Wesco Renewables Guide 2025

Renewables Guide

9th Edition

Welcome!

I’m excited to share the 9th edition of the Wesco Renewables Guide—a trusted resource created to help our customers and strategic supplier partners navigate the ever-evolving solar landscape.

As the renewable energy industry continues to grow and transform, Wesco remains a committed leader—delivering advanced, scalable solutions across residential, commercial, and utility-scale solar applications. This year’s guide goes beyond the essentials, spotlighting our latest innovations in string collection solutions and utility-scale solar capabilities—two rapidly expanding areas that are key to improving efficiency, lowering installation costs, and maximizing performance at scale.

Inside, you’ll find a comprehensive portfolio of renewable energy solutions, including photovoltaic modules, inverters, racking systems, battery storage, balance of system components, and more. Backed by our experienced technical team and global distribution network, Wesco is your go-to partner for solar success— whether you’re installing a rooftop system or deploying a utility-scale array.

We recognize that the solar industry faces both exciting opportunities and complex challenges—from shifting regulations and evolving incentive programs to ongoing supply chain dynamics. At Wesco, we’re here to help you stay informed and resilient by providing the expertise, resources, and solutions you need to thrive.

Sustainability remains a core pillar of our business strategy. We’re actively working to reduce our environmental footprint while empowering our partners to achieve their own sustainability goals. Our 2030 targets include:

• 30% reduction in greenhouse gas emissions

• 15% reduction in landfill waste intensity across U.S. and Canadian sites

• 15% reduction in total recordable safety incidents

You can learn more in our latest Sustainability Report at Wesco.com

As we look ahead, innovation continues to drive our mission to build, connect, power, and protect the world. Thank you for your continued partnership in renewable energy—and for choosing Wesco as your trusted advisor and supplier.

When you think solar, think Wesco.

Kind regards,

Nelson Squires Executive Vice President & General Manager - EES

Ingenuity Delivered.

We strive to provide the top level support needed to make your next solar project a complete success.

The U.S. solar market continues to experience unprecedented growth. According to the 2024 Solar Market Insight Year in Review from SEIA and Wood Mackenzie, solar PV accounted for 66% of all new electricity-generating capacity added to the U.S. grid in 2024, up from 45% in 2022. The industry installed nearly 50 GWdc of new capacity, marking a 21% increase over 2023 and the second consecutive year of record-breaking growth.

This momentum is fueled in part by the Inflation Reduction Act (IRA), which has catalyzed over $100 billion in private-sector investments and is projected to drive 48% more solar deployment over the next decade compared to a noIRA scenario. Domestic solar manufacturing has also surged, with U.S. module production capacity tripling in 2024 alone.

Energy storage is rapidly scaling alongside solar. In 2024, the U.S. deployed 12.3 GW / 37.1 GWh of energy storage, a 33% increase over 2023. Residential storage grew by 57%, and utility-scale storage is expected to reach 13.3 GW in 2025, supporting grid reliability and renewable integration.

At Wesco, we recognize the scale and significance of this transformation. To support our customers and the evolving solar landscape, we’ve established a Solar Center of Excellence (COE)—a centralized hub of seasoned experts offering technical, operational, and strategic support across the full project lifecycle. Our COE is equipped to support residential, commercial/industrial, and utility-scale projects, ensuring seamless execution and long-term success.

WESCO participates in the Solar Energy Industries Association (SEIA) at the national level, as well as in the Hawaii, California, Colorado, Oregon, Utah, Florida, MDV (Maryland, Delaware, Virginia) and Nevada chapters.

Solar Focus Branches

Wesco Branches

Wesco Distribution Centers

String Harness and Combiner Manufacturing Locations

Serving a Wide Range of Markets

Whether your focus is Residential, Commercial or Utility Scale Solar, Wesco Renewables has the products, solutions and expertise to improve your productivity and reduce operating costs.

Residential

• Modules, racking, inverters and storage

• Electrical Balance of Systems

• National Support, Branch-level customer focus

• Financing programs and solutions

• Nationally scalable project kitting solutions

Commercial

• Modules, racking, inverters and storage

• Large and small electrical Balance of Systems

• Controlled Product delivery and staging

• Applications engineer support to customer design team

Broad Product

Utility Scale

• Wire and wire management solutions

• Medium voltage

• On-site storage and material management

• Customized electrical assembly production and procurement options

• Established and comprehensive electrical supplier network

String collection

• Combiner boxes

• Load Break Disconnects

• Harness to combiner solutions

Wesco...Helping You Excel at Project Execution

Whether you are installing solar in a residential, commercial or large-scale application, Wesco has solutions to help you come in on-time and on-budget.

Project Execution Solutions

We can help with your construction projects with our unique project execution services and solutions to improve your productivity and reduce operating costs. Our renewables experts provide in-depth information and technical support for installers and end-users.

Save time, reduce cost and mitigate risk through these solar project execution services:

• Cable management

• Design services group

• Digital procurement

• eStock

• Kitting

• On-site job trailers

• Safety

• Storeroom management

• Vendor-managed inventory (VMI)

Solar Product and Technologies

At Wesco, we partner with the world’s industry-leading providers of sustainability products and solutions, including manufacturers of solar photovoltaic modules, inverters, racking, balance of systems (BOS) and energy storage. Our strong partnerships combined with our expansive distribution network ensure you have the right products when you need them to quickly scale to meet the demands of the marketplace.

e-Business Solutions

Wesco offers a broad range of e-Business Solutions, including customerspecific e-Catalogs, buy.wesco.com online ordering system, e-Stock web-based inventory management and procurement system, Point-of-Use Systems and integration of buy.wesco.com with your procurement system.

Extra-Effort Service — That is the Wesco difference. Whether you call or visit one of our branches, you will find the electrical and general MRO products you need — fast and ready to ship.

Wesco’s Renewable Energy Supplier Partners

Vendor Managed Inventory

Wesco’s materials management services are designed to improve productivity and lower total cost of ownership.

Supply chain disruptions, labor shortages and supply handling costs have become prohibitive and distract from your operation’s strategic priorities. No matter the dynamics of your specific needs, Wesco can tailor a vendor managed inventory (VMI) solution that works in step with your facility’s operations. We’ll help you optimize just-in-time materials management and improve your visibility and control on tail spend. The goal is to avoid costly downtime and improve your balance sheet by maintaining optimal direct and indirect materials inventory.

Optimizing Your Supply Chain with Smarter Inventory Management

With Wesco’s VMI solution, you’ll get the right parts and supplies when you need them. Our highly skilled team of inventory management experts will design and implement a world-class solution that leverages the robust capabilities of Wesco’s sourcing and procurement capabilities. Whether you have your own proprietary enterprise resource planning (ERP) system or need a fully tailored solution, Wesco’s VMI solution can be designed to fit with nearly any system or process.

We offer a complete suite of supply chain and project deployment services to optimize your inventory.

• Just-in-time delivery

• Replenishment programs

• Storeroom management

• Tail spend management

• Digital tools and resources

• Vending services

• Mobile truck stock services

• Job trailer and temporary projects management

• Pick tickets and asset transfers

Effectively Manage Your Critical Inventory with eStock

A dynamic digital solution providing vision across the parts and inventory that keeps your business up and running smoothly

Powerful Software to Manage What Matters

Labor, delivery and procurement challenges impact every business in different ways. Wesco’s eStock platform is a robust inventory management system designed with one goal in mind: keeping your business running smoothly and profitably.

eStock: Powering Progress for Tomorrow

• Access your storeroom multiple ways

• Flexible design can be implemented to support and enhance your current inventory management process or as part of a Wesco designed vendor-managed inventory (VMI) solution

• Off-line mode available

• Web-and app-based software designed to deliver full visibility into the flow and replenishment of your critical inventory - iOS and Android compatible

Innovative Features

• Automated and customizable reporting

• Asset management

• Checkout software

• Checkout items to job/allocation codes

• Cost savings analysis

• Dynamic reporting capabilities

• Inventory/asset control

• Inventory analysis and optimization via machine learning

• Multi-location tracking and traceability

• Over 300 features

• Portals and dashboards

• Print scannable labels

Wesco at a Glance

Wesco International (NYSE: WCC) builds, connects, powers, and protects the world. Headquartered in Pittsburgh, Pennsylvania, Wesco is a FORTUNE 500® company with more than $22 billion in annual sales and a leading provider of business-to-business distribution, logistics services, and supply chain solutions.

Wesco offers a best-in-class product and services portfolio of Electrical and Electronic Solutions, Communications and Security Solutions, and Utility and Broadband Solutions. The Company employs approximately 20,000 people and partners with more than 50,000 of the industry’s premier suppliers to serve 150,000 customers around the world.

With millions of products, end-to-end supply chain services, and leading digital capabilities, Wesco provides innovative solutions to meet customer needs. Wesco operates approximately 800 branches, warehouses, and sales offices in more than 50 countries, providing a local presence for customers and a global network to serve multi-location businesses and multi-national corporations.

In June 2020, Anixter International became a wholly owned subsidiary of Wesco. The combined company is the largest MRO distributor in North America. We have 100 years of ingenuity and a solid record of strong financial results.

We embrace this opportunity to share best practices and explore ways to build an enriching relationship with Sunrun built upon a foundation of trust, service excellence, and industry expertise.

Renewables Guide

Modules and Racking

JayBox® Junction Box

An Ever-Adaptable Junction Box.

Securely enclose wires on nearly any solar project. Is UL-Listed, NEMA-3R-rated, supports up to 1500-volt system and is made of a NORYL™ resin. Available in Roof Mount and Rail Mount.

• Multiple configuration options

• Wind-driven, rain-tested

• Ambient operating conditions — 40º C to 75º C

Jaybox, Roof Mounted (comp/asphalt shingle) — QM-JBX-RF02-B1

Lid, J-Box

J-Box

J-Box

Jaybox, Rail Mounted — QM-JBX-RL02-B1

Rail-Hanger, J-Box

QM, Lid, J-Box

#8 X .750", SS

J-Box

x 3/8"

JayBox Top

JayBox Inside

JayBox Bottom Seal

Contour™ Solar Array Trim

Elevate Any Solar Array.

A sleek trim (or skirt) that contours across the south edge or around the perimeter to hide components that are visible beneath the solar panels. Contour™ will make any array look great and have your crew on and off the roof in a snap.

Wesco Part No.

400042-99915

CTR-OUT-01-B1 Contour Corner Cap, Outer 400042-99914

CTR-IN-01-B1 Contour Corner Cap, Inside 400042-99918

CTR-CL-01-B1 Contour Clamp 400042-99917

CTR-SPLC-01-M1 Contour Splice 400042-99919

CTR-TR84-01-B1 Contour Trim, 84 400042-99916

CTR-CAP-01-B1 Contour End Caps (L-R pair)

Contour™ Solar Array Trim

Contour Inside Corner Cap

Contour Outer Corner Cap

Contour End Caps (L-R pair)

Contour Clamp, Outside (CTR-CL-01-B1)

Contour Clamp, Inside (CTR-CL-01-B1)

Contour Clamp, Top (CTR-CL-01-B1)

Contour, Torx Bolt (CTR-CL-01-B1) 1/4-20 x 7/16

Contour, Torx Bolt (CTR-CL-01-B1) 1/4-20 x 2 1/4

Contour Trim, 84

Contour Splice

Trim

Inner Corner Cap

Splice

End Caps

Outer Corner Cap

Clamp

Renewables Guide

PV Modules and Racking

XR Rail Family

An Ever-Adaptable Junction Box.

XR Rails are the backbone of the solar array. Their unique curved profile increases structural strength and spanning capability, allowing for fewer roof penetrations and more cost-effective system designs.

XR Rails are available in three targeted sizes: XR10, XR100 and XR1000. Each size supports specific design loads, while minimizing material costs. Whatever your location, there is an XR Rail to match.

