LIGHTFIXTURESCHEDULE

FORLOWVOLTAGELIGHTS.COORDINATEEMERGENCYPOWERPRIORTOROUGH-IN. FIXTURETOBEWETLOCATIONRATED.PROVIDEJUNCTIONBOXAND3/4"CONDUIT DECORATIVEPENDANT.VERIFYALLOPTIONSWITHINTERIORSPRIORTOORDERING.

RECESSED2X4FLATPANELWITHACRYLICDIFFUSER.

RECESSED2X2FLATPANELWITHACRYLICDIFFUSER.

THEELECTRICALCONTRACTORSHALLPROVIDEANDINSTALLALLDISCONNECTSWITCHES,RECEPTACLE,ETC. TOMECHANICAL/PLUMBINGANDKITCHENEQUIPMENTASREQUIRED.THEELECTRICALCONTRACTORSHALL ALSOPROVIDEALLCORDS,PLUGS,CABLES,ETC.ONEQUIPMENTREQUIRINGSUCHITEMS. THEELECTRICALCONTRACTORSHALLPROVIDEFINALCONNECTIONSTOALLMECHANICAL/PLUMBINGAND KITCHENEQUIPMENTASREQUIRED. ALLDISCONNECTSWITCHES,FUSESIZES,PLUGCONFIGURATIONS,BREAKERSIZES,ETC.,SHALLBECOORDINATED WITHSHOPDRAWINGSPRIORTOINSTALLING.ANYEQUIPMENTINSTALLEDINCORRECTLYBECAUSEOFLACKOF COORDINATIONWILLBEREMOVEDANDINSTALLEDCORRECTLYATTHEELECTRICALCONTRACTOR'SEXPENSE. ELEC.CONTRACTORSHALLPULLAGROUNDANDANEUTRALWITHALLCIRCUITS,WHETHERSODESIGNATEDORNOT.

5.210.8GROUND-FAULTCIRCUIT-INTERRUPTERPROTECTIONFORPERSONNEL.GROUND-FAULTCIRCUIT-INTERRUPTER PROTECTIONFORPERSONNELSHALLBEPROVIDEDASREQUIREDIN210.8(A)THROUGH(F).THEGROUND-FAULT CIRCUITINTERRUPTERSHALLBEINSTALLEDINAREADILYACCESSIBLELOCATION.(B)OTHERTHANDWELLINGUNITS. ALL125-VOLTTHROUGH250-VOLTRECEPTACLESSUPPLIEDBYSINGLE-PHASEBRANCHCIRCUIT5RATED150VOLTSOR LESSTOGROUND,50AMPERESORLESS,ANDALLRECEPTACLESSUPPLIEDBYTHREE-PHASEBRANCHCIRCUITSRATED 150VOLTSORLESSTOGROUND,100AMPERESORLESS,INSTALLEDINTHELOCATIONSSPECIFIEDIN210.8(B)(1) THROUGH(B)(12)SHALLHAVEGROUNDFAULTCIRCUIT-INTERRUPTERPROTECTIONFORPERSONNEL.

6.THECONTRACTORSHALLENSUREPROVISIONSPERNOTEAREPROVIDEDANDCOORDINATEDWITHGEARMANUFACTUREPRIORTO ORDERINGGEARAND/ORCREATINGSUBMITTALS.

7.CONTRACTORTOVERIFYELECTRICALREQUIREMENTSFORALLEQUIPMENTPRIORTOROUGH-INWORK.NOTIFYENGINEER ONRECORDIFREQUIREMENTSAREDIFFERENTTHANSHOWNABOVE,PRIORTORESUMINGINSTALLATION.

1.ALLEMERGENCY/EGRESSFIXTURESSHALLBE CONNECTEDCIRCUITEH1-9ANDAHEADOFALL CONTROLS.

2.THEELECTRICALCONTRACTORISRESPONSIBLE FORPROVIDING0-10VCONDUCTORSFROMDIMMER SWITCHESTOALL0-10VLIGHTINGASREQUIRED. 3.ALLLIGHTSLOCATEDWITHINWORKAREASSHALL BEEQUIPPEDWITHINDIVIDUALSHIELDSOR SHATTERPROOFLAMPSASREQUIREDBY15ANCAC 18A-2630. 4.LIGHTFIXTURESSELECTEDBYOTHERSHALLMEET THEREQUIRED50FOOTCANDLEREQUIREMENTSIN THEKITCHENANDSTORAGEAREAS.

WORKAND/ORPRICING.FIELDLOCATIONMAYDIFFER FROMLOCATIONINDICATEDHEREIN.SEEDETAILTHIS SHEETFORCIRCUITIDENTIFICATION. 3.PROVIDETAPELIGHTINGFORCEILINGFEATURESAS DIRECTEDBYARCHITECT/INTERIORS.COORDINATE SPECIFICSWITHARCHITECT/INTERIORSPRIORTO ROUGH-IN.PROVIDEDIMMING/SWITCHESPEROWNER DIRECTION.1200WMAXALLOWANCEISASSUMED. 4.SETSENSORTIMEOUTTO30MINUTES. 1 GENERALNOTESTHISSHEET

GENERALNOTESTHISSHEET

1.ALLCONNECTIONSSHALLBECOORDINATEDWITH OTHERTRADES,FIELDLOCATIONSANDSHOP DRAWINGSPRIORTOANYROUGH-INWORK. 2.COORDINATEPLACEMENTOFGENERALWIRING DEVICESWITHARCHITECTURALELEVATIONSPRIOR TOROUGH-INWORK. 3.BRINGALLRECEPTACLESINSTALLEDINFURNITURE TOTHEFACEOFSAIDFURNITURE. 4.ITEMSSHOWNASDASHEDORMARKED'EX'ARE EXISTINGTOREMAINUNLESSOTHERWISENOTED.

KEYEDNOTESTHISSHEET

1.ECTOCOORDINATELOCATIONOFTELEPHONEBOARD WITHOWNERARCHITECTPRIORTOANYROUGHIN WORK.MOUNTHIGHONWALLABOVESHELVING.

2.PROVIDERECEPTACLEFORSIGNAGEPERNEC600.5(A).

3.COORDINATELOCATIONANDPOWERREQUIREMENTS FORELECTRONICSHUTDOWNSOLENOIDWITH PLUMBINGCONTRACTOR.PROVIDELINEANDLOW VOLTAGECONNECTIONSASREQUIREDFORSHUTDOWN OFASINTHEEVENTHOODFUNCTIONISACTIVATED.

4.PROVIDECONTACTORFOREQUIPMENTUNDERHOOD. CONTACTORTOHAVEASHUNTTRIPBREAKER.SEE DETAILTHISSHEET.

5.PROVIDEEMERGENCYHOODSHUTOFF.CONTRACTOR TOCOORDINATEREQUIRMENTSANDLOCATIONWITH HOODMANUFACTURER,OWNER,&LOCALAHJPRIORTO ROUGH-INWORK.

6.PROVIDE3/4"CONDUIT.COORDINATETERMINATION POINTSWITHOWNER/ARCHITECTPRIORTOROUGH-IN WORK.

GENERALNOTESTHISSHEET

1.ALLCONNECTIONSSHALLBECOORDINATEDWITH OTHERTRADES,FIELDLOCATIONSANDSHOP DRAWINGSPRIORTOANYROUGH-INWORK.

2.COORDINATEPLACEMENTOFGENERALWIRING DEVICESWITHARCHITECTURALELEVATIONSPRIOR TOROUGH-INWORK.

