ROAD BUILDING SUPPORT

TRUCKS & TRAILERS

Talbert 55CC-RP Roller Paver Trailer

The 55CC-RP has a concentrated load rating of 55 tons in 12.5 ft. of deck for hauling various equipment including rollers, pavers, excavators and dozers.

• 53-ft. length with a 24-ft. clear deck length in the well

• 22-in.-high deck with 6-in. loaded road clearance

• 41-in.-long tapered ramps can be adjusted to accommodate various widths of equipment

• 57-in. rear slope has a 20.2 ° load angle suited for loading asphalt and soil rollers

• Manufactured with heavy-duty T-1, 100,000-psi minimum yield steel

Etnyre Era Live Bottom Belt Trailer

The redesigned Live Bottom Belt Trailer includes an aluminum huck-bolted bogie to reduce weight, fatigue and corrosion.

• Polymer belt flashing is easy to adjust and replace

• Smooth exterior bin sides for a clean and aerodynamic look

• Hardox interior bin walls resist wear and extend the life of the trailer

Arapaho Line Striping Truck by EZ Liner

The Arapahoe by EZ Liner has a versatile design for universal market appeal. The machine is capable of twocolor simultaneous painting from both sides of the truck.

• No CDL required to operate

• Equipped with three Graco Model 238-377 paint guns

• 230-gal capacity two compartment 10-gal 304 grade stainless steel tank

• On-board electric system

Pegasus Live Bottom Truck Bed

The extruded aluminum interlocking components on this all-aluminum body create a fully unitized structure that is strong, light and durable, plus allows for increased payload.

• Ultra-wide belt gives a low center of gravity and fast, controlled discharge of material

• Includes a 45-in. hot asphalt belt, smooth sides, aluminum fenders and dual-chain drive

Eager Beaver Paver PT Series Trailers

The Paver PT Series is designed to safely load rollers, pavers and milling machines.

• Low front approach, tapered ramps and gradual slope

• Run-up wheel covers with wood center

• Air-ride suspension

• All-wheel anti-lock brakes

• Hi-clearance self-lifting gooseneck

• Lock-in/lock-out outriggers

Brandt C550 Heavy Haul Trailer

The C550 55-ton hydraulic removable gooseneck construction trailer delivers more load versatility and faster turnaround times to ensure you get more out of every minute on the road or on-site. Premium QT100 steel construction and the largest deck well in the industry enable you to haul a variety of equipment with ease. These trailers are reliable, designed with long-lasting components that eliminate costly repairs and reduce the total cost of ownership. They are also backed by unmatched customer service and support.

Talbert Custom 70SA-RC-RA Trailer

This trailer incorporates multiple axle configurations based on customer requirements for versatility. The trailer’s design features a flip extension to accommodate a tri-axle jeep dolly, allowing for maximum load configurations. Talbert’s E3Nitro self-tracking axle extension accommodates a 3+3+3 configuration for proper weight distribution and weight transfer. The trailer maintains a 70-ton rating at half the deck length and offers 6-in. loaded road clearance. The 70SA-RC-RA features a wide center bolster for axles one and two and two and a lightweight design of axle three for even weight distribution.

• CAPACITY: 40,000 lbs.

• 20 Ton Air Brakes

• 8 Degree Loading Angle Low Profile

• Trailer Weight: 8,380 lbs.

• Overall Width:102", Length: 31'4"

• Deck Length: 21’ Flat (model shown)

• 6’ Beavertail

• Deck Height: 34"

• Tires: Eight 215/75R17.5 (H)

• Brakes: Air (Full ABS System)

• Ramps: 72" Long x 22” Wide Range: 102" Max. 29" Min.

• Lighting:100% Sealed Wiring harness and L.E.D. Lights

Standard Features On All Easy Loaders

ONE PIECE CAST LUNETTE EYE

Tested @ 275,000# and wrap around nose plate. Standard on all trailers.

HIGH TENSILE MAIN RAIL

One piece and cold formed. CROSS MEMBERS pierced through Main Beam for lowest possible deck height and more unitized frame.

APITONG/COMPOSITE DECK

Durable Composite Decking is fastened to the crossmembers with bolts and deck washers making it easier to replace decking when required.

Eager Beaver WIDE TRACK AXLES: 98”

Some Competition - 92”

ALL WHEEL ABS with Spring Brakes on all axles. Standard on all air brake trailers.

SUMITOMO BRAND TIRES th 76 6

National Dealer Supported. HUB PILOTED WHEELS Outboard brake drums for easier maintenance.