Wesco Part No. Mfr.’s

XR10 — XR10 is a low-profile residential rail perfectly matched to regions without snow. It achieves 6-foot spans while also staying light and economical 400042-98749 XR-10-168M XR10, Rail 168", Mill

400042-98812 XR-10-168B XR10, Rail 168", Black 400042-99859 XR-10-184M XR10, Rail 184", Mill 400042-99860 XR-10-184B XR10, Rail 184", Black 400042-99880

XR-10-168M-US XR10, Rail 168" (14 Feet) Mill, US Production 400042-99878

XR-10-168B-US XR10, Rail 168" (14 Feet) Black, US Production XR100 — XR100 is the ultimate residential rail. It supports a range of wind and snow conditions while also maximizing spans 400042-98751

XR-100-168M XR100, Rail 168, Mill 400042-98836

XR-100-168B XR100, Rail 168", Black 400042-99857

XR-100-184M XR100, Rail 184, Mill 400042-99858

XR-100-184B XR100, Rail 184", Black 400042-98750

XR-100-204M XR100, Rail 204", Mill 400042-98837

XR-100-204B XR100, Rail 204", Black 400042-99877

XR-100-168M-US XR100, Rail 168" (14 Feet) Mill, US Production 400042-99876

XR-100-168B-US XR100, Rail 168" (14 Feet) Black, US Production

FlashFoot2

FlashFoot2 raises the bar in solar roof protection. Its unique water-seal design is both elevated and encapsulated, delivering multiple layers of protection against water intrusion. In addition, the twist-on cap perfectly aligns the rail attachment with the lag bolt to maximize mechanical strength.

• Twist-on cap eases installation

• Wind-driven, rain-tested

• Mill or black finish

Wesco

Black

Wesco Part No.

Mfr.’s Model No. Description XR1000 — XR1000 is a heavyweight among solar mounting rails. It is built to handle extreme climates and spans 12 feet or more for commercial applications

400042-98833 XR-1000-168A XR1000, Rail 168" (14') Clear 400042-98832 XR-1000-204A XR1000, Rail 204" (17') Clear 400042-99886 XR-1000-170M XR1000, Rail 170, Mill 400042-99885 XR-1000-210M XR1000, Rail 210", Mill

Bonded Splice — Multiple sections of XR Rails can easily be spliced and bonded together with internal, bonded splices

400042-98587 XR10-BOSS-01-M1 Bonded Structural Splice, XR10 400042-98586 XR100-BOSS-01-M1 Bonded Structural Splice, XR100 400042-98585 XR1000-BOSS-01-M1 Bonded Structural Splice, XR1000 400042-99865 XR10-BOSS-01-M1-US Bonded Splice, XR10, US Production 400042-99864 XR100-BOSS-01-M1-US Bonded Splice, XR100, US Production

FlashVue

• Right-Sized Flashing — 8" x 12" flashing footprint fits between and avoids most roofing nails

• Large Viewport — 0.75" opening in flashing enables easy alignment with the pilot hole

• Elevated Dock — Raised viewport platform diverts water and supports GripCap®

• Friction-Fit GripCap® — Unlike L-Feet, it stays in place so only one hand is needed to fasten

• 360° Placement — GripCap® installs in NS or EW orientation, or whatever is needed

• Sealing 7/16" Lag — Bolt and EPDM washer combo uses same socket size as rest of system

Wesco Part No. Mfr.’s Model No. Description

400042-98589 FV-01-M1 Flashing, FlashFoot, Mill

400042-98588 FV-01-B1 Flashing, FlashFoot, Black

Armor Products

K2 Armor with Big Foot, Kit

Discover the K2 Armor with Big Foot Kit — a high-quality, Germanengineered roof attachment for flat roofs, offering redundant waterproofing with K2 EverSeal.

Ideal for TPO, rolled asphalt, concrete, and EPDM membrane roofs, this code-compliant solution ensures minimal pallet and freight costs. Optimize your solar installations with the compact and efficient K2 Armor.

For more information, visit https://k2-systems.com/en-us/product-solutions/k2-armor-big-foot-kit/

The South Face

The South Face System is K2’s innovative south facing ballasted system with optional anchoring.

• Mats have built-in patented feature that accounts for thermal migration

• Sliding, self-aligning clamp allows for adjustable inter-row spacing

• Array density can be optimized per job

• Module rests on hook without need for a clamp during installation

• Stackable for shipping

• Can be installed in portrait or landscape orientation

Wesco Part

439004-99822

4000192 South Face Ridge

439004-99823 4000158 South Face Valley

439004-99791 4000159 South Face Summit

439004-99820 4000194 South Face Anchor Bracket

439004-99821 4000193 South Face Mat/Spacer Pad

439004-99819 4000197 K2 End Clamp Set, Mill

439004-99784 4000233 K2 End Clamp Set, Dark

439004-99816 4000278 SF, K2 Conduit Clamp, Kit

For more information, visit https://k2-systems.com/en-us/product-solutions/the-south-face-system/

Renewables Guide

Metal Rail-less Products

MicroRail TR

Quick installation with a minimum number of components results in a low total installation cost.

For more information, visit https://k2-systems.com/en-us/ product-solutions/microrail-tr/

Tilt Up Multi Row System

Our Tilt Up Multi Row System is a two-row tilted system, designed to give the installer flexibility with multiple degrees of tilt (7 to 25) and reduced part count.

• Inclined system allows the front leg to be raised up to 50 cm

• High quality, German-engineered system optimized for residential installations

• MK4 technology provides highest rail engagement

• Fast installation with minimal component count results in low total installed cost

• Flexible to several tilt angles and pre-engineered 7º–25º

• Minimize rail waste by using scrap as tilt legs

• Reduced freight — ships in a box

Wesco Part No. Mfr.’s Model No. Description

439004-99779 4000719 CrossRail 44-X 172", Mill

439004-99778 4000720 CrossRail 44-X 172", Dark 439004-99777 4000721 CrossRail 44-X 185", Mill 439004-99776 4000722 CrossRail 44-X 185", Dark 439004-99775 4000723 CrossRail 48-X 172", Mill 439004-99725 4000724 CrossRail 48-X 172", Dark 439004-99774 4000727 CrossRail 48-XL 172", Mill 439004-99762 4000728 CrossRail 48-XL 172", Dark

Standing Seam Rail-less System

Non-penetrating seam clamp maintains roof integrity. All that’s needed to install this system is the Standing Seam Rail-less and the Cross Clamp.

For more information, visit https://k2-systems.com/en-us/ product-solutions/standing-seam-rail-less-syst

CrossRail Simple Tilt System

The highlight of the CrossRail Simple Tilt System is the innovative Simple Knee, which streamlines the tilting process.

439004-99972 4000505 CrossRail Tilt Connector Set

439004-99968 4006042-H CR 48-X, 48-XL Climber Set

439004-99926 4006043 CR 44-X, Climber Set

439004-99747 4000135 K2 Cross Clamp Set, Mill

439004-99756 4000145 K2 Cross Clamp Set, Dark

439004-99784 4000233 K2 End Clamp Set, Dark

439004-99964 4000050-H Yeti Hidden EC for CR, 13 mm Hex Set

439004-99704 4000416 Simple Tilt Knee, Kit

439004-99739 4000559 K2 EverSeal Armor with Big Foot, Set

For more information, visit https://k2-systems.com/en-us/product-solutions/crossrail-tiltup-multirow-system/

MSX10 N-Type 108HC

Mono-facial High Efficiency N-type

• Rooftop module featuring 6.2% domestic content

• Sleek black-on-black design

• Achieves 22.3% efficiency with advanced high-density interconnect technology

• Assembled in the U.S.A.

• 25-year workmanship warranty, 30-year production warranty

• Made with N-type i-TOPCon Monocrystalline cells

Electrical Specifications

Product

Temperature Coefficients

Warranty Information

Module Product Workmanship Warranty

Mechanical Data

Solar Cells N-type i-TOPCon Monocrystalline Cell Orientation

Front Glass

mm AR Coating Tempered Glass

35 mm Anodized Aluminum, Black Encapsulant Polyolefin Elastomer (POE) Junction Box IP 68 Rated

Cable 1.2 m, Wire 4 mm2 (12AWG)

Connector MC4 EV02 / Staubli EVO-2A

Operating Conditions

Maximum System Voltage 1,500 Vdc

Operating Temperature Range -40°F to 185°F (-40°C to +85°C)

Maximum Series Fuse Rating 30A

Fire Safety Classification Type 1

Front and Back Load (UL Standard) Up to 5,400 Pa Front and 5,400 Pa Back Load. Tested to UL 61730

*Mission Solar Energy uses quality sourced materials that result in a Type 1 fire rating. Please note, the ‘Fire Class’ Rating is designated for the fully-installed PV system, which includes, but is not limited to, the module, the type of mounting used, pitch and roof composition.

Certifications and Tests

Inverters and Storage

Renewables Guide

Inverters and Storage

IQ8HC Microinverter

Our newest IQ8 Series Microinverters are the industry’s first microgrid-forming, software-defined

microinverters with split-phase power conversion capability to convert DC power to AC power efficiently.

IQ8HC-72-M-US@240 VAC

IQ8HC-72-M-US@208 VAC

Key Specifications

IQ8HC-72-M-DOM-US@240 VAC

IQ8HC-72-M-DOM-US@208 VAC

IQ8 Commercial Microinverters

The high-powered, smart grid-ready Enphase IQ8P-3P Microinverters are specifically designed for 120/208 VAC (4-wire) three-phase interconnection for small commercial solutions.

Each microinverter integrates with the IQ Gateway Commercial 2 and the Enphase App monitoring and analysis software.

With simplified design, improved energy harvesting, and advanced monitoring, microinverters offer true peace of mind during operation and maintenance.

Features IQ8P-3P-72-E-US/ IQ8P-3P-72-E-DOM-US1

Communication Power Line Communication (PLC)

Monitoring Enphase App Monitoring and Analysis Software. Both Options Require the Installation of an IQ Gateway Commercial 2. Compliance CA Rule 21 (UL 1741-SB), UL 62109-1, UL 1741/IEEE 1547, FCC Part 15 Class B, ICES-0003 Class B, CAN/CSA-C22.2 NO. 107.1-01. This Product is UL Listed as PV Rapid Shutdown Equipment and Conforms with NEC 2014, NEC 2017, and NEC 2020 section 690.12 and C22.12018 Rule 64-218 Rapid Shutdown of PV Systems for AC and DC Conductors, When Installed According to Manufacturer’s Instructions. 1 IQ8P-3P-72-E-DOM-US is made in the USA. The PCBA, electrical parts, and enclosure are domestically manufactured to meet the eligibility requirements for the ITC domestic content bonus adder.

IQ Battery 5P

The IQ Battery 5P all-in-one AC-coupled system is powerful, reliable, simple, and safe. It has a total usable energy capacity of 5.0 kWh and includes six embedded grid-forming microinverters with

a continuous power rating of up to 3.84 kVA. It provides backup capability, and installers can quickly design the right system size to meet the customer needs.

Non-Condensing Ambient

(discharging) –20°C to

Non-Condensing Chemistry Lithium Iron Phosphate (LFP)

Mounting Wall-Mount or Pedestal-Mount (sold separately)

IQ™ Gateway

Comprehensive, remote maintenance and management.

• Designed for installation indoors or outdoors

• Easy system configuration using Enphase Installer App

• Bidirectional communications for remote upgrades

• Supports power export limiting and zero export applications

• Flexible networking with WiFi, Ethernet or cellular

• 5-year warranty

Specifications

200A Continued Rated Production CT

120/240 VAC Split-Phase Power

802.11B /G /N Integrated WiFi Typical Power Consumption 5W Capacity Up to 600 Microinverters

IQ Battery 10C

An all-in-one, AC-coupled storage system, the IQ Battery 10C integrates 240 V and 120 V microinverters, providing backup functionality and removing the need for additional neutral-forming

IQ Gateway Commercial

Supports 120/208 V three-phase applications

• Integrated production and consumption metering for three-phase systems/services up to 200 A

• Enables web-based monitoring and control

• Bidirectional communications for remote upgrades

• Supports power export limiting and zero export applications

• Easy system configuration using the Enphase Installer App

• Flexible networking with Wi-Fi, Ethernet, or cellular (additional charges may apply)

and

hardware. It provides a total usable energy capacity of 10 kWh and delivers 7.08 kW of continuous power, easily supporting heavy loads such as HVAC units and pool pumps.