KEYEDNOTESTHISSHEET

1.THEELECTRICALCONTRACTORSHALLCOORDINATE EXACTREQUIREMENTSFORCOOLEREVAPORATORAND CONDENSERWITHMANUFACTUREPRIORTOROUGH-IN. ALLCONNECTIONS/PENETRATIONSSHALLBESEALED PERNEC300.7.

2.COORDINATELOCATION,CONNECTION,AND CONNECTIONTYPEFORWATERHEATERANDHOT WATERCIRCULATIONPUMPWITHPLUMBING CONTRACTORPRIORTOANYROUGHINWORK.

3.COORDINATEWITHMECHANICALCONTRACTORTO PROVIDEFIREALARMANDLINEVOLTAGECONNECTION FORFIRE/SMOKEDAMPER.ECTOPROVIDERIBRELAYAS REQUIREDFOROPERATION.

FIREALARMRISERNOTES: FACPHASAMINIMUM24HR.BATTERYBACKUP. ALLITEMSINDICATEDDASHEDAREEXISTINGTOREMAIN. FACPISCONNECTEDTOAULAPPROVEDCENTRALSTATION. ZONEPERNFPA72ANDMANUFACTURER'SRECOMMENDATIONS.

CONTRACTORSHALLMODIFYEXISTINGSYSTEMAS REQUIREDTOHANDLETHENEWFIREALARMDEVICES. SEESPECIFICATIONSFORADDITIONALREQUIREMENTS.

12"Lx2"Wx1/4"TCU. #6AWGTOBLDG.STEEL

PROVIDE1#6G(INSULATED), 1/2"CANDBONDTOBUILDING STEELANDMAINGROUNDING ELECTRODESYSTEMATSERVICE EQUIPMENT.

'MSB1'LOADTABULATION: EXISTINGCONNECTEDLOAD@125%1270.1KVA

DIAGRAMMATICALONLY POWERRISERDIAGRAM 8 E401 NOTES: 1.ITEMSSHOWNASDASHEDAREEXISTINGTOREMAINUNLESSOTHERWISENOTED. 2.FIELDVERIFYLOCATIONOFEXISTINGSERVICEMAIN. 3.THECONTRACTORSHALLCOORDINATEFAULTCURRENTSTUDYWITHFIELD CONFIRMEDTRANSFORMERFAULTCURRENT,PERUTILITY.PANELBOARDSAND GEARSHALLMATCHFAULTCURRENTOFSTUDY.PHENOLICLABELSINDICATING RESPECTIVEFAULTCURRENTSHALLBEMECHANICALLYFASTENEDTOPANEL. PROVIDEARC-FLASHWARNINGLABELSTHATCOMPLYWITHNEC110.16. 4.FAULTCURRENTRATINGSSHOWNHEREAREBASEDONEXISTINGBUILDING DRAWINGS.NOTIFYENGINEERONRECORDIFFIELDDETERMINEFAULTCURRENT RATINGSAREDIFFERENTFROMSHOWNABOVE.SEENOTE3.

NOTETOGENERALCONTRACTOR,SUBCONTRACTORSANDSUPPLIERS: TheGeneralContractorandallSubcontractorsandMaterialSuppliersshallreviewandbefamiliarwith alldrawingsassociatedwiththisprojectincludingthearchitectural,civil,structural,plumbing, mechanical,andelectricaldrawings.Specificrequirementsdepictedononedrawingpageorinone portionofthedrawingsshallbeapplicabletoalldrawingpagesandallportionsofthedrawings.Should aconflictordiscrepancybediscoveredinthedrawingsduringthebiddingornegotiationphase,the GeneralContractor,SubcontractororMaterialSuppliershallimmediatelynotifytheArchitectand requestadditionalinformationandclarification.FailuretodosowillnotrelievetheGeneralContractor, SubcontractororMaterialSupplierfromtherequirementsofallportionsofthedrawings.

MECHANICALLEGEND

DIFFUSERDESIGNATIONANDCFM

NATURALGASPIPING

CONDENSATEPIPING

MANUALVOLUMEDAMPER

MOTORIZEDDAMPER

BIPOLARIONIZATIONUNIT

THERMOSTAT

TEMPERATURESENSOR

COMBINATIONCARBONMONOXIDE NITROGENDIOXIDESENSOR

REFRIGERANTMONITORINGDEVICE R

STANDARD4-WAYBLOWSUPPLYDIFFUSER

1. THECONTRACTORSHALLFURNISHANDINSTALLALLMATERIALANDEQUIPMENTINSTRICTACCORDANCEWITHAPPLICABLECODESANDSTANDARDS,ANDPER MANUFACTURER'SDIRECTIONS.INSTALLATIONSHALLCOMPLYWITHANSI/ACCASTANDARD5.

TRANSFERGRILLE

ROOFEXHAUSTFAN (RD)RADIATIONDAMPER (FD)FIREDAMPER (SD)SMOKEDAMPER (FSD)FIRE/SMOKE DAMPER (--)FSDIF NOT NOTED

2. THEGENERALCONTRACTORANDALLSUBCONTRACTORSANDMATERIALSUPPLIERSSHALLREVIEWANDBEFAMILIARWITHALLDRAWINGSASSOCIATEDWITHTHIS PROJECTINCLUDINGTHEARCHITECTURAL,CIVIL,STRUCTURAL,PLUMBING,MECHANICAL,ANDELECTRICALDRAWINGS.SPECIFICREQUIREMENTSDEPICTEDONONE DRAWINGPAGEORINONEPORTIONOFTHEDRAWINGSSHALLBEAPPLICABLETOALLDRAWINGPAGESANDALLPORTIONSOFTHEDRAWINGS.SHOULDACONFLICT ORDISCREPANCYBEDISCOVEREDINTHEDRAWINGSDURINGTHEBIDDINGORNEGOTIATIONPHASE,THEGENERALCONTRACTOR,SUBCONTRACTORORMATERIAL SUPPLIERSHALLIMMEDIATELYNOTIFYTHEARCHITECTANDREQUESTADDITIONALINFORMATIONANDCLARIFICATION.FAILURETODOSOWILLNOTRELIEVETHE GENERALCONTRACTOR,SUBCONTRACTORORMATERIALSUPPLIERFROMTHEREQUIREMENTSOFALLPORTIONSOFTHEDRAWINGS.

AIRFLOW RETURNOREXHAUST SUPPLYAIRFLOW EXHAUSTGRILLE RETURNOR

3. THECONTRACTORSHALLSECUREANDPAYFORALLNECESSARYPERMITS,LICENSE,INSPECTIONS,APPROVALS,ANDFEES.

4.THECONTRACTORSHALLPROVIDEAWRITTENGUARANTEETHATSHALLWARRANTALLWORKMANSHIPANDMATERIALSFORONEYEARFROMDATEOFFINAL ACCEPTANCEBYTHEOWNER.ANYBREAKDOWNOCCURRINGINTHEFIRSTYEARSHALLBEATNOEXPENSETOTHEOWNER.ALLREFRIGERATIONCOMPRESSORS SHALLHAVEAFIVEYEAR(PARTSONLY)WARRANTY,ANDALLNATURALGASHEATEXCHANGERSSHALLHAVEATENYEAR(PARTSONLY)WARRANTY.

5.DRAWINGSARESCHEMATIC,NOTALLRISESANDDROPSARESHOWN.DONOTSCALEDRAWINGSFORMEASUREMENTS.DRAWINGSTHATHAVENOTRECEIVEDPERMIT APPROVALFROMAUTHORITYHAVINGJURISDICTIONSHOULDNOTBEUSEDFORFINALORGUARANTEEDPRICING.ANYPRICINGBASEDONUNAPPROVEDDRAWINGS SHOULDBENOTEDASPROVISIONAL.CONTRACTORACCEPTSALLRESPONSIBILITYFORGUARANTEEDPRICINGBASEDONUNAPPROVEDDRAWINGS.

