,300 13,904
Height to Hinge Pin (in.) 115 120 115 120 122 126 132 132
Hydraulic Flow (gpm) 31 31 33 33 39 42 47 50
NEW HOLLAND
New Holland’s skid-steers include a new 8-in. LCD multifunction display that provides features like maintenance tracking, engine protection and ignition time-out right at your fingertips. Along with the easy to navigate user experience, the display offers electrohydraulic control settings that allow the operator to customize and adjust machine settings. The upgraded wiring components and drive pump sensors provide advanced features such as Auto Straight Line Tracking and CREEP mode when precision operation is critical.
CATERPILLAR INC.
Cat D3 series skid-steer loaders feature a hydraulic system that delivers optimal pushing power and breakout for everyday tasks. For more demanding tasks, the available High Flow XPS system supplies a high-flow, high-pressure auxiliary hydraulic system (32 gpm max/4,061 psi max). The additional pressure provided with the High Flow XPS system delivers enhanced productivity with demanding hydromechanical attachments such as cold planers (milling heads), wheel saws, stump grinders or industrial brush cutters.
www.forconstructionpros.com/10075307
www.forconstructionpros.com/10072472 Model L316 L318 L320 L321 L328 L334
Net HP 57 57 64 68 68 84
Operating Weight (lbs.) 5,510 5,930 6,470 6,970 8,245 8,900
Rated Operating Capacity (lbs.) 1,600 1,800 2,000 2,100 2,800 3,400
26 EQUIPMEN T TOD AY | July 2020
Breakout Force (lbs.) 5,270 5,550 7,300 7,270 8,620 9,323
Height to Hinge Pin (in.) 9' 4" 10' 10' 1" 10' 3" 10' 9" 10' 11"
Std. Hydraulic Flow (gpm) 18.4 20.6 20.6 24.2 24.2 24.2
Model 226D3 236D3 232D3 242D3 246D3 262D3 272D3 272D3 XE
Net HP 66 73 66 73 73 73 95 106
Operating Weight (lbs.) 5,849 6,567 6,514 7,138 7,478 8,296 9,133 9,573
Rated Operating Capacity (lbs.) 1,550 1,800 1,900 2,200 2,200 2,700 3,450 3,700
www.ForConstructionPros.com
Breakout Force (lbs.) 3,927 5,003 3,928 4,963 7,355 7,355 7,443 7,362
Height to Hinge Pin (in.) 110.9 122.9 118.1 121.1 124.2 124.9 127.1 128.6
Std. Hydraulic Flow (gpm) 18 20 18 20 23 23 23 23