L1 and L2

IQ Combiner 6C

The IQ Combiner 6C consolidates interconnection equipment into a single enclosure, simplifying the installation of IQ Series Microinverters and IQ

Batteries by offering a consistent, pre-wired solution for residential applications.

Renewables Guide

Inverters and Storage

IQ Meter Collar

The Enphase IQ Meter Collar is designed to make whole-home backup accessible for every homeowner. By eliminating the need for a backup subpanel and the associated labor costs of load

rewiring, the IQ Meter Collar streamlines installation and ensures seamless integration with the Enphase Energy System.

Specifications

Dimensions 6.9 in x 8.1 in x 5.0 in (175 mm x 206 mm x 128 mm)

Mounting Options

Behind Utility Meter on Meter Main Combo or Standalone Meter Socket Downstream of the Meter or Main Panel on a Standalone Meter Socket

Enclosure Rating NEMA 3R (Polycarbonate)

Weight 4 lbs

Supported Circuit Breakers: Mains

Maximum 200A External

Maximum Continuous Current 200A

Maximum Short Circuit Current 22 kA (with external, load-side, overcurrent protection device.)

Energy Meter Accuracy +/- 0.5%

Overvoltage Category Category IV, Service Entrance Rated Communication Interfaces CTRL Wiring

IQ 50 EV Charger with J1772 Connector

40 A, 9.6 kW, hardwired, ruggedized connector, Wi-Fi enabled.

The IQ 50 EV Charger is a smart and reliable Level 2 charging station, providing energy management and custom scheduling using the Enphase App. When integrated with the Enphase Energy System, additional features allow you to charge an EV with

excess solar. Offering 9.6 kW of charging power which provides up to 38 miles of range per hour. Take advantage of low electricity rates through off-peak or custom charging schedules.

Specifications

Product Dimensions

Installation

Hardwired (3-foot service whip provided), NEMA 14-50 Plug, NEMA 6-50 Plug

Charge Cable Length 25 ft.

Vehicle Connector Type Rugged SAE J1772 Connector

Accessories Included SAE J1772 Connector Holster

Enclosure NEMA 4

Environment Rating

Indoor/Outdoor Rated

Operating Temperature -22° F to +122° F (-30° C to +50° C)

Certifications ETL, cETLus, ENERGY STAR

Enphase offers multiple options at different amperage requirements using both an NACS Connector or a J1772 Connector. The IQ50-EV Charge with J1772 is an example of one top seller.

For more information, contact your local Wesco representative.

Renewables Guide

Inverters and Storage

SMA Home Energy Solution

Meet the Sunny Boy Smart Energy — the most reliable solution for new installations and repowering projects. A hybrid PV + storage inverter (3.8 kW – 11.5 kW) that packs the ultimate flexibility, value and support aligned with your business. Add new options like the SMA Energy Meter-US, Backup Secure, Backup Select, Rapid Shutdown Initiator (RSI) and RSD Devices for maximized energy use and efficiency.

• Back-up ready, DC Disconnect, CEC listed, UL 1741 SB certified, 120/240/208 VAC

• Sunspec RSD/AFCI

• Self-consumption, peak shaving and backup

• CEC efficiency up to 98.1%

• Built-in SMA ShadeFix, Smart Connected and WiFi

*The sum of all inputs must not exceed 60 A for SBSE 3.8-7.7 and

SMA Backup Secure

Provides owners peace of mind during power outages. Up to 1,920W, 120VAC backup for eessential household appliances.

*Installer provides the on/off switch and electrical outlet.

*If SunSpec RSD devices are used, the SMA Backup Start module accessory must be added/installed to activate.

SMA Backup Select

Choose up to seven (7) 120V circuits to automatically power during a grid outage using energy from your solar panels when the sun is shining. For backup when sunlight isn’t available, you can add a battery to provide up to 24 hours of power. The system offers 3.8 kW output capacity, with a 5.7 kW option for larger installations.

SMA Commercial Energy Solution

SMA Energy Meter US Gives homeowners the complete picture of their energy use, home energy consumption and production monitoring; required for selfconsumption systems (Includes 2 CTs).

The SMA Commercial Energy Solution delivers 1000 VDC/480 VAC products that help businesses generate power for optimal energy use and sustainability — on rooftops, carports, ground mounts or repowering projects, today and into the future. Fully UL 3741 compliant, the system offers rapid shutdown and meets the highest PV Hazard Control standards, protecting first responders and giving building owners peace of mind. SMA is committed to safety-driven design and protocols that keep systems secure for the long run.

Sunny Tripower X

• DC to AC ratio of 150%

• Three MPPTs allows for connection of up to six strings

• Sunny Tripower X – 13 (208V) available to order beginning summer 2025

• Includes AFCI, DC Disconnect and SunSpec Certified Rapid Shutdown Transmitters

• CEC efficiency up to 98.0%*

*Depending on power class

Sunny Tripower CORE1

• DC to AC ratio of 150%

• Six MPPTs for flexible stringing and maximum power production

• 12 direct string inputs for reduced labor and material costs

• Achieve an optimized design using SMA Sunny Design with NEC 690.8(A) (1)(a)(2) when calculating maximum current on systems over 100 kW

SMA Commercial Energy Solution (continued)

Data Manager M — Monitors up to 50 devices, powered by ennexOS CALL

JMS-FA Sunspec Certified Shut Down Device

With fast, simple installation and commissioning, the Sunny Highpower PEAK3-21 is accelerating the path to energization. The PEAK3-21 1500 VDC inverter offers high-power density in a modular architecture that achieves a cost-optimized solution for large-scale PV integrators and repowering applications.

Sunny Highpower PEAK3-21

• PEAK3-21 1500 VDC inverter offers high-power density in a modular architecture that achieves a cost-optimized solution for large-scale PV integrators

• CEC Efficiency up to 99.0%

• Single MPPT input for centralized architecture implementation

Sunny Highpower PEAK3 FLEX-US— For Repowering

• Delivers adjustable AC outputs for power, current and voltage

• Can be tuned to match older inverters that operate at now uncommon voltages (like 385 VAC or 400 VAC)

• Enable customers to repower their systems while leaving the transformers in place and avoid costly or time-consuming studies

*Dependent on AC voltage

Why SMA?

Innovation

• Integrated, solution-focused product portfolio

• SMA ShadeFix

• Offered the first-to-market UL 3741 commercial solution

• IV curve tracing

• Advanced AFCI detection

Trusted Partner

• 40+ years of industry experience and expertise in string inverter technology

• Support throughout the entire project life cycle, from consulting and engineering to service and repowering

Monitoring

• Free MPPT-level monitoring on ennexOS Sunny Portal

• Analysis Pro and many configurable automatic notifications

• Export control with Data Manager M and Energy Meter

Service Support

• 24/7/365 support via Online Service Center from live agents and Sunny chatbot

• SMA Solar Academy

• Commissioning support for home and C/I products

• SMA Smart Connected — free automated support from SMA Service

Renewables Guide

Inverters and Storage

Power Everything with Tesla Powerwall 3

Powerwall 3 is a fully integrated solar and battery system designed to accelerate the world’s transition to sustainable energy. Powerwall 3 can store solar or grid energy for later use when the sun goes down or when the electricity prices are high; lowering their electricity bills, reducing their reliance on the grid, and power their homes during a grid outage. Once installed, customers can manage their home energy system using the Tesla App and customize system behavior to meet their energy goals.

Powerwall 3 has the ability to store up to 13.5 kWh of energy and start heavy loads rated up to 185 A LRA, meaning a single Powerwall 3 can support the power needs of most homes. Powerwall 3 is designed for fast and efficient installation and modular system expansion. With multiple Powerwall 3 units and/ or Expansions, it is easier and more affordable to scale up customers’ systems to provide 44 kW AC of continuous power and to store up to 94.5 kWh of energy.

• Low Cost Design: Designed and engineered to provide whole-home backup protection at a lower per-unit cost

• Simple Installation: With a fully integrated solar inverter, each unit is selfcontained with fewer parts to install

System Technical Specifications

Continuous Charge Power (Powerwall 3 only)

Maximum Continuous Charge Power (Powerwall 3 with up to (3) Expansions)

• Maximum Power Per Unit: One unit has the storage capacity and efficiency to provide backup power for the entire home

• Easy System Expansion: Designed to allow for easy stacking of up to 10 units as household energy needs increase

Output Power Factor Rating 0 - 1 (Grid Code configurable)

Maximum Output Fault Current (1 s)

Maximum Short-Circuit Current Rating

Load Start Capability 185 A LRA (Locked Rotor Amps)

Solar to Battery to Home/Grid Efficiency 1, 3

Solar to Home/Grid Efficiency 4

Power Scalability Up to 4 Powerwall 3 Units Supported Energy Scalability Up to 3 Expansion Units (for a maximum total of 7 units)

Supported Islanding Device Backup Gateway 2

Connectivity Wi-Fi (2.4 and 5 GHz), Ethernet, Cellular (LTE/4G 5)

Hardware Interface

Dry Contact Relay 60V 2A, Rapid Shutdown (RSD) Certified Switch and 2-Pin Connector, RS485 Connector for Tesla Remote Meter

AC Metering Accuracy +/- 0.5%

Protections

Integrated Arc Fault Circuit Interrupter (AFCI), Isolation Monitor Interrupter (IMI), Integrated DC Isolator

Customer Interface Tesla Mobile App

Warranty 6 10 Years

1 Values provided for 25°C (77°F), at beginning of life. 3.3 kW charge/discharge power.

2 Powerwall 3 can output up to 15.4 kW AC power at 64 A and 240 V.

3 Typical use case with energy produced by PV and stored in battery and then released to loads or the grid.

4 Tested using CEC weighted efficiency methodology.

5 The customer is expected to provide internet connectivity for Powerwall 3; cellular should not be used as the primary mode of connectivity. Cellular connectivity subject to network operator service coverage and signal strength.

6 Powerwall 3 must be reliably connected to the internet to secure the full 10-year warranty.

Power Everything with Tesla Powerwall 3

Solar Technical Specifications

Maximum Solar STC Input

Compliance Information

Certifications

V DC

Environmental Specifications

Operating Temperature 7 –20°C to 50°C

Operating Humidity (RH) Up to 100%, Condensing

Storage Temperature –20°C to 30°C, up to 95% RH, Non-Condensing, State of Energy (SOE): 25% Initial

Maximum Elevation 2000 m

Environment

Indoor and Outdoor Rated

Enclosure Rating IP55

Ingress Rating IP67 (Battery and Power Electronics) IP55 (Wiring Compartment)

Pollution Rating PD3

Operating Noise @ 1 m < 50 db(A) typical, < 62 db(A) maximum

IEC 61000-6-1:2016, IEC 61000-6-3:2020, IEC 62477-1:2022, IEC 62109-1:2010, IEC 62109-2:2011, IEC 62933-5-2:2020, IEC 62619:2022, UL 9540A, UN 38.3, Radio

Equipment Directive 2014/53/ EU, G98 Issue 1 - Amd 7:Oct 2022, G99 Issue 1Amd 9:Oct 2022, G100 Issue 2 - Amd 2

Environmental RoHS Directive 2011/65/EU, REACH Regulation EC 1907/2006

Grid Connection Single Phase

Emissions FCC Part 15 Class B, ICES 003

Seismic AC156, IEEE 693-2005 (high)

Fire Testing Meets the Unit Level Performance Criteria of UL 9540A

Mechanical Specifications

Dimensions

Weight

Mounting Options

1105 x 609 x 193 mm

Floor or Wall Mount

7 Powerwall 3 is designed to operate in all climates and in direct sunlight, from temperatures of -20°C to 50°C. Performance may be de-rated at operating temperatures above

Wire and Cable Solutions and Services

Wesco offers electrical contractors a suite of services designed to support your projects during installation to reduce labor, mitigate risk, speed installation, minimize scrap while increasing safety and financial leverage.

Project Execution Solutions

Wesco has developed many cabling solutions for many applications and cable types. Our representatives can map the best solution to your specific needs.