6. WHENEXISTINGEQUIPMENTISREUSEDCONTRACTORSHALLENSUREEQUIPMENTISISGOODWORKINGORDERANDSHALLREPORTTOTHEOWNERANYREPAIRS REQUIREDTOBRINGEQUIPMENTTOGOODWORKINGORDERPRIORTOTURNOVER.

3-WAYBLOWSUPPLYDIFFUSER

LOUVEREDDOOR(SEE ARCHITECTURAL DRAWINGS) HUMIDITYSENSOR

2-WAYBLOWSUPPLYDIFFUSER

1-WAYBLOWSUPPLYDIFFUSER

LINEARDIFFUSER

ENERGYREQUIREMENTS:

1"DOORUNDERCUT

DUCTMOUNTEDSMOKE DETECTOR

CONDENSATEPUMP CD

MECHANICALSYSTEMS,SERVICESYSTEMSANDEQUIPMENT

METHODOFCOMPLIANCE

CLIMATEZONE

THERMALZONE

WINTERDRYBULB

SUMMERDRYBULB

INTERIORDESIGNCONDITIONS

WINTERDRYBULB

SUMMERDRYBULB

RELATIVEHUMIDITY

BUILDINGHEATINGLOAD(MBH)

BUILDINGCOOLINGLOAD(MBH)

MECHANICALSPACINGCONDITIONINGSYSTEM

DESCRIPTIONOFUNIT

HEATINGEFFICIENCY COOLINGEFFICIENCY

HEATOUTPUTOFUNIT

COOLINGOUTPUTOFUNIT

TOTALBOILEROUTPUT.IFOVERSIZED,STATEREASON.

TOTALCHILLEROUTPUT.IFOVERSIZED,STATEREASON.

LISTEQUIPMENTEFFICIENCIES

EQUIPMENTSCHEDULESWITHMOTORS(MECHANICALSYSTEMS)

MOTORHORSEPOWER NUMBEROFPHASES

7. TRADESARETOCOORDINATETHEIRWORKWITHALLOTHERTRADESTOAVOIDCONFLICTS.GENERALLY,DUCTWORKSHALLBEKEPTASHIGHASPOSSIBLE. MECHANICALCONTRACTORSHALLREVIEWENTIRESETOFCONTRACTDOCUMENTSINCLUDINGBUTNOTNECESSARILYLIMITEDTOALLARCHITECTURAL,STRUCTURAL, MECHANICAL,ELECTRICAL,PLUMBINGANDENTIREPROJECTMANUAL.MECHANICALCONTRACTORSHALLACKNOWLEDGEANDINCLUDEINTHESCOPEOFWORK (CONTRACT)ALLCONDITIONSPERTINENTTOTHECOMPLETIONOFTHEMECHANICALWORK.MECHANICALCONTRACTORSHALLFULLYCOORDINATEMECHANICALWORK WITHTHEINSTALLATIONOFWORKBYALLOTHERTRADESANDMAKENECESSARYFIELDADJUSTMENTSASREQUIREDTOACCOMMODATETHEMECHANICAL INSTALLATION.ALLOFTHEABOVESHALLBEINCLUDEDINTHESCOPEOFWORKATNOADDITIONALCOSTTOTHEOWNER.

8.CONTRACTORSHALLCOORDINATEELECTRICALCHARACTERISTICSANDREQUIREMENTSOFALLMECHANICALEQUIPMENTWITHELECTRICALDRAWINGSPRIORTO ORDERINGEQUIPMENTORSUBMITTINGSHOPDRAWINGSANDSHALLFURNISHEQUIPMENTWIREDFORVOLTAGESSHOWNTHEREIN.

9.CONTRACTORSHALLCOORDINATETHEINSTALLATIONOFMECHANICALEQUIPMENT,DUCTWORK,ETC.TOFITWITHINTHESPACEALLOWEDBYTHEARCHITECTURAL ANDSTRUCTURALCONDITIONS.CONTRACTORSHALLFIELDVERIFYEXISTINGCONDITIONSPRIORTOORDERINGANYEQUIPMENTORMATERIALS.ALLSUSPENDED MATERIALSANDEQUIPMENTSHALLBEINDIVIDUALLYSUPPORTEDFROMTHEBUILDINGSTRUCTURE.DONOTSUSPENDITEMSFROMTHECEILINGORITSSUPPORT SYSTEM.

10.CUTTINGOROTHERWISEALTERINGANYSTRUCTURALMEMBERSSHALLNOTBEPERMITTEDWITHOUTWRITTENPERMISSIONFROMTHESTRUCTURALENGINEEROF RECORD.

11.CONTRACTORSHALLKEEPASETOFMARKEDUPPRINTSWITHANYFIELDCHANGESMADEDURINGCONSTRUCTIONTOCREATEAN"AS-BUILT"SETOFPRINTSTOBE TURNEDOVERTOTHEOWNERATTHECOMPLETIONOFTHEPROJECT.NOTEPERENERGYCODESECTIONDESIGNSETPOINTSOFEQUIPMENTATAMAXIMUMOFNO LOWERTHAN75°INCOOLINGANDNOHIGHERTHAN72°INHEATING.

12.INTHEEVENTCONTRACTORSUBSTITUTESALTERNATEMANUFACTURERSTHENCONTRACTORSHALLCOORDINATEALLASPECTSOFSUBSTITUTEDEQUIPMENTWITH ALLTRADESINCLUDINGBUTNOTLIMITEDTOGASSERVICE,ELECTRICALSERVICE,STRUCTURALLOADSANDOPENINGS,ETC.

13.PROVIDEACCESSPANELSINCEILINGSANDWALLSTOALLOWACCESSTOVALVES,TRAPS,DAMPERS,CLEANOUTS,CONTROLS,ETC.MINIMUMACCESSSIZE12"x12", UNLESSLIMITEDBYPHYSICALCONSTRAINTS.

14.ALLCONDENSATEDRAINPIPINGSHALLBETYPEHARDDRAWNCOPPER,ASTMB-88,WITHTYPEDWVFITTINGS,ASMEB16.23,ORSCHEDULE40PVC,ASTMD1785,WITH TYPEDWVFITTINGS,ASTMD2672.COPPERDRAINPIPEANDFITTINGSSHALLBEJOINEDUSING95-5SILVERSOLDER,ANDPVCPIPEANDFITTINGSSHALLBEJOINED USINGSOLVENTCEMENT.PROVIDETRAPWITHCLEANOUTANDUNIONS.SLOPECONDENSATEDRAINLINESAMINIMUMOF1/8"PERFOOTAWAYFROMTHEMECHANICAL EQUIPMENT.PROVIDEAUXILIARYWATERLEVELMONITORINGDEVICESPERSECTION307.2.3.UNLESSOTHERWISENOTEDROUTECONDENSATEATFULLSIZEOF EQUIPMENTCONNECTIONFROMEQUIPMENTTODRYWELLORSITESTORM.INCASESWHERENEITHERISAVAILABLEDISCHARGETONEARESTMOPSINKORUTILITY SINK.PROVIDECONDENSATEPUMPASREQUIREDBYFIELDCONDITIONS.

15.SUBMITTALS: ASAMINIMUM,THECONTRACTORSHALLPROVIDESUBMITTALSFORALLITEMSSCHEDULEDONTHEDRAWINGS,UNLESSDIRECTEDOTHERWISE.

