selecfedsolesoids

Tool

Other functions include determining and laying out compound miter cuts, locking into any angle for use as a trisquare, checking the alignment of radial arm or table saws, and as an educational aid to illustrate angles. This new tool also has many advantages for use in finish carpentry, general carpentry, cabinet making, hobby work, sheet metal work, and plumbing. The Mite-RGage can save the professional valuable on-the-job time and virtually eliminates trial-and-error methods. For the do-it-yourselfer, it takes out the guesswork and reduces related frustrations.

It is made of Lexan and is guaranteed not to break, crack, or warp under normal usage.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach, Ca.92660.

Helps the Air Box

A louvered aluminum window screen developed by Kaiser Aluminum can reduce solar heat gain through windows by as much as 80%, resulting in substantial savings on air conditioning requirements and energy costs.

The solar control ShadeScreen consists of tiny built-in aluminum louvers (17.5 per inch) which intercept all of the sun's scorching rays during the hottest hours of the day while allowing controlled useful light to enter.

In calculations based on typical conditions prevailing on July 2l at

4 p.m. at 40o North Latitude (a line stretching roughly from New York City to Quincy, Ca.), it was shown that ordinary window glass facing west allowed a solar heat gain of 216 Btu's per hour to penetrate each square foot of glass. Covered with ShadeScreen, this same window area reduced the heat gain to 45 Btu's per hour. Even greater savings are possible at locations farther south. Even without air conditioning, ShadeScreen installed on sunny windows can reduce inside room temperatures by as much as 15 degrees

WRITE: The Merchant Maeazine. 4500 Campus Dr., suite 476. NEwporr Beach. Ca. 92660.

Waterproof Roof Decks

Plyroof SRC is specially designed as a smooth-roof composite, ideal for lightweight roof systems, both old and Branford, CT - Plyroof SRC, a composite waterproofing membrane for roof systems, was specifically developed for smooth (no ballast) installation on lightweight roof structures. It gets its unique characteristics from a three-part laminating process. Top layer is PVC (polyvinylchloride); middle layer is a Nylon

Cherry Batten Styling

Quaker Maid kitchens has introduced "Fireside," a new beveled edge, batten door style. Crafted from knotty cherry, this new door style is available in all of Quaker Maid's woodtone finishes.

It g]ows with the charm of early country styling, yet it's planned for modern kitchen keeping. Bold, brass hardware is accented bv door oulls of porcelain white.

WRITE: -The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach, Ca.92660.

scrim; bottom layer, depending on application can be either Butyl or Neoprene. All are bonded together. Result is a membrane material that will fully adhere to lightweight decks without the need for ballast. The laminant construction allows the membrane to accommodate the flexural movements of lightweight construction without ripping, tearing or developing punctures.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach. Ca.92660.

September, l977

Garage Door Innovation

New jamb-type overhead garage door hardware with exclusive patented features that allow ouick installation. sinrple and easy adjustment, smooth operation with a standard perfect arc, and is compatible with electric operators, has been introduced by Beehive Door Co.

Two types of hardware are available, depending upon the overhead clearance. The standard perfect arc requires only a maximum head clearance of 9-112" and is adjustable in one simple operation to a minimum head clearance of 2-314". Low overhead hardware only requires a clearance of l-112". The hinge's balance and perfect arc allow the door to open and close smoothly and evenly either manually or with an automatic electric ooerator.

The hardware's compatibility with electric operators provides significant savings where operators and low head room clearances can be effected with jamb-type hardware thereby eliminating the need for more costly track hardware.

Safe'and compact, it is the first jamb-type hinge with the spring factory-mounted as part of the hardware. Once the door is placed in its opening, one man can install the hardware in l5 minutes first bolting it on each jamb and then securing each lever arm to the door. The hardware uses only one type spring. simplifying inventory.

Adjustments are simplified with an exclusive patented feature. Only a wrench is needed to adjust a bolt in a slotted scale. Another slotted adjustment allows quick alignntent of the door if the jamb is not true.

WRITE: The Merchant Magazine. ,1500 Campus Dr., suite 476, Newport Beach. Ca. 92660.

