Preface
The Internet of Things (IoT) and artificial intelligence (AI) are without a doubt the most important technology topics of the near future. As the world undergoes Digital Transformation (DX), the Internet data collection through IoT is becoming the norm, and an era of massive time series data accumulation is about to begin. Furthermore, modeling technology will no longer be able to keep up with manually in extracting relevant information from the large ocean of time series data. AI modeling will be an inevitable core technology of the DX era.
Most image recognition, which is a representative of AI technology, can be said to be static modeling that does not depend on past history, but the time series data accumulated by DX can be said to be dynamic modeling in which the appearance of values changes with past history. Long short-term memory (LSTM), a neural network specialized for time series data, has been attracting attention as a neural network that is good at prediction depending on the history of time series data, and its tools are now readily available.
Since time series AI modeling is a sophisticated predictor that deals with history, it is difficult for beginners to understand the learning theory and effective training data collection techniques. For example, even if you study the theory and collect time series data to test it in your own work, you will face problems such as obtaining only biased training data or not being able to determine realistic convergence conditions.
However, there seem to be two extremes in the world: theoretical books with only mathematical formulas, or how-to books on tools. For graduate students in university laboratories and front-line engineers in the industrial world, there is a need for specialized books that serve as a “bridge” by describing the development of practical models based on theory.
In each chapter of this book, a structure is adopted that has never been seen before: a section that presents the basic theory in mathematical form, followed by a section that presents practical applications of the theory. In other words, the emphasis is on showing concrete examples of the application of the basic algorithms in the field of system control immediately after understanding them mathematically. By doing so, the author aimed to take a different approach from mathematical books that develop theories in an abstract manner by deriving pure mathematical formulas and from
how-to books that only describe how to input and output data to off-the-shelf tools without describing theories.
In general, examples of AI machine learning may appear to be handled well, but there may be cases where the reliability is not guaranteed. Therefore, all the examples in this book were selected from peer-reviewed papers by IEEJ, IEEE, and other experts to ensure reliability.
The structure of this book is as follows.
Chapter 1 begins with the definition of “time series” in system control and describes the position of control design modeling from time series data of physical quantities of interest.
Chapter 2 presents the basic theory of linear multiple regression modeling and autoregressive (AR) modeling as the most fundamental methods in time series data modeling and their practical applications.
Chapter 3 describes the basic theory of neural network modeling of dynamic characteristics of control targets as a representative of AI machine learning modeling with time series data and its application to modeling of step response characteristics.
Chapter 4 presents the theory of long short-term memory (LSTM) neural networks, which have attracted attention in recent years as a method for modeling control targets whose subsequent behavior differs depending on the time series history, and an example of a prediction model for sudden events in control as an application of the theory.
Chapter 5 describes the theory and examples of heuristic optimal search control as optimal control using the above time series AI model.
Chapter 6 describes a practical method for collecting time series data in the field of system control design, including a method for correcting collected data bias and a method for estimating training data from normal operation data.
Chapter 7 describes a practical method for implementing the methods described in the above chapters: a time series data collection platform, a method for extracting zones of interest from field-collected data, and self-developed machine learning software.
I would like to express my gratitude to many people for their help in compiling this book. Morio Takahama, former professor at Nagoya University, as an expert in control engineering, and Satoru Hayamizu, former professor at Gifu University, as an expert in AI, provided valuable comments on the manuscript. Former Assistant Professor Shun Matsukawa of Ninagawa Laboratory, Gifu University, and current Lecturer at Hokkaido University of Science, helped to confirm the mathematical expressions. Of course, I am grateful to Assistant Professor Yoshifumi Aoki, Ph.D. student Asif Iqbal, and other members of the Ninagawa Laboratory at Gifu University for their research. I would like to express my gratitude to all of them. Finally, I would like to thank my wife for allowing me to write this book at home for a long time.
