The SC423XL Series Flow Controller is a unique device which supplies a constant flow with a self correcting action to compensate for changes in downstream pressure.
The SC423XL was designed for air and analyzer sampling systems which require very low flow rates (less than 10 scc/m). Connected to a vacuum cylinder, the SC423XL provides consistant flow control despite changes in the vacuum.
Veri flo Contact Information: Parker Hannifin Corporation Veriflo Division 250 Canal Blvd Richmond, California 94804 phone 510 235 9590 fax 510 232 7396 veriflo.sales@parker.com www.parker.com/veriflo Mobile App: m.parker.com/veriflo
Value Proposition:
Gas Flow Controller Low Flow, Vacuum Applications, Stainless Steel SC423XL Series Product Features: • Stable flows over a wide temperature band • Color coded orifices • Special CFC Free cleaning • Tamper Proof • Rugged design • Reliable Precision Flow Control as low as 1 scc/m. • Adjustable flows • Hastelloy C-22® diaphragms • Stable flows as vacuum pressure changes from 28 in. Hg to 5 in. Hg
Flow Curves
Flow Stability Curve- .0016 orifice
Flow Rate (scc/m)
Tank Pressure (Inches Hg Vacuum)
Flow Stability Curve- .002 orifice
Flow Rate (scc/m)
Flow Stability Curve- .0012 orifice
Tank Pressure (Inches Hg Vacuum)
Flow Stability Curve- .003 orifice
Flow Rate (scc/m)
Tank Pressure (Inches Hg Vacuum)
Safety Guide and Installation and Operating Instructions available at www.parker.com/veriflo
0 1 2 3 4 5 6 7 8 0 5 10 15 20 25 30
0 2 4 6 8 10 12 14 16 0 5 10 15 20 25 30
Tank Pressure (Inches Hg Vacuum) Flow Rate (scc/m)
0 5 10 15 20 25 30 7580859095100105110115120125 Temperature ( F)
5% Flow Drop 8% Flow Drop 6% Flow Drop 0 0.5 1 1.5 2 2.5 3 3.5 4 0 5 10 15 20 25 30
Flow Rate (scc/m) Temperature Effect On Flow Rate
0 5 10 15 20 25 30 35 0 5 10 15 20 25 30
For an explanation of Ordering options please reference literature 25000275 at www.parker.com/veriflo Black = Standard Lead Time Configurations Blue = Extended Lead Time Configurations Green Italic = Express Service Program (ESP) Build an SC423XL Series by replacing the numbered symbols with an option from the corresponding tables below. Color Explanations: Body Material S = 316L Stainless Steel Sample Time/Flow Rate 3 = 27.1 - 27.7 sccm (Yellow) 8 = 10.0 - 10.4 sccm (Green) 12 = 6.5 - 6.9 sccm (Blue) 24 = 3.1 - 3.4 sccm (Red) Inlet Connection 4T = 1/4” A-LOK® Outlet Connection X = No Connections 4TS = 1/4” Tube Fitting 1 2 3 4 1 2 3 4 SC423XL S 24 4T 4TS SC423XLS244T4TS SC423XL Series Ordering Information Sample: Finished Order: Dimensional Drawing 4.29 (109 mm)
Materials of Construction
Wetted
For additional information on materials of construction, functional performance and operating conditions, please contact factory.
Functional Performance
Leak Rate Inboard Test Method
External 1 x 10-6 scc/sec He Approx. Weight 1.75 lbs. (0.80 kg) Operating Conditions
Maximum Inlet Atmospheric Outlet Vacuum Flow (see Flow Curves) As low as 1 scc/m Temperature -40°F to 200°F (-40°C to 94°C)
Hastelloy C-22® is a registered trademark of Haynes International, Inc. A-LOK® is a registered trademark of Parker Hannifin Corporation