• Increased financial leverage

• Minimize injury risk

• Minimize scrap

Paraspin allows different diameters of cable to be pulled simultaneously by using independent spinning chambers.

Paraplex reduces the amount of reels at the job site by bundling of two or more cables paralleled on the same reel.

Ready Grip (Low Voltage & Medium Voltage) eliminates on- site termination by having medium-voltage pulling eyes installed by Wesco.

Low voltage cable cart is ideal for installing cables such as Category 5 and 6, security cables, door lock cables and other low voltage communications cables.

• Mitigate risk

• Optimize labor

• Speed installation

Speedpull bundles multiple numbered circuit conductors, so they can be accessed in a single pull.

Insta-reel consists of a standard wooden reel that has oversized flanges attached to both sides and becomes a payout stand when chocked in place.

Slim-spin reel is designed to simultaneously pull multiple cables for indoor applications. At only 32 inches wide, the Slim-spin easily fits through standard 36-inch doorways.

Solar Insta-reel pulls the positive and negative PV Feeder Cables.

Eliminates the need for jack stands or cable trailers at the job site.

Cables are cut to exact circuit length and can have pulling heads pre-installed.

Wesco Solar String Collection Solutions

Wesco’s solar portfolio combines deep technical expertise, a broad range of products, and proven execution strategies to support large-scale projects. Engaging Wesco early in your planning process ensures you maximize the value of our engineered services and integrated solutions.

Harness to Combiner Solution

Over-Mold PV Harnesses:

• Connects multiple PV strings

• Custom-designed and labeled

• Over-molded fuses

• UL 9703 Listed

• Quality control tested

• Design engineering support

Custom-Manufactured Assemblies (Homeruns/Extenders):

• Connects modules or harnesses to combiner boxes

• Pre-terminated and labeled

• UL 9703 Listed

• Quality control tested

• Design engineering support

As your partner across all three segments of the DC String Collection system, Wesco delivers high-quality, competitively priced solutions.

Combiner Boxes:

• Combines DC string circuits into main DC feeders

• High-amp options for utility-scale, low-amp for commercial

• Multiple mounting configurations

• Pre-terminated PV whips

• UL 1741 Listed

• Design engineering support

Key Benefit:

• Engineering Support: Wesco Engineering reviews site plans and provides complete solution

• Plug-and-Play: Reduces scrap, excess, and labor

• Factory Terminated: Reduces connectors failures by eliminating field terminations

Harness to Trunk Solution

Wesco combines its internal manufacturing capabilities with leading solar suppliers to deliver an innovative trunkbased solution for large-scale applications. The aboveground aluminum trunk system integrates Wesco-built cable assemblies, insulation-piercing connectors (IPCs), and Wesco-built load break disconnects. Wesco’s harness to trunk solution offers customers a high-quality solution in a category with limited options.

Over-Mold PV Harnesses: (Connects multiple PV strings)

• Custom-designed and labeled

• Over-molded fuses

• UL 9703 Listed

• Quality control tested

• Design engineering support

Trunk Assembly: (Connects modules or harnesses to LBDs)

• Pre-terminated and labeled

• UL 9703 Listing Pending

• Field-deployed or plug-and-play

• Design engineering support

Load Break Disconnects: (Required field disconnect)

• Simple design for easy installation

• Multiple mounting options

• UL 1741 Listed

• Design engineering support

Ready to Power Your Next Solar Project?

Partner with Wesco for engineered, high-quality, plug-and-play solar string solutions—built to scale with your success.

Comprehensive Wire and Cable Solutions with Supply Chain Assurance

Wesco delivers high-performance wire, cable, accessories, and hardware tailored for the solar energy market. Our products are built to withstand environmental challenges and mechanical stress, ensuring long-term reliability across diverse solar applications. As a trusted leader in solar connectivity, Wesco combines technical expertise with a robust global supply chain to support renewable energy projects of all sizes.

Photovoltaic Cables — Copper String Wire and Aluminum Feeder Cable

Sunlight-resistant, durable cables for interconnecting solar panels and system components. UL 4703 Listed.

Medium Voltage Power Cables

Ranging from 5 kV to 46 kV, available with TR-XLPE or EPR insulation and various shielding options including copper tape, concentric neutral wires, or flat straps.

Communication and Control Cables

Fiber optic cables in multiple configurations, including armored and Cable-in-Conduit options, ideal for data transmission and system monitoring.

Instrumentation and Control: tray rated cables with multiple insulation, jacket and conductor variations for motor control and system power/control applications.

Grounding Cables

Bare copper and copper-clad steel wires designed to safely discharge excess electricity and ensure system grounding.

Transmission Wire and Cable

Overhead bare or covered transmission wires such as ACSR and AAAC for efficient power distribution.

Hardware and Equipment

A full suite of accessories to support wire and cable systems, including:

• MV Sectional cabinets, MV Splices and Terminations, Lugs, Grounding, Cable ties, edge clips, Split-Loom, Conduit, Fittings, Tools, Hardware, Safety, GOABs, Reclosers, CTs, PTs, Insulators, Breakers, Cable Tray

Leading with Domestic — Supporting with Global

Wesco leads the industry by partnering with the largest and most established domestic cable manufacturers, ensuring trusted quality and performance across every project.

In addition to our strong domestic foundation, Wesco leverages a substantial global sourcing footprint—built on a commitment to quality, reliability, and compliance.

We apply a rigorous, multiphase vetting process to identify and certify only a select group of global vendors who meet our stringent standards. This ensures that every product sourced internationally upholds the same level of excellence our customers expect.

Global Quality Assurance

• Wesco Certified Global Vendor Program

Suppliers undergo a rigorous review process to qualify as certified vendors, ensuring consistent quality and compliance

• 3-Phase On-Site Factory Audits

Conducted by UL to verify manufacturing capabilities and compliance with. Social standards; Security protocols; Quality benchmarks

• Pre-Qualification Testing (PQT)

Suppliers submit production samples to UL labs for testing against agreed specifications before approval

• Pre-Shipment Inspections (PSI)

Every Wesco purchase order requires UL-conducted inspections prior to shipment, ensuring product integrity and specification compliance

Renewables Guide

BOS and Tools

ReliaHome™ Smart Panel

Intelligent Energy Management

• Avoid service upgrades when adding electrical appliances

• Optimize and extend battery backup through whole home monitoring and automation

• Compatible with any load center, inverter or battery backup system

• Pre-wired and labeled for straightforward installation

• Up to 12 circuits of load management, stackable for additional control

• Set-and-forget or real-time circuit scheduling

• Real-time and historic energy insights

• Designed, engineered and assembled in Virginia

• U.S.- based customer support

Wesco

783164-72067

783164-74663

783164-69469

783164-69468

ABBHEM2 ReliaHome Smart Panel — Indoor

ABBHEM2N3R ReliaHome Smart Panel — Outdoor

ABBHEM1CT Spare 200A CTS for Second Source

ABBHEM1RC ABB Smart Panel Replacement Cover

ReliaHome™ Meter Combos

Solar-Ready Meter Combos

• UL listed for solar ready applications

• Complies with the National Electric Code (NEC) for use with a photovoltaic (PV) power source

• Per NEC 705.12, these meter combos can handle current up to 120% of the bus ampacity, using standard back fed circuit breakers

• Plug-on neutral capability with ABB ReliaLock installation method on select models

• Built to last – galvanized, rust-resistant enclosures ensure quality and performance

• Common circuit breaker platform — simplified stocking strategy across all ReliaHome products

783164-72050

Spec-Setter™ Safety Switch with Viewing Window

The Safer, The Better

• Heavy-duty switches are available in 30–1200 amps

• Available in all enclosure types — NEMA 1,3R, 4/4X and 5/12

• UL Listed to UL 98 Standards

• Meet NEMA enclosed KS1-2001

• Largest viewing windows are availabe for 30–600 amp heavy-duty switches

• Clear line shield installed in all heavy-duty switches 30–600 amp in all enclosures types

783164-63439

783164-08709

Black Beauty® General Purpose Nylon Cable Glands T&B® Rigid and Intermediate Metal Conduit Fittings

®/E-Z-Ground®

Color Keyed®

• Connectors for aluminum/copper code conductors

• One hole lugs/two-hole lugs

Deltec® Double Locking Heads

Deltec® Installation/Cutting Tool

Catamount® Cable Ties

® Cable Tie with Double Locking Head

Ty-Rap® Cable Tie, Stainless Steel

Ty-Rap® High-Performance Cable Edge Clip

Ty-Rap® High-Performance Cable Ties

Cable ties secured with metal barb to provide safe, secure wire/cable bundling.

Cables and Wires for Renewable Projects by APAR Industries Limited

Product

DC Feeder Aluminum Cables

DC Feeder Copper Cables

Single-conductor photovoltaic (Type PV) power cable 2000V 8000 Series aluminum conductor XLPE insulation. Sizes 8 AWG through 1000kcmil. Heatand moisture resistant RoHS. 90º C.

Single-conductor photovoltaic (Type PV) power cable 2000V copper conductor XLPE insulation. Sizes 14AWG through 1000kcmil. Heatand moisture-resistant RoHS. 90º C.

EPR | CPE | DLO Cables

2kV heavy-duty flexible power cable (HDFPC) DLO, rated 90º C dry or wet. 2kV type RHH/RHW 2 flexible power cable rated 90º C dry or wet.

MV Cable | XLPE Cables

MV Cable | EPR Cables

Tower Cables

Primary grounded distribution cables. Block strand aluminum conductors TRXLPE insulation, copper wire, concentric neutral, longitudinal water and blocked XLPE outer protecting jacket. PVC and LLDPE outer jacket.

CU/AL Conductor, EPR Insulation, Metallic Shielded and CPE Outer Jacket, 5 to 35 kV Grade, MV-90/MV 105 type cable

Aluminum conductor. AA 8000 Series, compacted stranded, 2000V, EPR insulated and CPE sheathed cables of size 1/0AWG through 1000kcmil.

• For use in solar power applications

• Rated 90º C for exposed or concealed wiring in wet or dry locations

• Rated for direct burial conduit

• For use in solar power applications

• Rated 90º C for exposed or concealed wiring in wet or dry locations

• Rated for direct burial conduit

• Use for drilling rigs, railroad and transit car wiring, mining and other industrial equipment, and as flexible motor leads and wind turbine applications

• The cable is suited for use in wet and dry areas, conduits, ducts, troughs and trays

• For use on single phase and 3 phase primary underground distribution system operating at 35kV phase to phase

• For use at conductor normal working temperature of 90º C and 105º C

• Suitable for either direct burial or installations in ducts in dry and wet location

• For use on single phase and 3 phase primary underground distribution system operating at 35kV phase to phase

• Suitable for use in wet or dry locations, direct burial, underground duct and where exposed to sunlight

• Used in wind towers

• UL-44 for Type RHW-2

• UL-4703 for Type PV

• UL 854 for USE-2

• UL-44 for Type RHW-2

• UL-4703 for Type PV

• UL 854 for USE-2

• UL-44 for Type RHH/ RHW-2

• ASTM B172

• UL-1072

• ICEA S-94-649

• AEIC CS8

Tower Cable

35KV MV Cable DC Feeder

Aluminum Cable

DC Feeder Copper Cable

Renewables Guide

BOS and Tools

600/1000 VDC Switches

• UL® Listed to UL 98B standard

• Ampacity range — 30–400A

• NEMA 3R, 4 painted steel, and 4X 304 or 316 stainless steel enclosures

• 1-, 2- and 3-circuit configurations for both grounded and ungrounded systems

• Non-fusible only (currently no applicable 600/1000 VDC fuses are available at 100A and below)

• Clear polycarbonate deadfront shield

• Factory-installed jumpers

• Suitable for use on a circuit capable of delivering up to 10,000A at 600/1000 VDC

DCG 3 06 1 U R M

*Not all configurations for ampere rating and number of circuits are available. All circuit configurations can be found in the product dimension tables. Protection

Class and Type

DCG = DCU = DC disconnect/grounded system DC disconnect/ungrounded system

1500 VDC Switches

auxiliary contact

2NO/2NC auxiliary contact

Viewing window

Factory-converted Class J fuse provisions Switch Series M = DC photovoltaic applications

Rated for bidirectional flow of power as well as for increased DC voltages required with higher-rated inverters. Additionally, their heavy-duty safety switch design protects people, property and investment. Their proven reliability can meet your current and future energy transition needs.