Gifu, Japan Chuzo Ninagawa
4.4
5.2
4.4.4
5.4
5.2.1
5.4.1
7.3.1
About the Author
Prof. Chuzo Ninagawa is CEO of N Laboratory, Inc., and Professor of Smart Grid Power Control Engineering Joint Research Laboratory¸ Gifu University, Gifu, Japan. He has been Executive Chief Engineer of Mitsubishi Heavy Industries, Ltd., which is one of the largest hi-tech manufacturers in Japan. His research interests span various topics of smart grid, with special focus on virtual power plant (VPP) with a largescale aggregation of fast automated demand responses. He has published over 110 academic papers and five advanced research books.
Chapter 1 Introduction
Abstract This chapter begins with the definition of “time series” in system control and describes the position of control design modeling from time series data of physical quantities of interest. Statistical modeling approach is introduced as a black box modeling on the control system target. Then, the concept of machine learning modeling approach will be introduced.
Keywords Time series data · White box model · Black box model · Autoregressive model · Machine learning
1.1 Time Series
1.1.1 What is “Time Series” Dealt in This Book?
This book describes the practical application of artificial intelligence (AI) methods using time series data in system control. It consistently discusses the application of machine learning to the analysis and modeling of time series data of physical quantities to be controlled in the field of system control.
In the field of system control, a time series is a sequence of physical quantity data arranged in time order at fixed time intervals. Although it is not absolutely necessary to have a fixed time interval, virtually any data sequence with a fixed time interval is called a time series from the standpoint of mathematical handling and practical data organization. Depending on the time scale of the physical quantity of interest, the interval may be one microsecond or one hour. In any case, this book implicitly refers to them as fixed time interval time series.
In recent years, the term “time series” has often been used in the field of information science, especially in the field of AI, to refer to the order of appearance of words and scenes in language processing and video processing. In contrast to control, the term “time series” is used in situations such as word order and image transition. These are different from time series in system control and are outside the scope of this book.
The purpose of this book in discussing time series in system control is to predict and manipulate the target physical quantity based on its history. A dynamic system
is a system in which the subsequent change in the physical quantity to be controlled depends on the time series of the state physical quantity that determines the state.
Dynamic systems exhibit physical phenomena in which the transient characteristics are problematic as well as the steady-state characteristics. Transients are problematic because they are affected by the system state before and after the change occurs. The control target of this book is a system in which it is essentially important to handle the time history, or time series, of the physical quantities that determine the response behavior of the system state.
In addition, when dealing with time series for control, it is interesting to consider target systems in which each physical quantity that constitutes the time series data has a stochastic value.
In real-world control, even in systems where there is no uncertainty in the target itself, it is natural for the observed data of the controlled quantity to be noisy, and the actual manipulated physical quantity will naturally contain errors relative to the calculated value of the manipulated quantity. However, the subject of interest to control engineers is not merely such uncertainty in observations and operations, but dynamic systems dominated by intrinsic stochastic phenomena.
1.1.2 Time Series for Statistical Control
Naturally, if the time series of the past state history of a dynamic system is different, the transient response output, or the change in the controlled quantity, will be different even if the current input, or the amount of operation, is exactly the same. In addition, even if the time series of the state history and the input at the present time are exactly the same, there are dynamic systems with uncertain intrinsic behavior, i.e., statistical elements, depending on the target system. This book concentrates on statistical dynamic systems with inherent uncertainty.
The uncertain behavior of such statistical dynamic systems cannot be easily taken into account by the deterministic control theory that has been widely used so far. In recent years, research results in control theory have led to the development of advanced mathematical methods that can deal with uncertain control targets. However, it must be said that these methods are too difficult for engineers in the field who are involved in the control of embedded systems.
Such inherently uncertain dynamic systems may include the following. An example of a statistical dynamic system is the prediction of the path of a typhoon. The purpose of these systems is not to manipulate the system itself, but to quantitatively estimate the transient changes in the future based on the past history of state. Load frequency control, which targets each power plant from the power system’s central power supply command center, is an example of statistical dynamic system control. In these systems, prediction alone is not enough to solve the problem; it is necessary to feed back the observed values and perform control operations to output the operational quantities. However, the system frequency, which is the controlled quantity, cannot be completely controlled due to the inherent uncertainty, or statistical factor,
of the control target, and the rate of stay of the controlled quantity in the target region is to be kept within a practical range.