16.MECHANICALEQUIPMENTSHALLBEINSTALLEDINACCORDANCEWITHTHEMANUFACTURER'SRECOMMENDATIONS.

SEESCHEDULES

SEESCHEDULES SEESCHEDULES SEESCHEDULES SEESCHEDULES

SEESCHEDULES

17.OUTSIDEAIRFORAIRCONDITIONINGUNITSSHALLBEAMINIMUMOF10FEETFROMEXHAUSTFANS,EXHAUSTOPENINGSANDPLUMBINGVENTS.

18.ALLDUCTDIMENSIONSSHOWNAREINSIDECLEARDIMENSIONS.

19.ALLSUPPLYANDRETURNDUCTWORKSHALLBECONSTRUCTEDANDINSTALLEDINACCORDANCEWITHTHELATESTSMACNAANDASHRAESTANDARDS.DUCTWORK SHALLBEFABRICATEDOFGALVANIZEDSTEELFORAPRESSURERATINGOF(-)2"WGFORRETURNAND(+)2"WGFORSUPPLYDUCTWORK.ALLEXHAUSTDUCTWORK SHALLCONSTRUCTEDANDINSTALLEDINACCORDANCEWITHTHELATESTSMACNAANDASHRAESTANDARDS.EXHAUSTDUCTWORKSHALLBEFABRICATEDOF GALVANIZEDSTEELFORAPRESSURERATINGOF1"WGINEXCESSOFTHESYSTEMFANTOTALSTATICPRESSURERATINGATDESIGNFLOWRATE,UNLESSNOTED OTHERWISE.

20.SUPPORTDUCTWORKFROMBUILDINGSTRUCTUREINACCORDANCEWITHSMACNASTANDARDS.

MINIMUMEFFICIENCY NUMBEROFPOLES

DESIGNER'SSTATEMENT:

COMPLIESWITHTHEMECHANICALSYSTEMS,SERVICESYSTEMSANDEQUIPMENT TOTHEBESTOFMYKNOWLEDGEANDBELIEF,THEDESIGNOFTHISBUILDING

SEESCHEDULES SEESCHEDULES

REQUIRMENTSOFTHEN.C.S.ENERGYCODE.

TITLE: NAME: SIGNED: MOTORTYPE

BrandonRDillard

MechanicalEngineerP.E.

21.RADIUSEDDUCTWORKELBOWSSHALLHAVEACENTERLINERADIUSOF1.5TIMESTHEDUCTWIDTH(ORDIAMETER)UNLESSNOTEDOTHERWISE.

22.ALLMITEREDELBOWS(RECTANGULARANDROUND)SHALLHAVEDOUBLETHICKNESSTURNINGVANESINSTALLEDUNLESSNOTEDOTHERWISEONDRAWINGS.

23.SECURELYSEALALLJOINTSLONGITUDINALANDTRANSVERSESEAMSANDCONNECTIONSINDUCTWORKUSINGWELDMENTS,MECHANICALFASTENERSWITHSEALSOR GASKETSORMASTICS,MESHANDMASTICSEALINGSYSTEMSORTAPES.TAPESANDMASTICSMUSTBELISTEDANDLABELEDINACCORDANCEWITHUL181AORUL181B.

24.DUCTCONNECTIONSTOFANSANDOTHERAIRDISTRIBUTIONEQUIPMENTSHALLBEMADEUSINGMECHANICALFASTENERSWITHSEALS,MASTICSORGASKETS.ALL MECHANICALEQUIPMENTSHALLBEPROVIDEDWITHVIBRATIONISOLATIONBETWEENEQUIPMENTANDBUILDINGSTRUCTURE.

25.SUPPLYAIRANDRETURNAIRDUCTWORKSHALLBEINSULATEDWITHAMINIMUM2"THICK,3/4LB.PERCUBICFOOT,FIBERGLASSDUCTWRAP,WITHFOILFACEDVAPOR BARRIERANDANINSTALLEDTHERMALRESISTANCEOF6.0(RVALUE).ALTERNATEINSULATIONFORRECTANGULARSUPPLYANDRETURNDUCTSHALLBEANINTERIOR DUCTLININGWITHAMINIMUM1-1/2"THICK,1.5LB.PERCUBICFOOTDUCTLINER.DUCTLINERSHALLCONTAINANANTI-MICROBIALAGENTWITHINTHEDUCTLINING ITSELF.MINIMUM"R"VALUESHALLBER-6.3.INCREASEDUCTSHEETMETALSIZEASREQUIREDTOMEETINSIDECLEARDIMENSIONSGIVENONDRAWINGS.

26.ALLDUCTINSULATIONSHALLMEETTHEMINIMUMREQUIREMENTSOFU.L.181FORFLAMESPREADANDSMOKEDEVELOPMENT,ANDSHALLBEU.L.LISTED.

27.TRANSFERDUCTSSHALLBEINTERNALLYLINEDTOAIDINCANCELINGNOISETRANSFER.

28.EXHAUSTDUCTWORKSHALLBEINSULATEDUNLESSNOTEDOTHERWISE.

29.EXPOSEDDUCTWORKSHALLBEINTERNALLYLINEDANDWHENROUNDSHALLBESPIRALCONSTRUCTION.STANDINGSEAMROUNDDUCTWORKSHALLNOTBE ALLOWEDWHENVISIBLE.INTERNALINSULATIONEXPOSEDTOAIRSTREAMSHALLBECLOSEDCELLELASTOMERICMATERIAL

30.COORDINATELOCATIONSOFGRILLES,REGISTERSANDDIFFUSERSWITHARCHITECTURALREFLECTEDCEILINGPLAN.LOCATIONSSHOWNAREAPPROXIMATE,ADJUST LOCATIONSINTHEFIELDASREQUIREDBYCONSTRUCTIONCONSTRAINTS.

31.PROVIDEEACHSUPPLYAIROUTLETORDIFFUSERWITHITSOWNBALANCINGDEVICE.DEVICESCANBELOCATEDINDUCTWORKORSUPPLYAIRDEVICEITSELF.

32.ALLMANUALBALANCINGDAMPERSSHALLHAVEALOCKINGQUADRANT.

33.FLEXIBLEDUCTWORKSHALLBECLASSIFIEDUNDERUL181.PROVIDEAMINIMUMOFFEETINLENGTHANDAMAXIMUMOF10FEETINLENGTH,SUPPORTEDWITH3" GALVANIZEDSHEETMETALSTRAPSAT4FEETCENTERS(MAX).FLEXIBLEDUCTRUNOUTSSHALLBEROUNDDUCTWORKREINFORCEDWITHAWIREHELIXAND INSULATEDWITH1-1/2"THICKFIBERGLASS(WITHA6.0"R"VALUEMINIMUM)COVEREDWITHFLAMEPROOFVAPORBARRIEROFALUMINUMMETALIZEDPOLYESTERFILM LAMINATEDTOGLASSMESH.DUCTSHALLBEATCO'SUPC#036VALUFLEXCLASS1AIRDUCTOREQUAL.CONNECTIONSTODUCTMAINSSHALLBEMADEWITHFITTINGS PROVIDEDWITHTWISTRINGS,BUTTERFLYDAMPERS,LOCKINGHANDQUADRANTS,ANDINSULATIONGUARDS.

34.CONTRACTORSHALLFURNISH,ROUTE,ANDINSTALLCONTROLWIRINGFORALLMECHANICALSYSTEMS.FORSYSTEMSWITHMULTIPLECOMPONENTSCONTRACTORIS RESPONSIBLEFORALLWIRINGBETWEENCOMPONENTS.