Acrylic/Wood Railings

Julius Blum & Co. has a new acryl- ic/wood railing system; acryliciwood facings bonded to a structural aluminum spine. The designer can select the beauty of natural walnut or oak in the facings, and still obtain the structural capability afforded by an aluminum spine.

WRITE: The Merchant Masazine. .1500 Camnus Dr.. suite 476. N6wport Bcach. Ca. 92660.

Put The Top Down

A new series of convertible range hoods that enable a dealer to carry a single decorator-styled hood in inventory and thus reduce his investment in space and dollars is being added to Kich-n-vent line of range hoods by Home Metal Products Co.

The 2100 Series features a unique venting structure that allows a standard hood to be converted at the time of installation into any of three venting systems - 7" round, 3% x lO" , or ductless.

Kich-n-vent's "3-in-1" hood, Model 2185, is a standard 2100 Series hood with all three venting options - ductless or vented - all in one box.

WRITE: The Merchant Magazine. 4500 Campus Dr., suite 476, Newport Beach. Ca.92660.

Rack'em Up

Jarke Corporation's Speedstore rack is shipped completely knockeddown and bolts quickly into a structure for vertical storage of sheet, plate, and other flat materials.

Speedstore units are designed in l0 foot sections and can be ioined end-for-end in continuous rows of any multiple. Six inch compartments individually accept up to 6000 lbs. of sheet or light plate. Each section provides five full compartments plus a half compartment at each end. Seven feet wide and thirty inches high, the Speedstore is designed for material

MAHOGANY WOOD SALES, LTD.

sales agents and save $$$$.

The Merchant Magazine sizes ranging from three to six feet in width and eight to twelve feet in length.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach. Ca. 92660.

Raingutter I mprovement

Plastmo, Inc. has a lighter, stronger, and less expensive plastic bracket for its polyvinyl chloride snap-together raingutters. The plastic bracket is the product of five years research at Plastmo's main plant in Copenhagen, Denmark, and is made of Hostalit-Z, Plastmo's exclusive pvc formula modified with polyethylene chloride.

Plastmo's Hostalit-Z plastic bracket can withstand the same tension as its epoxy-coated metal bracket but retails for 55d each, while metal retails for 89( each. The new plastic bracket weighs 7IVo less than the conventional metal bracket, but a specially designed flange on the lower edge insures maximum strength. Plastmo has also repositioned the mounting holes on the Hostalit-Z plastic bracket for easier access by the builder or do-it-yourselfer.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach. Ca.92660.

September, 1977

Advanced Forklifts

J I Case Co. has a new "C" series forklifts offering componentized power train, four-speed synchromesh transmission with power shuttle and torque converter. The features are standard throughout the Construction King line of 584C, 585C and 586C models.

The componentized power train design simplifies servicing, e.g., individual power train components can be removed without disturbine other drive line members, which cin save maintenance time and expense over conventional torque tube designs. A rugged unitized frame, which absorbs stress and shock loads, guards the power train alignment of the new 50 hp (37, 3 kW) SAE net forklift models.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach, Ca.92660.

Locks & Luggage Promo

A popular dealer sales promotions in hardware, Kwikset's "Locks & Luggage," got underway this month. For every case of Bel Air entry locksets ordered between September lst and November lst, 1977, dealers will receive free a deluxe, two+uiter suitcase. The promotion applies to both visually packaged and regular pack Bel Air locksets in polished braSs finish.

The luggage is claimed to be a $45 retail value. Dealers may, at their option, re-sell the suitcases, use them for premiums or traffic builders, or use them personally.

WRITE: The Merchant Magazine, 4500. Campus Dr., suire 476, N-wport Beach. Ca. 92660.

Merchandising Wi re Hardwa re

Gerwin claims to have designed the potential for a compact wire hardware center with the introduction of nine modular template merchandisers.

The Pac-Rak program offen the flexibility of creating an add-on wall display, starting with only one or several of the 10" x 10" or 12" x 16" units. Each holds from 40 to 100 customer-reusable moulded pacs with items in a selection of sizes. Included are turnbuckles, U-bolts, screw eyes, and a variety of other home-use hooks.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach, Ca.9266O.