This section will review the target physical quantities, which are the controlled quantity, the operating quantity, and the state variable in the statistical dynamic system treated in this book. The physical quantities here are the quantities that determine the behavior of the target system, specifically, the properties governed by the physical laws of natural science, such as temperature, voltage, and velocity. These elements are called “physical control elements” in this book.
Next, we consider factors that are not “physically controlled” but are caused by social factors. In general society, the word “control” is used to describe managerial behavior toward highly uncertain phenomena. The word “infection control” for a novel coronavirus, for example, is not the same as the restrictive definition of control engineering. The term “control” seems to be closer to “management,” but the reason to use the term “control” is that it involves some kind of feedback and manipulation to approach a desired state. Naturally, these inherently uncertain elements are separate from the laws of physics, such as the psychology of human behavior. These elements are called “uncertain control elements.”
The control of statistical dynamic systems in this book deals with objects that have both of the above elements. In other words, it deals with a very interesting system control that combines two elements, one dealing with industrial physical quantities and the other dealing with social uncertainties.
Although there are many aspects of complex system control consisting of uncertain social and industrial systems that do not conform to the mathematical precision of automatic control engineering, the controller outputs an operational quantity based on the observed physical quantity of the dynamic system, and an uncertain response is returned. Uncertainty management control, which increases the probability that the controlled quantity will be in the desired range, is much needed in the real world.
In general, it must be said that automatic control theory as an academic discipline has been extremely difficult to handle dynamic systems with uncertain responses, although it makes full use of advanced mathematical theory. It is felt that a practical method for managing and controlling a control target with such uncertain behavior has not been accessible.
The topic of statistical extraction of “uncertainty control features” from time series data is addressed, which has been increasingly popular in recent years, as one of the answers in this book.
1.1.3 Dissemination of Time Series Data for Control
Now, let us discuss the history of time series data. Before the spread of digital computers as we know them today, data to be controlled in system control was often treated as analog quantities. In measurement and recording devices called pen recorders, physical quantities measured by sensors were converted directly into pendriven electrical signals and recorded as curves on paper fed from a roll. It can be
said that it is a kind of continuous measurement and recording of the time history of physical quantities.
Microprocessors, or microcomputers, were introduced to the world around 1970. It quickly developed and spread to the stage where it was called a personal computer around 1980. Since then, microprocessors and personal computers have been actively used in the measurement and recording of physical quantities for system control. These digital computers became the norm, and pen recorders became extinct. In the field of system control, measurement and recording came to be handled as digital data in the form of discrete numbers. As a natural progression, it became common to record discrete numerical values at fixed time intervals, and time series data became the basic method of recording the time history, time changes, and transient phenomena of physical quantities to be controlled.
Since around 1980, with the spread of microcomputers, a large number of devices and systems in society have come to be controlled by embedded systems. However, at that time, the embedded control of various equipment systems was developed within the equipment itself, and there were few systems that continuously communicated operation data to the outside for a long period of time. From around 2000, remote centralized control of equipment systems began to be used, and cases where data on equipment behavior was accumulated as a time series gradually appeared.
In addition, the Internet of things (IoT) communication network has become widespread since around 2010, and it has become possible to accumulate time series data on the behavior of embedded control systems on the things side of the IoT easily and at low cost. On the Internet side of the IoT, the cloud centralized monitoring and control side constantly collects time series data from many things side.
In this way, we are living in an era in which time series data on the behavior of a huge variety of devices is constantly being collected and stored in data centers at a short-time granularity through the IoT, and it seems that time series data is now regarded as a natural resource that is collected and stored even without saying anything.