35.INSTALLTHERMOSTATSAT4'-0"A.F.F.UNLESSNOTEDOTHERWISE.THERMOSTATLOCATIONSSHALLBECOORDINATEDWITHFINALLOCATIONSOFWALL-MOUNTED ARCHITECTURALANDELECTRICALEQUIPMENT.FINALLOCATIONSMUSTBEAPPROVEDBYTHEARCHITECTANDOWNER.THERMOSTATSSHALLNOTBEINSTALLEDON EXTERIORWALLSIFINTERIORWALLSAREAVAILABLEWITHINSPACESERVEDBYTHERMOSTAT.SHOULDTHETHERMOSTATREQUIREINSTALLATIONONANEXTERIOR WALLANINSULATEDBACKINGPLATEMUSTBEPROVIDEDTOPREVENTFALSEREADINGSBYTHETHERMOSTAT.

36.MECHANICALCONTRACTORSHALLPROVIDEACOMPLETETESTANDBALANCEREPORTOFTHEHVACSYSTEMSPREPAREDBYANINDEPENDENTTESTANDBALANCE CONTRACTOR.ACOPYOFTHETESTANDBALANCEREPORTSHALLBETRANSMITTEDTOTHELOCALCODEOFFICIALSASREQUIRED.THETESTANDBALANCEREPORT SHALLINCLUDECOILLEAVINGTEMPERATURE,OUTSIDEAIRTEMPERATURE,RETURNAIRTEMPERATURE,ANDBOTHOUTDOORANDINDOORHUMIDITYREADINGS.

37.CONTRACTORSHALLPROVIDEACOMPLETECOMMISSIONINGREPORTOFTHEHVACSYSTEMSPREPAREDBYANINDEPENDENTCOMMISSIONINGCONSULTANTAS REQUIREDBYTHEENERGYCONSERVATIONCODEINEFFECT.ACOPYOFTHECOMMISSIONINGREPORTSHALLBETRANSMITTEDTOTHELOCALCODEOFFICIALSAS REQUIRED.

38.ALLPENETRATIONSTHROUGHEXTERIORWALLS&ROOFSHALLBEFLASHED&COUNTERFLASHEDINAWATERPROOFMANNER.(COLORTOMATCHEXTERIOR).

39.CONTRACTORSHALLVERIFYLOCATIONOFALLPENETRATIONSFORRELIEFHOODS,OUTSIDEAIRHOODS,LOUVERS,ANDWALLCAPSWITHARCHITECT&OWNERPRIOR TOINSTALLATION.

40.PENETRATIONSOFRATEDWALLS,PARTITIONSANDFLOORSOFNON-COMBUSTIBLECONSTRUCTIONSHALLBEFIRESTOPPEDWITHNONCOMBUSTIBLEMATERIALS. PENETRATIONSOFNONRATEDWALLS,PARTITIONSANDFLOOROFCOMBUSTIBLECONSTRUCTIONSHALLBEFIRESTOPPEDWITHMATERIALSEQUIVALENTTOTWO INCHESOFWOOD.FIRESTOPPINGSHALLCOMPLYWITHASTME-814.CONTRACTORSHALLCOORDINATEPENETRATIONSWITHARCHITECTURALPLANSANDSHALL PROVIDEFIREDAMPERSATEVERYPENETRATIONOFARATEDWALLANDSMOKEDAMPERSWHEREARCHITECTURALRATINGSREQUIREINCLUDINGTHEPENETRATION OFCORRIDORENCLOSURES.WHEREBOTHAFIREANDSMOKEDAMPERAREREQUIREDACOMBINATIONFIRESMOKEDAMPERMAYBEPROVIDED.PROVIDERADIATION DAMPERSFORALLAIRDEVICESPENETRATINGARATEDCEILING.LISTINGOFDAMPERSSHALLMEETOREXCEEDRATINGOFASSEMBLYWHEREINSTALLED.

41.REFRIGERANTPIPING,NOTSHOWNONPLANS,SHALLBESIZED&INSTALLEDINACCORDANCEWITHTHEMANUFACTURER'SRECOMMENDATIONS,INSTALLATION INSTRUCTIONSANDLOCALCODES.

42.KITCHENHOODEXHAUSTDUCTSHALLBE16GAUGECARBONSTEELOFFACTORYFABRICATEDSTAINLESSSTEEL.ALLJOINTSANDSEAMSSHALLBECONSTRUCTED WITHACONTINUOUSLIQUID-TIGHTEXTERNALWELD.ALLDUCTWORKSHALLBEINSTALLEDPERSECTION506OFTHEMECHANICALCODE.PROVIDECLEANOUTSAT EVERYCHANGEOFDIRECTIONINTHEEXHAUSTDUCTANDPERSPACINGREQUIREMENTSINDICATEDINSECTION506.

43.CONTRACTORSHALLPREPAREALLEXPOSEDDUCT,GRILLES,PIPING,ANDUNITSFORPAINTING.GCWILLBERESPONSIBLEFORPAINTING.

44.AIRHANDLERSWITHAIRFLOWSGREATERTHANOREQUALTO2000CFMORTHATSHAREACOMMONOUTSIDEAIRORRETURNDUCTSHALLBEFURNISHEDWITHSMOKE DETECTORSLOCATEDINTHESUPPLYANDRETURNSECTIONSFORALLUNITS.

EVAPORATORFORCOOLER/FREEZERCOORDINATE EXACTLOCATIONWITHEQUIPMENTSUPPLIER.REFER TOFOODSERVICEDRAWINGS. 4

COORDINATEEXACTLOCATIONOFFREEZER/COOLER CONDENSERWITHFIELDCONDITIONS.PROVIDE GUARDSASREQUIREDBYNCMC304.11. 5

ROUTEEVAPORATORCONDENSATETOMOPSINKOR NEARESTFLOORDRAINOUTSIDEOFFREEZER/ COOLER. 6

EXISTINGCHASELOCATION.COORDINATEROUTING OFDUCTWORKWITHFIELDCONDITIONS. 7

EQUIPMENTOFROOFSHALLBECOORDINATEDWITH LLANDFIELDCONDITIONS. 8

DUCTWORKSHALLBECOORDINATEDWITHLLAND FIELDCONDITIONSTOMAINTAINCLEARHEIGHTS. 9

GALVANIZEDALL-THREAD HANGERRODATMAXIMUM SPACINGOF10'-0"ON CENTER(PROVIDEAMINIMUM OFHANGERSPERSECTION OFDUCT).PROVIDELOCK NUTSATDUCTANDSECURE TOSTRUCTURE.

GALVANIZEDALL-THREAD HANGERRODATAMAXIMUM SPACINGOF10'-0"ON CENTER(PROVIDEAMINIMUM

3.CONTRACTORSHALLPROVIDEDDUCTWITHAPAINTGRIPFINISH.

KITCHENEXHAUSTDUCTTOBECONSTRUCTEDOF 16GAUGEBLACKIRONW/CONTINUOUSEXTERNAL LIQUID-TIGHTWELDS

OFFSETSWITHMINIMUM6"INNERRADIUS PROVIDECLEAN-OUTSPERCODE.

WRAPENTIREDUCTW/UL"FIREMASTER"BYTHERMAL CERAMICS,FROMHOODEXHAUSTTOFANDISCHARGE WHEREREQ'D.FORCLEARANCESPERCODE.

DUCTWRAPTOBEINSTALLEDPERMFGR'S REQUIREMENTSANDULCLASSIFICATION ANDTESTS.

GCTOSPACESTRUCTURETOACCOMMODATEDUCTSW/ WRAPASREQ'D.(MIN18"CLEARTOCOMBUSTIBLES)& PROVIDERATEDCHASEW/RATEDACCESSDOORAS REQ'D.