Insulating Cork

Corco Insulating Cork, a decorating and insulating product marketed by The Butter Co., is a wall covering', coarse, dark cork in 12" x 24" panels. A good insulator, having an

R factor of 3.84 per inch, each package contains four, 1" thick panels, and covers 8 sq. ft.

It can be used on outside walls. ceilings, rafters, or attic floors.

The Cork will not form a vapor barrier and will prevent moisture build up behind insulation. It will not absorb water, is warm to the touch, and is rot proof and vermin proof. Cork is the world's only natural insulation; from trees, a renewable resource.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach. Ca. 92660.

Locked ln

Interlocking Paving Stones are a new concept in concrete paving in the U.S., although they have a past history of successful use in Europe and Canada.

High strength concrete stones interlock upon installation and can withstand tremendous ooint loads

Quality Lumber

REDWOOD-K||n. Dried or Green

Rough or Surfaced

DOUGLAS FIR-Rough Cuttings

Premium 4x4 and 4x6-FOHG

1450f and 1750f Stress

Kiln Dried Clears

STUDS-Green Douglas Fir, Redwood & Hem-Fir, Kiln Dried Pine & Spruce

Station to station

PHILKELTY 707-487-3201

DEAN FOX 707-487-3231

DENNTS LOWE 707-487-6061

P.O. Box 250 Smith River, California 95567

TREES ARE AMERICA'S RENEWABLE RESOURCE without cracking. They come in a variety of patterns and colors, and are durable, possessing the advantages of both rigid and flexible paving surfaces. No mortar, only sand is required in the joints, which makes them easy and quick to install.

The three available mosaic patterns (hexagonal, I-beamed shaped, and four-sided curved form) are available in earth tone shades of brown, red, charcoal, and natural. Turfstone (a grass paver) has open apertures for either turf or rock filling which makes them ideal for erosion control and parking areas.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach. Ca.92660.

Thermal Replacement Window

The model 587 is a new heavy-duty aluminum replacement window featuring fully insulated master frame, sash frames, insulated glass and double weatherstripping with high density wool pile and fin seal. Maker is Season-all Industries, Inc.

Its design engineering stresses energy efficiency and puts this metal window, which is virtually maintenance-free, into the same class as fine quality wood windows in terms of

September, 1977 avoiding the problem of condensation, according to Season-all.

This new window by Season-all is custom-fit. which makes it the economical way to replace old worn-out windows.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach. Ca.92660.

New Locking Network

A new locking system that secures doors on all four sides simultaneously has been introduced by the Mul-TLock Corp.

Mul-T-Lock security products feature an ingeniously engineered locking network which activates multiple deadbolts, like in a bank's vault, with an easy turn of the key. Unlike conventional door locks which utilize a single or double. bolt on one side of the door, MulT-Lock products feature four to six deadbolts which are driven deep into the door frame on all four sides including the threshold.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newporr Beach. Ca.92660.

Carved Wood Mouldings

Carved hardwood mouldings in 22 Accent* patterns for decorative applications by homeowners were featured by Klise Manufacturing at the National Hardware Show.

Accent mouldings in 4' lengths with price and instructions tag were displayed on two 1l-pattern modular merchandisers for hanging on perfboard fixtures or wall. The header demonstrated diy applications for enhancement of furniture and cabinetry, flush doors, walls and shelves. Suggested retail prices: - 4'lengths, 891 to $5.49, depending upon pattern intricacy.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach. Ca. 92660.

Keep Them Out

A new addition to its Doorshield line has been announced by Key Control Systems.

Doorshield II incorporates a protective stainless steel flange which extends beyond the basic unit and covers the door opening in the lock area.

Free Reader Service

For more information on New Products and New Literatur€, write fhe Merchant Magazine, 4500 Campus Dr., Suite 476, Newport Beach, Ca. 92660. Please mention issue date and page number so we can process your requsst fasterl Many thanks!

The protective cover renders the lock even more tamper resistant by reducing the possibility of attack directed against the bolt or strike; available in stainless steel. Designed only for use with doors swinging outward which have sufficient flat surface on the molding of the door frame to permit installation, it is offered in standard sizes to suit most cylindrical or mortise locks in general use.

WRITE: The Merchant Magazine, 4500 Campus Dr., suite 476, Newport Beach. Ca.92660.