As well as, we are living in an era where it is normal to collect and accumulate time series data on the behavior of control targets. It is becoming more and more important for engineers in the field to effectively use this vast amount of accumulated time series data for system control design, especially for modeling the control target.
1.2 Time Series and Control Models
1.2.1 Control Modeling
In the field of system control, a model is a representation of the dynamic characteristics of a system in a specific form, focusing on the essential parts from the perspective of control. This is too abstract, so let us consider it more concretely from the viewpoint of system control.
Since the actual object operates in the real world, various aspects of it operate in a complex and uncertain manner. However, among these behaviors, only a limited number of essential characteristics are necessary for a control system. The important point here is that only those features of the real thing that are necessary for control need to match. In other words, the model used in system control does not need to perfectly reproduce all the behavioral actions of the real thing to be controlled.
However, it is still not easy to capture and describe the dynamic behavior. Except for extremely simple dynamic models of quality point systems, when constructing a valuable control system in the real world, it is usually very difficult to describe the dynamic characteristics instead of the static characteristics when the system is a little complex.
Advanced control theories such as modern control theory have been studied, but even after several decades, they do not seem to be widely used in industry, especially in the field of embedded control.
The mathematical representation of a control target as a state space is not so common among engineers in the field of embedded control systems. Basically, the state-space representation needs to be in the form of differential equations or difference equations that determine the dynamic characteristics of the control target. It can be limited to the case when the physical laws governing the dynamic characteristics of interest in the behavior of the control target are known if it can be represented by such differential equations. This is not an easy task in the real world.
On the other hand, as mentioned in the previous section, with the recent spread of IoT, it has become very easy to collect and accumulate time series data of physical quantities to be controlled. In some cases, the time series data may already exist somewhere before the control system is designed.
In the field of system control design in industry, it is much more convenient to express the dynamic characteristics of a control target using already existing time series data than to express them in state space.
1.2.2 Control Model Building Methods
There are two main approaches to obtaining a control target model: the white box approach and the black box approach. The white box approach models the dynamic behavior of the control target using differential equations based on physical laws. This modeling method is also called first principle modeling or physical modeling and has long occupied a central position in system control as an orthodox approach.
If the target system has simple behavior and shows definite actions, it can be modeled by control engineers in the field using the white box approach. One of the advantages of the white box approach is that it is suitable for understanding the cause-effect relationship and the mechanism of the behavioral analysis, since it is modeled based on physical laws.
In many cases, white box modeling is limited to linear mathematical methods such as transfer functions and state-space representations. Therefore, it is necessary
to pay attention to the target system with strong nonlinearity. Specifically, nonlinear behaviors such as the ineffectiveness of the gravitational combination theory and the fact that a constant-fold change in the input variable is far outside the constant-fold in the output. This is a major difficulty in designing controller algorithms.
Of course, as widely known, a linear physical model based on a white box approach can be used in practical applications by limiting the behavior to small signals around a steady state or by dynamically adapting the parameters. The essential difficulty of the white box approach may rather be in modeling uncertainty.
On the other hand, the black box approach is a modeling method based on experimental data. In this method, the control target is regarded as a black box, and a dynamic model is obtained from its input/output data and state variable data using statistical methods.
In the field of control engineering, the term “system identification” means a black box approach to obtain a mathematical expression by statistically extracting the dynamic characteristics based on the time series data of the control target.
The advantage of this approach is that a statistical approximation model, although not an exact solution, can be obtained if a certain number of samples of experimental data are available, even when it is virtually impossible to represent the system with differential and difference equations based on physical laws in a complex system. In the past, it was often expensive to obtain time series data with a sufficiently fine temporal granularity and a sufficient number of samples. However, in recent years, with the easy and inexpensive acquisition of time series data by IoT via the Internet, the black box approach of system identification has been reconsidered.