PROVIDE/PROTECTCLEAN-OUTSPERMFGR'SAND U.L.REQUIREMENTS.

PROVIDEWITHFACTORYPRE-WIREDMOTOR CONTROLPACKAGE.

INSTALLHOODATHEIGHTPERCODE&W/ GREASEFILTERS3.5'ABOVECOOKINGSURFACE W/OPENFLAME,PERCODE.

HOODCAPTURESIZEBASEDUPONEQUIP.SCHEDULED TOBEUNDERHOODPLUSMIN.6"ONALLEXPOSED SIDESPERCODE.FIELDVERIFY/COORD.HOODSIZE& FANSCAPACITIESW/ACTUALEQUIP.FURNISHED.

EXACTHOOD-DUCTCONNECTION&TRANSITIONSIZES SHALLBEFULLYCOORD.W/HOODMFG.PRIORTO FABRICATION MAKE-UPAIRFANTOSHUTDOWNUPONDETECTIONOF FIRESUPPRESSIONSYSTEM.

WITHMAX.PULLPRESSUREOF40LBS.ANDMAX.PULL MOVEMENTOF14".

EXHAUSTFANMUSTOPERATECONTINUOUSLYWHILE EXHAUSTINGAIRAT400°F(204°C)UNTILALLFAN

EXHAUSTFANMUSTOPERATECONTINUOUSLYWHILE EXHAUSTINGBURNINGGREASEVAPORSAT600°F (315°C)FORAPERIODOF15MINUTESWITHOUTTHE FANBECOMINGDAMAGEDTOANYEXTENTTHAT COULDCAUSEANUNSAFECONDITION.

U.L.LISTEDHOODEXHAUSTFANSEE SCHEDULEFORSPECIFICATION.

SEALOPENINGAROUND DUCTWITHKAOWOOL.

STEELANGLE BOLTEDTOTRUSS (TYP0F2)

1/2"STEELHANGING RODS(TYPOF6)

12x12ACCESSDOOR FORCLEANOUT

STEELHANGING ANGLE

WELDEDEXH. CONNECTIONTOHOOD EXHAUSTRISER

PROVIDEAPRE-ENGINEERED,WETCHEMICAL,CARTRIDGEOPERATEDTYPEFIRESUPPRESSION SYSTEM.ITSHALLBEAFIXEDNOZZLEAGENTDISTRIBUTIONNETWORK,ANDSHALLBEUL LISTED.THESYSTEMSHALLBECAPABLEOFAUTOMATICDETECTIONANDREMOTEACTUATION. THESYSTEMSHALLBEINACCORDANCEWITHNFPA96ANDAUTHORITYHAVINGJURISDICTION. DISCHARGENOZZLESWILLPROVIDECOVERAGEOF,BUTNOTLIMITEDTO,THEHOODAREAAND EXHAUSTDUCT.FURNISHELECTRICOPERATEDSHUTOFFVALVE.THESYSTEMSHALLBEAN ANSULMODELR-102ORAPPROVEDEQUAL.

U.L.LISTEDHOODMAKE-UPAIRFAN SEESCHEDULEFORSPECIFICATION.

PAINTALLFLASHINGAND EXTERNALMECHANICAL COMPONENTS,COLORAS SPECIFIEDBYARCHITECT.

INSULATECOMBUSTIBLES NEAREXHAUSTDUCTAS REQUIREDBYLOCALCODE

16"U.LLISTED BAFFLETYPE GREASEFILTERS

GREASEDRAINWITH REMOVABLECUP 100WATTU.L.LISTED INCANDESCENTLIGHT FIXTUREWITHPREWIRED J-BOXESBULBSBYMC. KITCHENEXHAUSTHOODWITHWETCHEMICALFIRE SUPPRESSIONSYSTEM.PROVIDECONTACTFOR SHUT-OFFOFGASANDELECT.POWERSOURCESTO KITCHENEQUIPMENT,ANDSUPPLYFANSHUT-DOWN INTHEEVENTOFAFIRE.(GASSOLENOIDVALVEBY OTHERS)

STAINLESSSTEELPANELTOFLOOR BYOTHERS.SEEARCH.DRAWINGS.

FACTORYFIRESYSTEMCONTROLBOXTOBE MOUNTEDWITHIN75FEETOFHOODAND BELOWCEILINGLEVEL.CABINETMAYBE INCLUDEDINCONTROLPANELATTACHEDTO ENDOFHOOD.

REMOTEPULLSTATION.

NOTE:ADDITIONALSTRUCTURALBRACING FORHOODSUPPORTPROVIDEDBYOTHERS. SEEARCHITECTURALDRAWINGSFORMORE INFORMATION.

TWOLAYERINSTALLATION(GreaseDuctperASTME2336)

SINGLELAYERINSTALLATIONOPTIONS(HVACDuctorGreaseDuctperUL1978)

TwoLayersofXLInsulationforASTME2336GreaseDuctEnclosures

OneLayerofXLInsulationforAirVentilationDuctEnclosuresandUL1978ZeroClearance

Tightbuttjoints(ULCGreaseDuctrequires3"(75)overlap) Min.3"(75)overlaponperimeterandbetweenadjacentblankets

FLOORDRAIN

PLUMBINGFIXTURESPECIFICATIONSANDCONNECTIONSCHEDULE

FIXTURE:AMERICANSTANDARDMADERAFLOWISEMODEL3461.001.020,WHITE,UNIVERSALFLUSH,ELONGATEDBOWL,SIPHONJETFLUSHACTION,1-1/2"TOPSPUD,EVERCLEANSURFACE. FLUSHVALVE:SLOANG2OPTIMAPLUSMODEL8111-1.28-LH,BATTERYPOWEREDSENSOROPERATED,EXPOSEDDIAPHRAGMTYPE,1.28GALLONSPERFLUSH,WITHOVERRIDE,LESSHANDLEOPENINGSEAT:BEMISMODEL3155SSCT EXTRAHEAVYWEIGHT,SOLIDPLASTIC,OPENFRONT,ELONGATED,LESSCOVER,STAINLESSSTEELSELF-SUSTAININGCHECKHINGES,STA-TITEFASTENINGSYSTEM,ANTIMICROBIAL.

FIXTURE:AMERICANSTANDARDWASHBROOKFLOWISEMODEL6590.001.020,WHITE,UNIVERSALFLUSH,WASHOUTFLUSHINGACTION,3/4"TOPSPUD. FLUSHVALVE:SLOANG2OPTIMAPLUSMODEL8186-0.5,BATTERYPOWEREDSENSOROPERATED,EXPOSEDDIAPHRAGMTYPE,0.5GALLONSPERFLUSH,WITHMANUALOVERRIDE.. CARRIER:ZURNZ1222SERIESWALLURINALSUPPORTSYSTEMWITHTOPANDBOTTOMSUPPORTPLATES.

FIXTURE:OWNER/INTERIORDESIGNERSELECTED. FAUCET:OWNER/INTERIORDESIGNERSELECTED,ASSE1070THERMOSTATICTEMPERATURELIMITERSETAT110°F. DRAIN:McGUIREMODEL155A,POLISHEDCHROMEPLATEDCASTBRASSOPENGRIDDRAIN,WITH1-1/4"6"17GAUGECHROMEPLATEDBRASSTAILPIECE. TRAP:McGUIREMODEL8902C,1-1/4"1-1/2"17GAUGECHROMEPLATEDCASTBRASSP-TRAP,WITHCLEANOUTPLUG.