DCG 1 15 4 U D K W

DCG =

system

disconnect/ungrounded system

*Not all configurations for ampere rating and number of circuits are available. All circuit configurations

Eaton Heavy-Duty Safety Switches with Advanced Visibility Features for

Safety and Confidence

Eaton heavy-duty safety switches with enhanced visible blades provide a highly visible means of disconnect to help improve personnel safety and equipment protection. Ideal for installation in environments where reliable performance and service continuity are critical. The design enhancements made to these switches provide added value for safety.

Eaton Enhanced Visible Blade

Improved Safety

• Enhanced visible means of disconnect allow personnel to clearly see that blades are disengaged from stationary contacts when the switch handle is in the OFF position

• New visible blade design provides increased visibility over each pole, allowing users to clearly see the trailing edge of the blade

• Material color update from red to yellow creates greater contrast between blades and arc shield

Reliable Performance

• Two points of contact provide a positive open and close operation and help prevent contact burning for longer contact life

• Meets stringent UL® 98 and CSA 22.2 No. 4 standards for safety, durability and reliability

• Builds upon Eaton’s heavy-duty switch solutions, which have decades of successful operation

Increased Flexibility

• Available in 30–1200A ratings

• Enhanced Visible Blade standard on 30–100A General Duty and Heavy Duty Switches

• NEC 230.62 and UL® 98 compliant Service Entrance Barrier standard

• Fusible and non-fusible configurations in two-, three-, four- and six-pole

• NEMA 1, 3R, 12, 4 and 4X enclosures for robust environmental protection

• Modifications available such as auxiliary contacts, pilot lights and more

To order safety switches with enhanced visible blade features and no viewing window, the standard heavy-duty catalog number should be used with the addition of a “V” suffix. The “V” suffix is not applicable to 30A–100A switches as they have Enhanced Visible Blade standard.

Enhanced visible means of disconnect allow personnel to clearly see that blades are disengaged from stationary contacts when the switch handle is in the OFF position.

Standard Service Entrance Barrier (30-1200A)

Eaton Solar Power Centers

Cost Effective

Whether for new installation or renovation, the line side solar meter breaker allows for up to 125A solar without the need to up-size incoming utility wire to match the maximum amperage of the distribution bus.

Solar rating is no longer constrained by distribution bus rating (NEC690.64).

• Utility cable can be rated to match the amperage of the main breaker instead of the maximum bus rating

Line Side Solar Meter Breaker

• Factory labeled for solar-ready installation

Markets and Applications

• EUSERC meter breaker

• Residential

MBE2040PV200BTS

Solar Power Center Features

Solar power center nameplate (on the front of the door) highlights that the device is a component of a complete PV electrical system.

Permanent solar marking identifies that the terminals on both line and load sides may be energized in the open position.

CH42PVPN200

Permanent solar marking identifies location of the parallel energy source disconnect (backfed PV breaker), which is always located opposite the normal power overcurrent device.

Permanent solar marking identifies the use of dual power sources, one normal power and the other a power production source (for example, solar).

Permanent solar marking identifies maximum bus, utility and PV disconnect ratings to ensure that the total utility and inverter power sources do not overload the busbar.

225A rated copper bussing maximizes solar source up to 70A for standard units.

200A main breaker factory installed and located at the end of the distribution panel, ensuring compliance with NEC® requirements.

Overhead and underground feed applications.

Inboard neutral provides direct neutral connection for breaker, eliminating the need for wiring a pigtail.

One-piece steel backpan provides reliable breaker mounting and superior stability.

One keyhole at the top and bottom provides easier mounting and leveling.

Ring (shown), ringless and lever bypass designs available to meet different utility requirements.

Surface (shown), flush and semi-flush mounting designs available for all installation types, including stucco homes.

Solar Power Center Meter Breakers

Type BR Meter Breakers

Combination Service Entrance Devices—EUSERC—7"-Deep Design 786685-69022

Combination Service Entrance Devices—Non-EUSERC (Over/Under Construction)

Combination Service Entrance Devices—Non-EUSERC—Lever Bypass (Over/Under Construction)

786685-69027

*For box size information, please contact your local WESCO Branch. **Type BR main breaker factory installed. All other units Type CSR.

Solar Power Center Loadcenters

BOS and Tools

Offering You the Full Package… Plus the Ability to Customize

At Eaton, we know space is always at a premium, time is limited and cost matters. That’s why we offer solar solutions that ease installation, save labor and lower the total cost of investment. For example, our spacesaving AC combiner integrates fuse protection and a disconnect or circuit breaker all within one enclosure. Integrated cable management, custom cable harness assemblies and transformers specially designed for solar PV applications are further examples of how our equipment is engineered to save our customers valuable space, time and money.

Eaton’s electrical engineering consultants at our satellite facilities understand your regional requirements and offer the fastest way to get you the right products your project needs. Our local expertise can fabricate custom electrical assembles, test and certify them, and provide the local support required. It’s like having a neighbor you can count on when you need a hand. To learn more about these capabilities, visit Eaton.com/Satellites.

Eaton’s Electrical Balance of System

Cable management

Cable harness assemblies

DC fuses, switches and circuit breakers

AC combiners, panelboards and switchboards

Solar transformers

Medium voltage switchgear

Electrical Balance of System for Commercial Installations with String Inverters

Renewables Guide

BOS and Tools

Eaton xStorage Battery Energy Storage System (BESS)

250–1000 kW power, up to 3MWh stored energy. Versatile energy storage for commercial and industrial applications.

The demand for power, and variation in the demand, continues to increase due to end-user loads and electrification, including the proliferation of new machinery, DC charging and AI-based chips. Battery energy storage systems (BESSs) play an important part in creating a compelling next-generation electrical infrastructure that encompasses microgrids, distributed energy resources (DERs), DC fast charging, Buildings as a Grid and backup power free of fossil fuels for buildings and data centers. A BESS can store and supplement power needs to keep utility loads relatively uniform based on utility supply and end-user demand. The xStorage BESS optimizes energy usage and enables energy transition with support for energy storage, EV integration and grid modernization. The ability to avoid peak usage rates from utilities helps reduce energy costs for businesses, government and military agencies, schools, industrial plants and healthcare facilities. If utility power is interrupted, the BESS can provide environmentally friendly backup to reduce dependence on generators.

Key features

Versatile energy storage

• xStorage BESS holds 250 to 1000 kWh of usable stored energy (279 to 1117 kWh of installed energy)

• The BESS includes a control cabinet with auxiliary transformer, a power conversion system (PCS) and up to three battery cabinets (with six or eight battery modules in each cabinet)

Flexible installation

• Modular installation maximizes available space (control cabinet, PCS and battery cabinets can be individually placed)

• Enclosures mount directly onto an outdoor concrete pad without the need for an additional container and air conditioning

Liquid-cooled PCS and battery cabinets

• PCS and battery cabinets have self-contained liquid cooling to deliver more precise temperature regulation than an air-cooled BESS

• Lithium iron phosphate batteries are maintained within two to three degrees Celsius of their ideal operating temperature for minimal maintenance and improved reliability and uptime

Energy functions

Energy optimization

• Peak shaving — During times of peak demand, stored energy can be used to help avoid penalties from the utility

• Time-of-use optimization — Energy consumption is shifted to avoid peak usage and optimize battery charge/discharge times. During the day, stored energy is used to offset peak demand, saving money on utility fees. Batteries charge at night when demand is lower and utility power is less expensive

Uninterrupted operation

• Backup power — Enables islanding capability to protect against downtime due to utility outages

• Solar self-consumption — Allows efficient use of on-site generation sources, like solar panels, and storage of the excess energy for later use

Grid stabilization

• Demand response — If the utility company requests a reduction in power use, stored energy can replace utility power to avoid penalties

• Aggregation services — The BESS can be aggregated with other distributed energy resources and managed by a higher-level site controller to optimize energy usage and gain financial benefits from participating in energy markets

Why choose xStorage BESS?

Specialized management features maximize system uptime

• Embedded Global Stored Energy Controls (GSEC) hardware provides mission-critical accuracy to optimize energy usage

• Eaton’s Brightlayer software suite enables remote monitoring and management

• The xStorage BESS is optimized for predictive 24x7 monitoring and management service to proactively identify component risks, reduce downtime and expedite critical alarm response

Expert service and support

Full support is available from quotation to startup and beyond.

• 24x7 call center support with dispatch

• Service plans from extended warranty to response-timebased agreements

• National network of 300+ highly trained field service engineers to support startup and provide technical support, maintenance and service

• Service engineer vehicles stocked with common spare parts

• Centralized spare parts warehouse with overnight shipping capability

Eaton xStorage Battery Energy Storage System (BESS)

Technical specifications

Control cabinet with 480/208V auxiliary transformer

BESS Rating

Power rating

Power conversion system (PCS)

250 to 1000 kW

Energy rating 250 to 1000 kWh

AC Characteristics

Nominal voltage (+/- 10%)

480 VAC 3Ph/3W

Aux power 208 VAC 1Ph

Max fault current allowed from AC source 180 kAIC

Power factor 100% active to 100% reactive

Input current distortion

Peak efficiency

DC Characteristics

DC voltage (nominal) 761 to 1200 VDC

DC voltage (maximum) 720 to 1500 VDC

Minimum battery voltage 1.65 x nominal VAC

Max fault current allowed from DC source 180 kAIC

Battery Cabinet (each)

Battery type Lithium iron phosphate

Battery voltage 1165 to 1498 VDC

Rated energy 373 kWh

General Characteristics

Ambient temperature (operating) -20°C to 50°C (-4°F to 122°F), derating >40°C (104°F)

Ambient temperature (storage) -40°C to 60°C (-40°F to 140°F)

Humidity 5 to 95% non-condensing

Protection NEMA type 3R (IP54)

Cooling (PCS/Battery cabinets) Liquid cooled (self-contained)

Battery cabinet

General Characteristics (continued)

Battery cabinet (interior view with 8 battery modules)

Cooling (Control cabinet) Air cooled (self-contained)

Audible noise

Altitude (max)

<75 dBA @ 3 m

1000 m @ 40°C (104°F) without derating

Installation Pad mount or skid mount

Dimensions and Weight (480V system)

Control cabinet 53.5" w x 58.5" d x 68.9"

(each)

Available Modes of Operation

Peak shaving, time-of-use optimization, demand response, backup power, islanding, solar self-consumption, aggregation services

References

System

Power conversion system

Battery

UL 9540

UL 1741 SA, SB

UL 1973, UL 9540A

Other ISO9001

Communications

Modbus TCP/IP

Service

Startup

Standard

24x7 dispatch call center for service needs Standard

User remote monitoring and control Standard

Service plans (remote or onsite) Optional

Predictive analytics remote monitoring and service Future

Due to continuous improvement programs, all specifications are subject to change without notice.

Renewables Guide

Bussmann® series Photovoltaic Overcurrent Products

Bussmann series Fuses

• Available in ferrule, ferrule with PCB tabs, bolt fixing, blade and bolt-on versions

• Low watts loss for energy efficiency

• Meet prevailing agency standards

• RoHS compliant

Bussmann series Fuse Blocks and Holders

• Available for ferrule, inline and bladed fuses

• UL®, IEC

• RoHS compliant

• Accessories and options available to extend application flexibility

Bussmann series 800VAC UL Recognized Fuses for Use with Solar String Inverters

• Can be used in UL AC Combiners

Current Rating

Size 2

Size 3

Bladed with Lugs

Bolt Holes No Lugs

125A 170M7356 170M7356-B

160A 170M7357 170M7357-B 200A 170M7358 170M7358-B

AbleEdge Home Energy Management

Transform new and existing loadcenters into modular smart panels. Electrification, increasing energy costs and more frequent power outages are driving homeowners to invest in onsite energy sources to keep the power on and control or even reduce electricity bills. Eaton’s AbleEdge smart breakers streamline these updates to retrofit and new home energy systems — while helping avoid main panel upgrades and utility service increases, and extending onsite backup duration during a grid outage.