This book uses both the physical model, which is a white box approach, and the system identification, which is a black box approach. For example, in the heat load model of a building multi-type air-conditioner, a physical model based on the differential equation of the heat balance between the building and the air-conditioner is used, and the change in the instantaneous power of the customer’s equipment from the viewpoint of the power system uses a statistical model, black box approach, identified from the time series of experimental data.
1.3 Control Time Series and AI Methods
1.3.1
Control Model by Time Series Analysis
The method of obtaining a control target model for system control design from time series data started in the 1970s.
In the past, time series analysis was often performed by decomposing the fluctuations of a time series into a discretized frequency domain. However, since the 1970s, an autoregressive modeling method has been established that directly converts the time series data into a dynamic model using the amount of information as a criterion [1, 2].
Autoregressive models are called autoregressive (AR) models. The multidimensional ones are called vector AR (VRA) models. Various derivatives of the AR model have also been proposed, such as AR moving average (ARMA).
The AR model alone cannot be used for the design of control systems based on modern control theory; it must be transformed into a state-space representation. A method to derive a discrete state-space representation from time series data via AR model has been studied.
The methods described so far for obtaining AR models and state-space representation models from time series data are all linear models. In many cases, the linear model is sufficient for control of a small signal range. However, depending on the control target, the model may not be sufficient in many cases where the dynamic characteristics are highly nonlinear or where the uncertainty of the statistical dynamic system is large.
From the latter half of the twentieth century until about 2010, nonlinearity and uncertainty were studied and devised in the field of control engineering. However, it has become too difficult for designers of embedded systems to use them in their products. An approach has emerged to obtain a dynamic model of a control target with nonlinearity and uncertainty in a black box manner as long as there is a sufficient amount of behavioral data.
There has been a trend to apply the results of AI to control from roughly 2010, with the rapid growth of artificial intelligence (AI) [3–5].
1.3.2 Control and AI Methods
In recent years, there has been a trend in control model building methods that has dramatically changed the situation. The combination of time series analysis and AI modeling methods is what the author wanted to write about in this book.
The time series data treated in this book is those that have at least a factor of uncertainty, fluctuation, or periodicity in the data sequence. From the author’s point of view, machine learning, an AI method, is essentially a statistical modeling engineering from a large amount of training data. It can also be interpreted as engineering to extract average characteristics rather than exact relationships between the realized values of each sample of a large amount of training data.
The difference between conventional analysis and modeling methods and AI machine learning, however, is that the former gives the algorithm for extracting characteristics for each application problem as a program, while the latter only gives the generic strategy for extracting characteristics in general terms and does not explicitly show the specific procedure for acquiring characteristics in the programming code.
The field of AI is very broad, ranging from pure science that approaches the activities of the human brain to practical applications in system control, which is the subject of this book. The author feels that the terms “intelligence” and “learning” are overused in control applications. It would be better to call it statistical engineering or data engineering.
The application of AI methods to system control seems to have become quite common in the past few years. Although there are various AI methods that can be applied to system control, the range of AI methods applied to machine control systems in this book has so far been quite limited. In a nutshell, they are mainly machine learning methods.
Then, why is there an incentive to use AI machine learning to analyze time series data in system control? As mentioned above, the essence of system control is to predict and manipulate the dynamic behavior of the target system. Systems with dynamic behaviors are called dynamic systems. Dynamic systems require the description of transient phenomena, and the theory of system control is basically based on differential or difference equations that describe the changes in the system. Since dynamic systems are not stable steady states but changing transient states, the changing transient states depend on the state history before the change. In other words, it is essential to predict the change from the present to the future based on the time history of each variable in the target system and to manipulate the system to achieve the desired change.
Rather than scientifically approaching the essence of human brain activity, machine learning, which is an AI method used in system control, uses the operation history of the target system as training data or the history of operation attempts on the target system as non-training data. In other words, the time series data of the target system is linked to the understanding and prediction of the system dynamics, and eventually to its operation.
In short, time series is the key to the application of AI machine learning to system control. In a nutshell, the philosophy of this book is: “time series data” + “AI machine learning” = “new practical control methods.”