SUPPLIES:McGUIREMODELLF2165,CHROMEPLATEDBRASSANGLESUPPLYSTOPSWITHBRASSSTEMS,WHEELHANDLES,1/2"IPSINLETS,3/8"COMPRESSIONOUTLETS,12"CHROMEPLATEDFLEXIBLESUPPLYRISERS. INCLUDETRUEBROLAVGUARD2MODEL#102E-ZUNDERSINKPIPINGCOVERS,WITHP-TRAPCOVER,ANDTWOANGLEVALVEANDSUPPLYCOVERS.

FIXTURE:FIATMODELTSB3002,12"DEEPWITH6"DROPFRONT,STAINLESSSTEELCAPSONALLCURBS,STAINLESSSTEELFACTORYINSTALLEDDRAINBODYWITHFLATSTAINLESSSTEELSTRAINER. FAUCET:PRIERMODELC-108DFREEZELESSWALLFAUCET,ANTI-SIPHON,CASTBRASSHOT&COLDHYDRANT,SATINNICKELFINISH,1/2"INLETS,3/4"HOSETHREADOUTLET,METALWHEELHANDLES,SELFDRAINING,WITHINTEGRAL VACUUMBREAKERANDBACKFLOWCHECKVALVE.

ADDITIONALEQUIPMENT:PROVIDEFIATMODEL889CCMOPBRACKET,MODEL832AAHOSEANDBRACKET,ANDMODELMSG3636STAINLESSSTEELWALLGUARDPANELS.

CASTIRONBODY,MEMBRANECLAMP,ADJUSTABLECOLLAR,6"DIAMETER"TYPEB"POLISHEDNICKELBRONZE STRAINER,1/2"TRAPPRIMERCONNECTION.TRAPSEALSSUBJECTTOEVAPORATIONSHALLBEPROTECTEDBYONE OFTHEMETHODSINSECTION1002.4.1.1THROUGH1002.4.1.4OFTHE2018NCPC.

12"x12"x8"DEEPCASTIRONBODYWITHWHITEACIDRESISTINGPORCELAINENAMELINTERIOR,ANCHORFLANGE WITHSEEPAGEHOLESANDCLAMPCOLLAR,NICKELBRONZEFRAMEWITH1/2GRATE. ZURNZN1901-KC-2

FCO ZURNZN1400-BP ADJUSTABLE,COATEDCASTIRONBODY,ROUNDSCORIATEDNICKELBRONZETOP,BRONZEPLUG. FLOORCLEANOUT

GASHEADERALONGWALL BEHINDEQUIPMENT,REFER TOFLOORPLANSFORSIZE.

GASCONNECTIONONEQUIPMENT, VERIFYSIZEANDLOCATIONWITH KITCHENEQUIPMENTSUPPLIER

GASQUICKCONNECTFITTING

WALLCLEANOUT

WCO ZURNZ1446-BP CASTIRONNO-HUBCLEANOUTTEE,WITHROUNDSTAINLESSSTEELWALLACCESSCOVER,BRONZEPLUG,SECURING SCREW.

DWH DOMESTICWATERHEATER

THERMOSTATICMIXINGVALVE

AOSMITHMODELBTH-199 COMMERCIALGAS-FIRED,CONDENSING,DIRECTVENT,100GALLONCAPACITY,199MBHINPUT,261GPHAT90F TEMPERATURERISE,GLASS-LINEDSTEELTANK,WITHFACTORYINSTALLEDT&PRELIEFVALVEANDDRAINVALVE.

AMTROLTHERM-X-TROL MODELST-12-C ASMECONSTRUCTION,STEELTANKWITHFIXEDDIAPHRAGM,STAINLESSSTEELSYSTEMCONNECTION,55PSI PRECHARGE,150PSIWORKINGPRESSURE,6.4GALLONS.

LEONARDLF-170 ASSE1070-2015CSAB125.70-15CERTIFIED.15ANCAC18A.2526(A-M)

DOUBLECHECKWITH INTERMEDIATEATMOSPHERICVENTWATTSLF9D DC DUALCHECKVALVEWITHATMOSPHERICVENTBACKFLOWPREVENTERFORSMALLSUPPLYLINESAND IDEALLYSUITEDFORICEMAKERS,STEAMERS,LABORATORYEQUIPMENT,PROCESSINGTANKS, STERILIZERS,DAIRYEQUIPMENT,ANDOTHERSIMILARAPPLICATIONS.

SECUREHEADERTO WALLWITHPIPECLAMPS

SLEEVETHROUGHFLOORSLAB

GREASETRAP

SCHIERGB-50&PP3PUMPOUT PORTKITFORREMOTE GREASEREMOVAL GT

GREASEINTERCEPTOR50GPM,GREASECAPACITY439.5LBS.,4"INLET/OUTLET,PEDESTRIANRATEDCOMPOSITE COVERS.THIRDPARTYPERFORMANCE-TESTEDANDLISTEDBYIAMPOTOASME#112.14.3ANDCSAB48.1GREASE INTERCEPTORSTANDARDSANDGREATLYEXCEEDREQUIREMENTSFORGREASESEPARATIONANDSTORAGE.THEY ARECOMPLINATTOTHEUNIFORMPLUMBINGCODEANDTHEINTERNATIONALPLUMBINGCODE.

FINISHEDFLOOR

SLOPE@MIN1%TODRAIN

TRAPPRIMERINSTALLATIONNOTES:

1.PROVIDETRAPPRIMERVALVESFORALL FLOORDRAINSANDHUBDRAINS,EXCEPT SHOWERDRAINS.

2.TRAPPRIMERVALVESSHALLBESIOUXCHIEF PRIMEPERFECTSERIES695,OREQUAL.

3.CONNECTTRAPPRIMERVALVETOCWLINE: 1/2"MIN.3"MAX.

4.PROVIDESIOUXCHIEFWYESPLITTERAND/OR DISTRIBUTORFORTRAPPRIMERVALVES SERVINGMORETHANONEFLOORDRAIN. 5.MAXIMUMOFEIGHTFLOORDRAINSMAYBE SERVEDBYONETRAPPRIMERVALVE.

TRAPPRIMERDETAIL 8

NOTTOSCALE

GENERALNOTESTHISSHEET

1.SEEFIXTURESCHEDULEONSHEETP002FORSIZESOF SANITARYWASTEANDVENTCONNECTIONSTO INDIVIDUALFIXTURES.

2.MINIMUMSIZEFORSANITARYWASTEANDVENTPIPING BELOWGROUNDSHALLBE2".

3.ALLSANITARYVENTPIPINGSHOWNONTHISSHEET SHALLBERUNABOVECEILINGSINAREASWITH CEILINGSANDSHALLBERUNASHIGHASPOSSIBLEIN AREASWITHOUTCEILINGS,UNLESSOTHERWISE NOTED;ALLSANITARYWASTEPIPINGSHOWNONTHIS SHEETSHALLBERUNBELOWFLOORS,UNLESS OTHERWISENOTED.

4.COORDINATION:VERIFYALLROUGH-INLOCATIONS ANDCOORDINATEPIPINGANDEQUIPMENTLOCATIONS WITHWORKUNDEROTHERDIVISIONSOFTHE SPECIFICATIONSTOAVOIDCONFLICTS.CONTRACTOR MUSTCOORDINATEWITHOTHERTRADESFORALL STRUCTURES,PIPING,CONDUIT,DUCTWORK, LIGHTING,ETCTOPROPERLYBEINSTALLED.ANY CONFLICTSSHALLBERESOLVEDATNOEXPENSETO THEOWNER.PIPINGSHOWNONTHESEDRAWINGSTO BEUSEDFORPIPESIZESANDGENERALPIPE ROUTING.ACTUALROUTINGOFPIPINGMAYVARY DEPENDINGONFIELDCONDITIONS.PRIORTO SUBMITTINGABID,THECOSTOFANYADDITIONAL PIPE,FITTINGS,OFFSETS,ETC.SHALLBEINCLUDEDIN THEPRICE.NOADDITIONALCOMPENSATIONWILLBE ALLOWEDFORFAILURETODOSO.