Minimize equipment, maximize functionality and create flexible energy systems to power today and tomorrow.

Optimize energy use with intelligent load management. Adding EV charging, heat pumps and other electrical appliances puts new strains on existing infrastructure. Eaton AbleEdge smart breakers provide proven intelligent load management to safely maximize capacity from the existing panel and utility service— minimizing additions equipment and maximizing functionality without replacing existing panels or upgrading utility infrastructure. This approach to intelligent load management also enables home energy infrastructure to automatically extend available onsite energy resources during a grid outage to power your critical home energy needs for longer.

Simplify solar and storage deployments.

Whatever onsite distributed energy resources (DERs) you want to add, Eaton AbleEdge smart breakers are designed to help. Delivering interoperability and flexibility, AbleEdge smart breakers create flexible power systems that transform what’s possible for the home as an energy source. And we’re working with the biggest names in home solar and energy storage to streamline deployments, maximize functionality of your energy investments and avoid the need for panel upgrades.

Update home energy systems without replacing the existing panel. AbleEdge smart breakers retrofit into existing electrical infrastructure (Eaton BR loadcenters and meter breakers as well as AbleEdge critical loads and combiner box panels) to avoid main panel upgrades, reduce equipment count and installation time.

Smart homes start with Eaton AbleEdge smart breakers. Eaton AbleEdge smart breaker technology delivers advanced control and energy insights, supporting smart and automated energy decisions in real time, to help you realize the full benefits of your energy assets.

There’s an app for that.

Managing energy habits can have a big payoff. Our Brightlayer Home app delivers data-driven insights and control to the palm of your hand, so you can optimize energy use, reduce your electric bill and advance sustainability.

For more information, contact your local Wesco representative.

Renewables Guide

Enclosed NRX Power Circuit Breakers

The Enclosed NRX is applicable anywhere remote open/close functionality is needed. It aligns with the needs and demands of not only the commercial and industrial markets, but the energy transition and energy storage markets as well.

Applications

• Engine generators

• Commercial and industrial distribution

• Emergency backup power and isolation applications

• Industrial lock-out/tag-out (LOTO)

• Utility control for load shed/ isolation/emergency

• End user control for load shed/isolation/ emergency

• Transfer between sources

• Pump station remote operation

• Islanding mode

• Any location where remote operation is required or desired

• Microgrid ready interconnect device

Standard features

• Remote open/close

• 1200 A frame (1000 A max.)

• 100% rated device

• PXR25 trip unit with LSIG, Modbus® and Arcflash Reduction Maintenance System™

• Maintenance mode cover control

• Safe off feature

• NEC® 240.87 compliant

• NEMA® Type 1 and NEMA 3R enclosures

• 120 Vac control voltage

• Trip indicator and bell alarm (2 Form C)

• Auxiliary contacts (4 Form C)

• 65 kAIC at 480 VAC

Optional features

• Stainless steel (304, 316)

• Custom paint

• Voltage indicators

• Surge protective device

• Remote pendant station

Certifications

• UL® listed per UL 489 (File No. E309241)

• cULus listed per CSA® C22.2 No.5 (File No. E309241)

PT module

NRX (PD-NF) breaker 1

– PXR25 trip unit with LSIG, Modbus and Arcflash Reduction Maintenance System

– Motor operator

– Spring release, latch check switch

– 2 shunt trips—4 Form C auxiliary switches Control power transformer (120 VAC output)

Enclosed NRX Power Circuit Breakers

Enclosed NRX Breaker

1 = 2 = 3 =

4 =

5 =

6 =

7 =

8 =

NX 8 A 1 N L3 R OSPD

NEMA Enclosure

G = R = NEMA 1 NEMA 3R

Ampere/Fault Current Rating

200A, 65kAIC at 480V

250A, 65kAIC at 480V

300A, 65kAIC at 480V

400A, 65kAIC at 480V

500A, 65kAIC at 480V

600A, 65kAIC at 480V

800A, 65kAIC at 480V

1000A, 65kAIC at 480V System Voltage

*Customer supplied 120V source for control circuit.

Options/Modifications

Terminals

(include control wire terminal)

TA700NB1MCWT

3/0–400kcmil (3 per phase)

TA1000NB1MCWT

4/0–500kcmil (4 per phase)

TA1200NB1MCWT

= #1–500kcmil (2 per phase)

500–750kcmil (3 per phase)

TA1201NB1MCWT

Blank = 0SPD = 00WT = 0RED = 00OR = 00SS = 0316 = 316W = 00RL = 0RPS =

None

Surge protective device (200kA)

Painted white

Painted red

Painted orange

304 stainless steel

316 stainless steel

316 stainless steel painted white

Red light instead of blue light (use 10250T197LRP24)

Remote pendant station

Short-Circuit Ratings

*D1 measurement represents additional depth due to required venting. Mfr.’s Model

Wesco Part No.

Renewables Guide

Shunt Trip Safety Switch

Eaton’s shunt trip safety switches can now be integrated with ground fault and arc energy reduction technology. Incorporating ground fault with safety switches meets service entrance requirements for 1200A. Arc energy reduction improves safety by providing a simple and reliable method to reduce fault clearing time. Faster clearing time means less arc energy. Less arc energy exposure means improved worker safety.

Eaton’s exclusive line of shunt trip safety switches incorporates the tried-and-true heavy-duty safety switch with an integrated shunt trip module, providing capabilities and applications not previously possible with a standard safety switch.

• Arc energy reduction*

• Ground fault*

• Remote opening (distant from switch)

• E-stop

• Safety interlocking

• Machinery OEM interlocking

• Cost-effective solution for high-interrupt applications

*Relay and applicable sensors/CTs available integrated into safety switch.

1. For overcurrent sensing only, remove orange jumpers, use terminals 5 and 6.

2. For ground fault sensing only, remove orange jumpers, use terminals 1 and 2. Move red jumpers from 5 and 6 to 1 and 2.

3. To enable remote maintenance mode, remove jumper at 7 and 8 and connect to a normally closed switch.

4. Control power transformer fusing, terminal blocks and neutral sensor are application specific.

Shunt Trip Safety Switch

Key features (when configured with integrated relay)

• Standard heavy-duty safety switch design with integrated shunt trip module

• Passes Class 1 ground fault testing (1200% opening)

• Integral ground fault available for 480 VAC service entrance applications (NECT 230.95)

• Integral arc energy reduction system available (NEC 240.67)

• Overcurrent protection

STS 3 6 8 N W 3 2 - 1 B 00

Switch Series

STS = Shunt trip switch (UL)

NEMA 4 (painted steel)

NEMA 4X, Stainless 304

NEMA 4X, Stainless 316

1 Relays can only be used with fusible switches.

2 Available for 600 VAC switches only.

3 Shunt trip safety switch with relay protection must use 120 VAC coils.

4 Available for 400–1200A fusible switches only.

5 Only one relay option allowed.

6 Relay viewing window standard with relay option.

7 Option A or C are not available for a 2-pole switch.

Auxiliary Switch

1NO/1NC alarm switch only

1NO/1NC auxiliary contact only

2NO/2NC auxiliary contacts only

1NO/1NC auxiliary contact and 1NO/1NC alarm switch

2NO/2NC auxiliary contacts and 1NO/1NC alarm switch

Control pole

Factory-converted provisions for Class J fusing

Factory-installed neutral for nonfused switch

Factory-converted provisions for Class T fusing

Viewing window over switch blades

Renewables Guide

Solar Solutions

1 Compression Terminals and Splices

Burndy® Hydent™ copper and aluminum compression terminals and splices for all sizes and applications.

2 Grounding Solutions

Burndy produces compression, mechanical and exothermic connectors for all grounding needs.

6 Wiley Wire Management

High-quality wire management for effcient organization and clean aesthetics in PV arrays.

3 Cold Shrink

7 Primary Pedestals

Also known as sectionalizing cabinets, Hubbell offers a full line of fiberglass and steel sectionalizing enclosures.

8 Box Pads and Ground Sleeves

10 Trunk Bus Solutions

Insulation piercing compression connectors deliver cost-effective, safe and reliable installation.

11 String Combiner Enclosures

A superior solution for utilitylevel solar applications.

Burndy provides a complete range of black and clear cold shrink products to insulate terminal lugs and splices, ensuring a fully engineered connection.

Hubbell box pads and ground sleeves provide a means to securely anchor and support the weight of pad-mounted electrical equipment.

12 Load Break Disconnect Enclosures

Disconnect switch enclosures with industry-leading safety and design features.

4 Wiley Bonding and Grounding

9 MV Cable Accessories

The Wiley WEEB® offers an easy, cost-effective solution for bonding PV module frames and racking.

5 Burndy Unirap™ Cable Ties

Offering a wide variety of colors and tensile strengths from 18 to 9000 lbs. with ready-to-secure latching mechanisms.

Full line of 35kV to 600V amp cable accessories, can be installed on conductors ranging from #2AWG to 1250 kcmil. Limits over-voltages to acceptable levels, protecting equipment and extending service life.

13 QIKSHEAR™ Shear Bolt Connectors

Medium voltage rubber goods and terminations.

For more information, contact your local Wesco representative.

Compression Insulation Piercing Connector (YIPC)

cULus Listed 486A-486B Wire Connector Category ZMVV

Burndy’s gel-filled cover design and material selection provides the following benefits:

• cULus Listed 486A-486B Wire Connector Standard

• UL 486D Sealed Wire Connector Standard compliant with Sequence E Rain and Sequence H Sunlight Resistance/UV

• Polycarbonate material: UL 94 V-0 flame rating

• Full connector perimeter gel seal, when covers are locked into place

• Eight (8) locking features, two (2) per side

• Strain relief locking devices provide stress and tension relief at the connection, minimizing wire movement in the gel for optimal sealing, while offering proper wire alignment grooves for placement in the cover

• Voltage rating: 2kV

• Patent pending

Wesco Trunk Assembly Options

Fully Engineered and Built Plug n’ Play Option

To best supporl the customer’s project, Wesco reviews the engineered plans and provides a bill of materials (BOM) and drawings for approval. This includes AL 2K PV wire, Burndy insulation piercing connectors (YIPCs), string pigtails, and labor to fabricate everything. From there, Wesco cuts the AL PV trunk line to length and installs Burndy YIPCs where specified. The Burndy YIPCs have pigtails to be plugged directly into the harness/extender in the field. Each trunk assembly is labeled per disconnect/inverter location as requested and is coiled and layered on pallets for easy deployment to the field.

For more information, contact your local Wesco representative.

Renewables Guide

Leviton Load Center

Solar Ready Breaker Box with Optional Smart Upgrades

• EUSERC and Title 24 compliant designs

• Tin-plated copper bussing on all models for superior quality and connectivity

• 225A bussing for solar photovoltaic (PV) backfeed

• Optional Smart Breakers for remote monitoring, tripping and firmware updates

• Easy install allows for all wiring at rough-in with modular plug-on breaker design

Wesco Part No. Mfr.’s Model No.