KEYEDNOTESTHISSHEET

CONNECTNEW4"SANITARYWASTEPIPINGTO EXISTING4"SANITARYWASTEPIPINGINTHISAREA. VERIFYEXACTLOCATION,SIZE,INVERT,AND DIRECTIONOFFLOWOFEXISTINGPIPINGINFIELD.

CONNECTNEW3"SANITARYVENTPIPINGTO EXISTING3"ORGREATERSANITARYVENTPIPINGIN THISAREA.VERIFYEXACTLOCATION,SIZE,INVERT, ANDDIRECTIONOFFLOWOFEXISTINGPIPINGIN FIELD.

CONNECTNEW4"GREASEWASTEPIPINGTO EXISTING4"GREASEWASTEPIPINGINTHISAREA. THISPIPINGCONNECTSTOTHEEXISTINGCENTER 3000GALLONCAPACITYGREASEINTERCEPTORS INSTALLEDINLINESHOWNON1415SCHURCH STREETINPARKINGGARAGEP.101AMECKLENBURG COUNTYRTAPDATED09-01-2023.VERIFYEXACT LOCATION,SIZE,INVERT,ANDDIRECTIONOFFLOW OFEXISTINGPIPINGINFIELD. 1 2 4

PROVIDEHOBARTGLASSWASHER&NOBLE GLASSWASHERMANUFACTURERSUPPLIEDHOT WATERWASTEMIXINGVALVETOTEMPERWASTE WATERTONOTEXCEED140°.

PLUMBINGCONTRACTORTOVERIFYGREASE INTERCEPTORLOCATIONANDTOMEETTHEDESIGN STANDARDSLOPETOKEEPSOLIDSSUSPENDEDIN LONGRUNSTOTHEGREASEINTERCEPTOR,PER MECKLENBURGCOUNTYPLUMBINGCODE ENFORCEMENT.EFFECTIVEDATESEPTEMBER30, 2012.

INSTALLEDPER2018NCPCSECTION709.4.1CLEAR WATERWASTERECEPTORS:WHEREWASTE RECEPTORSSUCHASFLOORDRAINS,FLOORSINKS, ANDHUBDRAINSRECEIVEONLYCLEAR-WATER WASTEFROMDISPLAYCASES,REFRIGERATED DISPLAYCASES,ICEBINS,COOLERS,AND FREEZERS,SUCHRECEPTORSSHALLHAVEA DRAINAGEFIXTUREUNITVALUEOFONE-HALF.

GENERALNOTESTHISSHEET

1.SEEFIXTURESCHEDULEONSHEETP002FORSIZESOF DOMESTICWATERCONNECTIONSTOINDIVIDUAL FIXTURES.

2.COORDINATEALLCONNECTIONREQUIREMENTSFOR KITCHENEQUIPMENTWITHFOODSERVICEEQUIPMENT SUPPLIER.DOMESTICWATERCONNECTIONSTO INDIVIDUALKITCHENSINKSOREQUIPMENTSHALLBE 1/2",UNLESSOTHERWISENOTED.

3.ALLDOMESTICWATERPIPINGSHOWNONTHISSHEET SHALLBERUNABOVECEILINGSINAREASWITH CEILINGSANDSHALLBERUNASHIGHASPOSSIBLEIN AREASWITHOUTCEILINGS,UNLESSOTHERWISE NOTED.

4.PROVIDETMVBELOWALLHANDSINKSANDLAVATORY SINKSTOTEMPERWATERTO110°FMAX.

KEYEDNOTESTHISSHEET

CONNECTNEW2"CWPIPINGTOEXISTING2"CW PIPINGVALVEINTHISAREA.VERIFYEXACT LOCATIONANDSIZEOFEXISTINGPIPINGINFIELD. SEEWATERHEATERDETAILONP002FORPIPING ARRANGEMENTS.

GENERALNOTESTHISSHEET

1.THEGASHASBEENDESIGNEDUSINGTHELONGEST LENGTHMETHODWITHTHEFOLLOWINGCRITERIA: GASTYPE:NATURALGAS INLETPRESSURE:2.0PSI PRESSUREDROP:1.0PSI SPECIFICGRAVITY0.60 SYSTEMLENGTH:400FT. TOTALLOAD:816MBH(1MBH=1CFH) SIZINGTABLE:2018NCFGC,TABLE402.4(5)

2.GASHEADERBEHINDCOOKLINEHASBEENDESIGNED USINGTHELONGESTLENGTHMETHODWITHTHE FOLLOWINGCRITERIA: GASTYPE:NATURALGAS INLETPRESSURE:LESSTHAN2.0PSI PRESSUREDROP:6.0IN.WC SPECIFICGRAVITY0.60 SYSTEMLENGTH:20FT.

TOTALLOAD:617MBH(1MBH=1CFH) SIZINGTABLE:2018NCFGC,TABLE402.4(2)

3.ALLGASEQUIPMENTMUSTHAVEAGASRATEDBALL VALVEANDWHERETHEPRESSUREISGREATERTHAN 0.5PSIITSHALLHAVEAGASPRESSUREREGULATOR VENTEDPERTHENCFGCODE.

CONNECTNEW1-1/4"GASPIPINGAT2PSITO EXISTING2"GASPIPINGTOTENANTSPACEFROM BUILDINGSUPPLIEDGASMETER.SEEINSTALLED GASMETERLOCATIONSSHOWNONCAMPNORTH ENDBUILDINGP.102AMECKLENBURGCOUNTY APPROVEDPLANSDATED03-12-2021 1-1/4"GASPIPINGDOWNTOGASSOLENOID SHUT-OFFVALVE(INTERLOCKEDWITHHOODFIRE SUPPRESSIONSYSTEM),PROVIDEDBYPLUMBING CONTRACTOR,ONWALLBELOWCEILING.REFERTO FOODSERVICEDRAWINGSFORGASCONNECTIONS TOEQUIPMENTANDACCESSIBLESHUTOFFVALVE. GASTURNDOWNTOBECOORDINATEDTOBE BETWEENEQUIPMENTSOTHATFOODWARMERS CANBEAGAINSTWALL.PROVIDEGASPRESSURE REGULATOR.ROUTE1-1/4"GASHEADERFROM REGULATORALONGWALLBEHINDEQUIPMENTAT 18"AFF.ROUTEALLGASPIPINGSOASNOTTO INTERFEREWITHOTHEREQUIPMENTANDKEEP PIPINGASTIGHTTOWALLASPOSSIBLE.

CONNECT3/4"GASPIPINGFROMHEADERTO FRYER,150MBHINPUT.

CONNECT3/4"GASPIPINGFROMHEADERTO CHARBROILER,102MBHINPUT.

CONNECT3/4"GASPIPINGFROMHEADERTOGAS RANGE,215MBHINPUT.

INSTALLERTOFOLLOWAOSMITHVENTANDAIR INTAKESYSTEMINSTALLATIONMANUALFOR CORRECTMEANSANDMETHODSTOROUTE EXHAUSTANDPROVIDECOMBUSTIONAIRINTAKE TOMEETALLMECHANICALANDPLUMBINGCODE REQUIREMENTS.

SIZEDPER2018NCFGTABLE402.4(5)