Standard Smart Breaker

078477-18739

078477-18740

078477-18741

078477-18742

078477-18744

078477-18745

078477-18746

078477-18747

078477-18748

078477-18749

078477-18756

078477-18758

078477-18793

Description

LB115-ST 2nd Gen Standard 1-Pole Smart Breaker 15 Amp

LB120-ST 2nd Gen Standard 1-Pole Smart Breaker 20 Amp

LB125-ST 2nd Gen Standard 1-Pole Smart Breaker 25 Amp

LB130-ST 2nd Gen Standard 1-Pole Smart Breaker 30 Amp

LB215-ST 2nd Gen Standard 2-Pole Smart Breaker 15 Amp

LB220-ST 2nd Gen Standard 2-Pole Smart Breaker 20 Amp

LB225-ST 2nd Gen Standard 2-Pole Smart Breaker 25 Amp

LB230-ST 2nd Gen Standard 2-Pole Smart Breaker 30 Amp

LB235-ST 2nd Gen Standard 2-Pole Smart Breaker 35 Amp

LB240-ST 2nd Gen Standard 2-Pole Smart Breaker 40 Amp

LB245-ST 2nd Gen Standard 2-Pole Smart Breaker 45 Amp

LB250-ST 2nd Gen Standard 2-Pole Smart Breaker 50 Amp

LB260-ST 2nd Gen Standard 2-Pole Smart Breaker 60 Amp

Whole Home Energy Monitor

078477-87737

LWHEM-2

Provides Real-Time Energy Consumption Data in the My Leviton App and Controls Leviton Smart Breakers

Wesco Part No. Mfr.’s Model No. Description Smart Breaker Data Hub

078477-82288 LDATA Smart Breaker Data Hub

The LDATA Smart Hub collects data from smart circuit breakers and transmits it securely to the router.

Meter-Load Center Combination, All-in-One, Over-Under Construction, Semi-Flush Mount, UG/OH* Service Entrance, EUSERC

*Overhead feed requires Overhead Tunnel Kit accessory. **Max Inverter Input Breaker rating

Meter-Load Center Combination, All-in-One, Side-by-Side Construction, Surface Mount, UG Service Entrance, EUSERC

EV Charging Solutions

EV Charging Stations

• Compatible with all electric vehicle supply equipment codes standards and recommended practices, including SAE J1772™, NEC® 625, UL 2231, and UL 2594

• Applications include Residential, MDUs and Commercial

• Available with My Leviton Compatibility, allowing users to take control of the entire home, from load center to lighting to EV charger

• Equipped with RFID reader for user identification and access control

• Compact size and mounting bracket provides a hassle-free installation

• Safe, reliable charging with up to 19.2 kW of output

• Water-resistant enclosure is rated NEMA Type 3R for indoor and outdoor use

• Ground monitor interrupter circuit for safety

Wesco Part No. Mfr.’s Model No. Description

078477-01558

078477-02418

078477-87757

078477-87758

078477-99728

078477-87759

078477-33408

078477-33409

EV40P

EV48S-DP

EV320

EV32W

EV480

EV48W

EV800

EV80W

EV Charging Station

Wesco Part No.

078477-87761

078477-87762

078477-98558

078477-98559

078477-98560

Pedestals

EV Series Charging Station with optional RFID, 40 Amp, with WiFi, works with My Leviton App, Plug-In 208/240 VAC, 9.6 kW Output, 25' Cord, Includes Mounting Bracket and Pre-attached 3-ft. long input cable with NEMA 14-50P Plug, WiFi Compatible, PLUG-IN ONLY

EV Series Pro Dual Port Level 2 Electric Vehicle Charging Station, 48A, 208/240 VAC, 11.6 kW Output, J1772 Charge Connector, 25' Cord, Charging Station Management Software, Hardwired

EV Series Standard Level 2 Electric Vehicle Charging Station, 32 A, 208/240 VAC, 7.6kW Output, J1772 Charge Connector, 18' Cord, Replacement for EVR30-B1C and EVR30-R2C, Includes Mounting Bracket and Pre-Attached Input Cable, HARDWIRED ONLY

EV Series Smart Level 2 Electric Vehicle Charging Station, 32A, 208/240 VAC, 7.6kW Output, J1772 Charge Connector, 18' Cord, Includes Mounting Bracket and Pre-Attached Input Cable, Optional RFID Control, Wi-Fi Compatible (Wi-Fi Function 802.11 b/g/n), Replacement for EVR30-B1C and EVR30-R2C. HARDWIRED ONLY

EV Series Standard Level 2 Electric Vehicle Charging Station, 48A, 208/240 VAC, 11.6kW Output, J1772 Charge Connector, 18' Cord, Replacement for EVR40-B2C, Includes Mounting Bracket and Pre-Attached Input Cable, HARDWIRED ONLY

EV Series Smart Level 2 Electric Vehicle Charging Station, 48A, 208/240 VAC, 11.6kW Output, J1772 Charge Connector, 18' Cord, Includes Mounting Bracket and Pre-Attached Input Cable, Optional RFID Control, Wi-Fi Compatible (Wi-Fi Function 802.11 b/g/n), Replacement for EVR40-B2C. HARDWIRED ONLY

EV Series Standard Level 2 Electric Vehicle Charging Station, 80 A, 208/240 VAC, 19.2kW Output, J1772 Charge Connector, 18’ Cord, Station comes with 2 RFID Cards and 1 Admin Card, Includes Mounting Bracket and Pre-Attached Input Cable, HARDWIRED ONLY

EV Series Smart Level 2 Electric Vehicle Charging Station, 80A, 208/240 VAC, 19.2kW Output, J1772 Charge Connector, 18' Cord, Includes Mounting Bracket and Pre-Attached Input Cable, Optional RFID Control, Wi-Fi Compatible (Wi-Fi Function 802.11 b/g/n). HARDWIRED ONLY

Mfr.’s Model No. Description

EPED1 Single Mount Pedestal

EPED2 Dual Mount Pedestal, Front/Back

EPCM1-OF3 Pedestal Body for Dual Mount Charging Station Pedestal, Side/Side with Retractable Cord Management

EPCM2-OF3 Mounting Template for Dual Mount Charging Station Pedestal, Side/Side with Retractable Cord Management

EPCM3-OF3 Retractable Cord Management System for Dual Mount Charging Station Pedestal, Side/Side with Retractable Cord Management

EV Charging Accessories

Wesco Part No.

078477-00061

078477-01559

078477-01334

Mfr.’s Model No. Description

EBASE Direct-Bury Mounting Foundation for all Leviton Level 2 EV Charging Pedestal

NACSA NACS Adapter for SAE J1772 Electric Vehicle (EV) Charging Stations

1450R 50 Amp EV Charging Receptacle/Outlet, Heavy Duty

078477-01335 1450W 50 Amp EV Charging Receptacle/Outlet, Heavy Duty, Weather-Resistant

Renewables Guide

Stainless Steel Hex Head Lag Screw

Stainless steel lag screws are heavy-duty fasteners used to connect heavy lumber or other materials that bear a strenuous load. They are manufactured from 304 stainless steel and can be used with lag shields in a variety of masonry applications, such as concrete, brick and mortar. Stainless steel lag screws can also be used where standard wood screws are too short or small. In some applications, a pilot hole may be pre-drilled to prevent splitting or snapping.

• Gimlet point

• Heavy-duty 304 stainless steel

• Used with heavy lumber, wood, brick, concrete, and mortar

Slotted Hex Washer Head Concrete Screw Anchor

Concrete screws are tempered masonry screws designed for long-lasting performance and superior-holding strength. Due to their unique thread design, they are the ideal fastening solution for light to medium duty applications in concrete, brick, masonry block and wood base materials. They are manufactured with a gimlet point that taps its own threads while drilling into the base material. Common applications for this fastener include the attachment of electrical boxes, light fixtures and masonry base materials.

• Gimlet point

• Designed for close to edge fastening

• Strong grip

• Corrosion resistance

• Case hardened

• Can be loosened for adjustment or removal

Insulated Ground Bushing with Lay In Lug

Insulated ground bushings are used to fasten and ground threaded rigid conduit or IMC to an enclosure. They feature a zinc/aluminum body and a 90° copper/aluminum dual-rated lay in lug that is intended for grounding jumper to neutral bus bar.

• 194° F copper/aluminum dual-rated lay in lug

• 302° F rated nylon insulator

• Threaded connection

• UL Listed

Wing Conical Anchor Kit

Suitable for use in solid and hollow wall, concrete, block or brick applications. When used in hollow walls such as drywall or plywood, the wings will splay out to provide a more secure installation and higher pull-out load. The anchor has a lip to prevent falling into deep holes or hollow walls. For hard wall applications, use the size of the anchor to determine hole size for installation. For drywall or soft applications, it is recommended to use the smallest hole that will enable a tight fit for the anchor. These anchors are not recommended for use in overhead applications or where holding values are critical.

• Wings provide extra holding power in drywall

• Tapered

• Ribbed for increased grip strength

781002-59203

781002-29635

Conical Anchor Kit

(100) Tapered Wing Anchors, (100) #10 x 1" Phillips/Slotted Sheet Metal Screws, (1) 1/4" Carbide Tipped Masonry Drill Bit

Phillips/ Slotted Hex Washer (100) Tapered Wing Anchors, (100) #10 x 1 Hex/Phillips/Slotted Sheet Metal Screws, (1) 1/4" Carbide Tipped Masonry Drill Bit

(50) Tapered Wing Anchors, (50) #12 x 1-1/2" Phillips/Slotted Sheet Metal Screws, (1) 5/16" Carbide Tipped Masonry Drill Bit

Suitable for use in solid and hollow wall, concrete, block or brick applications. When used in hollow walls such as drywall or plywood, the wings will splay out to provide a more secure installation and higher pull-out load. The anchor has a lip to prevent falling into deep holes or hollow walls. For hard wall applications, use the size of the anchor to determine hole size for installation. For drywall or soft applications it is recommended to use the smallest hole that will enable a tight fit of the anchor. These anchors are not recommended for use in overhead applications or where holding values are critical.

• Tapered body

• Collar to prevent falling through base material

2AK

2AKHX 3AK

Renewables Guide

nVent Solutions for Battery Energy Storage Systems

As energy storage becomes increasingly vital in meeting the world’s growing energy demands, nVent’s range of innovative products offers enhanced performance, safety and reliability of utilityscale energy storage systems. nVent has products that easily integrate into battery racks, power converters and inverters and provide the connection between the container and the power grid.

Resiliency and Protection

Battery Energy Storage System

Lifespan and Serviceability

Customer Productivity

nVent ERIFLEX Compact Power Distribution System, including Flexibar, IBSB Braids, Power Distribution Blocks, Busbar Support Systems and Insulators.

nVent ERICO Grounding, equipotential bonding, surge protection and lightning protection solutions — safeguard your technology from impulses generated internally and externally.

nVent HOFFMAN Enclosures, Climate Control Solutions and Accessories provides ultimate protection and reliability for all energy storage applications.

nVent ILSCO SureCrimp Compression Systems — copper and aluminum compression connectors (lugs and sleeves), dies and hydraulic crimping tools.

nVent ERIFLEX FleXbus — Innovative solution for connecting critical electric components: transformers, switchboards, generators and UPS. Use for applications from 500A to 6300A.

nVent CADDY Pyramid Support Solutions

Flexibar Advanced Flexible Busbar

• From 125 A to more than 2800 A at 1000 VAC/1500 VDC

• IEC/UL compliant flexible busbar made of tinned copper laminates covered with an insulation that is:

– Reinforced per IEC 61439-1

– Available in standard sizes or made-toorder configurations

– Low smoke, halogen-free and flameretardant insulation

– Direct connection for easy installation

– Low profile, light weight and flexible

Power and Distribution Blocks

• A complete range up to 1940 A as per IEC or 1680 A as per UL

• IP20 compact solution for distributing power with direct connection of the input/output cables (no lug needed)

• IEC 60947-7-1 tested (incl. short circuit)

• Significant space- and labor-saving solution

Made-to-Order Engineering Solutions

We deliver power distribution solutions that reduce total installed cost and increase design flexibility by providing a comprehensive range of innovative and reliable products through global end user application expertise and intimacy.

ERIFLEX FleXbus System

• Provides a patented connection solution between two pieces of electrical equipment

Grounding Strap for Indoor/Outdoor with MBJ & CPI

• Labor saving

• Greater reliability

• Vibration testing per ISO 6469-1:2019

Grounding Connectors

• Exothermic: nVent ERICO Cadweld exothermically welded connections are engineered to provide a permanent, molecular bond that will not loosen or corrode. The connections are designed to maintain for the life of the conductor and/or installation

• With reliable connections that consistently exceeded IEEE® 837 2014 EMF test requirements as certified by an independent lab, nVent ERICO Cadweld is the ultimate welded connection

• Mechanical Connectors: Building a reliable grounding and bonding system requires quality components. Connecting your system correctly by using nVent ERICO products gives you peace of mind and assurance that you are choosing products backed by years of engineering expertise and real-world use

nVent ERIFLEX has the products and engineering support you need to specify and build a complete range of solutions for industries like: energy, transportation, construction and other applications where low voltage power storage and transmission are critical.

Standard/Customized Grounding Busbar Solution

Proper bonding is essential to create an equipotential plane between service grounds and equipment during fault and transient conditions.

• Provides a convenient, singlepoint grounding and bonding location

• Custom bars can be designed and manufactured to customer specifications

Ground Rods and

Grounding Couplers

Ground rods offer a complete line of ground rods and accessories to accommodate various types of customer requests. From our industry-leading copper-bonded ground rods to solid copper rods, stainless steel rods or galvanized rods, nVent ERICO has the ground rod solution you can depend on.

• Offers faster installation and reduces total installation cost

• Use for applications from 500 A to 6300 A.

Reliable protection of battery energy storage operations and personnel demands a systematic and comprehensive approach to minimizing threats caused by transients, from the ground up.

Theft-Deterrent Grounding Solutions

Theft-deterrent composite cables (TDCC) are conductors that function as copper conductors, but incorporate an outer steel layer and are difficult to cut and steal. These conductors are ideal for exposed electrical grounding leads where copper theft may occur. Theft-deterrent conductors are difficult to cut with hand tools and the outer steel stranding is magnetic, which further deters thieves looking for copper.

Surge Protection Devices

nVent surge protective devices work together to create a coordinated defense. Safeguard your technology from impulses generated internally and externally with systems designed to provide primary and secondary protection at distribution panels and the point of use.

nVent

Renewables Guide

CSWS-500-12

CT-1/0

TB-6DF1000-P

nVent ILSCO SureCrimp Compression Connectors

• Specification grade quality for mission critical jobs

• Tested with nVent ILSCO and other major manufacturer’s compression tools

• 10-year industry best connection guarantee when used with nVent ILSCO Tools and Dies

• UL Listed and CSA Certified for power applications

Additional Copper-Only Features

• Approved for eight classes of conductor (flex & code) for increased versatility

• UL Listed and CSA Certified for grounding and bonding applications

• NEBS Level 3 Certified for data and communications applications

nVent ILSCO TaskMaster Battery-Powered Crimping Tools

• 5-year tool warranty ensures confidence for durability & quality

• 18 V, 5.0 Ah Milwaukee Li-ion battery with 3-year warranty provides longevity in battery life

• Tools accept all industry standard “W” or “U” type dies

• Brush protection on tool head protects against accidental contact with energized conductors

• Auto retract when tonnage is achieved to confirm a complete crimp

• USB-port for connectivity (inline tools) captures output data for performance and service

• Interchangeable heads with O, BG, D3 or no die (inline tools) provides application versatility

nVent ILSCO SureCrimp System Guarantee

Universal Free-Stand Enclosures

10-Year Warranty: Connections made with nVent

ILSCO TaskMaster Tool, nVent ILSCO Die and nVent

ILSCO SureCrimp Connector

Six base enclosures with Universal type ratings 4, 4x, 12, 4R, IP66 and IK10 can be configured to meet customers’ large enclosure needs. We provide wireless and wireline protection such as advanced cabinet architecture, cooling, surge suppression and cable/copper/ fiber management for high-density equipment environments.

SpectraCool Climate Control solutions

Many of our solar connectors carry UL 2703 Certification for grounding and bonding on solar racking systems.

Features & Benefits

• Set of three (3) dies that allows for crimping up to 1000 kcmil connectors using the 12-ton (10.8-metric-ton) die-taking crimp tool

• No need to purchase separate adapters or an additional tool to crimp complete range of sizes

• Replaces a standard set of more than 30 U-dies, saving time swapping between die sets on the job

Easily separate voltage with barriers panels, false floor and Sequestr for disconnect isolation and cable protection. Heavy gauge welded steel frame with six rack angle mounting struts are ideal for use in high-vibration areas or areas with high load capacities. The cabinet’s passive cooling design can be augmented with optional fans.

SpectraCool Standard Series Air Conditioners are designed for robust cooling performance in demanding indoor and harsh outdoor environments. Rotary compressors provide more energy efficiency than reciprocating compressors, and allow quick re-start under pressure without causing damage. Dual impellers on G52 and G57 units pull air into the front of the unit and direct the air upwards in a 90° angle for the most direct air path while providing redundancy.

Go-to global provider for tailored customer specified protection solutions — delivering value by providing industryleading application-based innovation and intimate support and services.

Advantages for Energy Storage Solutions

• Only supplier to offer extensive standard, modified, co-developed and custom capabilities

• Industry-specific solutions:

• Custom wellhead or process control panels

• Internal barriers, hubs and reservoirs

• Purge systems

• Switchgear control enclosures

• Arc flash safety systems

• DCS control

• In-house UL, CSA, NEMA, CE and IEC certified solutions: Type 4, 4X, 9, 12 and more

• Rapid response to engineering requests and modifications

TB-6WO500-I

nVent ILSCO Dino Dies

Solar Energy Solutions

Organize, connect and protect wires and cables throughout your solar project with Panduit components backed by a 20-year warranty.

Solar Wire Hanger

Hang and fill convenience for strong bundles.

Wesco Part No. Mfr.’s

613056-84521

613056-87814

WH10SS-C 1" Stainless Steel Wire Hanger

WH20SS-90-M 2" Stainless Steel Wire Hanger

Fully Coated Stainless Cable Ties

Coined edges make these ties easy to handle.

Wesco Part No.

613056-10854

613056-10876

613056-10877

613056-10860

613056-10878

613056-10865

Mfr.’s Model No. Description

IMLTFC51S-C6L Stronghold Self-Locking Fully Coated Stainless Steel Tie 7.9"; Coined Edge

IMLTFC64S-C6L Stronghold Self-Locking Fully Coated Stainless Steel Tie 9.4"; Coined Edge

IMLTFC86S-C6L

IMLTFC102S-C6L

Stronghold Self-Locking Fully Coated Stainless Steel Tie 12"; Coined Edge

Stronghold Self-Locking Fully Coated Stainless Steel Tie 14.3"; Coined Edge

IMLTFC137S-C6L Stronghold Self-Locking Fully Coated Stainless Steel Tie 18.2"; Coined Edge

Nylon 612 Cable Ties

The best plastic cable ties for solar, backed by a 20-year warranty.

IMLTFC152S-C6L Stronghold Self-Locking Fully Coated Stainless Steel Tie 20.5"; Coined Edge Wesco

613056-84513

UV/Weather-Resistant Cable Ties

Hardworking, dependable, UV resistant nylon 6.6 cable ties.

074983-54079

074983-54094

074983-41272

074983-41278

Plastic Edge Clips

Push on clip is fast, flexible, and tool free.

Corrugated Loom Tube

UV resistant protection for string bundles.

613056-85245

613056-85246

Loom Tubing

Loom Tubing

Renewables Guide

Solar Energy Solutions

Organize, connect and protect wires and cables throughout your solar project with Panduit components backed by a 20-year warranty.

Grounding and Bonding

Innovative compression grounding solutions that work in all weather (additional sizes available).

Wesco Part No.

613056-87853

074983-39064

613056-89299

613056-83991

Mfr.’s Model No. Description

LICC4-22TP-TL Tin-Plated Copper Lay-In-Lug, One-Hole, #12 Stud, 14–4 AWG

LIAC4-22-C Tin-Plated Aluminum Lay-In-Lug, One-Hole, #12 Stud, 14–4 AWG

LIAS4-Q Tin-Plated Lay-In-Lug, No Drill, 14–4AWG

CTAPR2-2-L Compression Ground Connector Tap, Copper, Main: 6 STR–2 STR, TAP: 6 STR–2 STR 613056-83977

CTAPR250-250-L Compression Ground Connector Tap, Copper, Main: 3/0 STR–250kcmil, Tap: 3/0 STR–250kcmil 613056-85452

GCE250-250-Q E-Style Grounding Connector, Copper, 1/0 STR–250kcmil

Power Connectors

Reliable compression lugs for copper and aluminum conductors (additional sizes/configurations available)

Wesco Part No.

074983-97204

074983-97207

074983-90088

Mfr.’s

LCA10-10-L

Tin-Plated Copper Compression Lug, One-Hole, Standard Barrel, One #10 Stud, 10 AWG Conductor Size

LCA10-14-L Tin-Plated Copper Compression Lug, One-Hole, Standard Barrel, One 1/4" Stud, 10 AWG Conductor Size

LCA8-38-L

Tin-Plated Copper Compression Lug, One-Hole, Standard Barrel, One 3/8" Stud, 8 AWG Conductor Size 074983-90087

LCA8-56-L

Tin-Plated Copper Compression Lug, One-Hole, Standard Barrel, One 5/16" Stud, 6 AWG Conductor Size 074983-90140

613056-85773

613056-85778

613056-85788

LCB4/0-12-X

LAA1/0-38-L

LAA2/0-38-40

LAA4/0-12-30

Tin-Plated Copper Compression Lug, One-Hole, Long Barrel, One 1/2" Stud, 4/0 AWG Conductor Size

Tin-Plated Aluminum Compression Lug, 1/0 AWG, One-Hole, 3/8" Stud

Tin-Plated Aluminum Compression Lug, 2/0 AWG, One-Hole, 3/8" Stud

Tin-Plated Aluminum Compression Lug, 4/0 AWG, One-Hole, 1/2" Stud 613056-85781

LAA250-12-E

613056-85802

613056-85804

613056-85805

613056-85807

Solar Labels

Tin-Plated Aluminum Compression Lug, 250 kcmil, One-Hole, 1/2" Stud

LAB350-12-XR Tin-Plated Aluminum Compression Lug, 350 kcmil, Two-Hole, 1/2" Stud

LAB400-12-24 Tin-Plated Aluminum Compression Lug, 400 kcmil, Two-Hole, 1/2" Stud

LAB500-12-24R Tin-Plated Aluminum Compression Lug, 500 kcmil, Two-Hole, 1/2" Stud

LAB750-12-24R Tin-Plated Aluminum Compression Lug, 750 kcmil, Two-Hole, 1/2" Stud

Peel and stick pre-printed solar labels in convenient 50 packs (32 types available).

613056-87518

613056-87520

613056-87515

613056-87535

PPS0106BRDSC-L Solar Label “DC Photovoltaic Source Circuit”

PPS0106BRMSD-L Solar Label “Main Photovoltaic System Disconnect”

PPS0106WRPS-L Solar Label Warning Header “Photovoltaic Power Source”

PPS0204WL5-L Solar Label Warning Header “Electrical Shock Hazard” 613056-87527

PPS0204BLASM-L Solar Label AC Solar Module “Nominal Operating AC Volatge”

Build Solar Better 20-Year Warranty

Panduit’s best-in-class 20-year warranty covers a wide range of cable management solutions for critical parts of the DC distribution system, so you — and your client — can feel confident of long-term performance.

Simplify Solar Bill of Materials

Let Panduit and Wesco create your next solar BOM proposal — at no charge. Panduit’s Technical Solutions Engineers will review your project drawings and suggest the right cable management, power, grounding and identification products, with pricing, quantities and all supporting documents.

World-Class Supply Chain Solutions

The first step in designing the right supply chain solution is an initial meeting with the Wesco team to assess your needs. We will lead the process, define the opportunities and coordinate

key activities from our extensive array of products and services to build a program that addresses your specific requirements.

How Wesco Creates Value for You

Identify Needs: Wesco and the customer meet to identify what the customer needs to help streamline its supply chain, alleviate pain points, reduce costs or increase productivity.

Align Solutions: Wesco’s solution experts review all of the customer’s requirements and align them with the solutions.

Propose and Refine: Wesco shares a proposal for a solution designed specifically for the customer’s needs. Wesco and the customer work together to refine the proposed solution.

Customize and Implement: Wesco solution experts design and implement customized solutions to meet the customer’s needs and deliver value.

Expertise Wherever You Operate

•

•

•

•

•

U.S. and Canada

CALA

EMEA

APAC
