Hughes Hall Adaptive Reuse - Spring 2024

April 16th, 2024

Devon Duch, Sam Ferguson

Arch 7420 Advanced Architecture Design 2, Spring 2024

Final Review

Arch 7420 Advanced Architecture Design 2, Spring 2024 Devon

Duch, Sam Ferguson

The Oval Arts District

Final Review

Devon Duch, Sam Ferguson

Arch 7420 Advanced Architecture Design 2, Spring 2024

Southeast Axon

Southwest Axon

Axon

Final Review

Relationship between existing and addition

Devon Duch, Sam Ferguson

Arch 7420 Advanced Architecture Design 2, Spring 2024

Atrium

Existing Hughes Hall

Double-Skin Library Facade Entry

Existing Hughes Hall

Double-Skin Library Facade

Lecture Hall Addition Entry

Northeast View Southwest View

Final Review

Elevations

Arch 7420 Advanced Architecture Design 2, Spring 2024

Devon Duch, Sam Ferguson

East Elevation

Final Review

Elevations

Arch 7420 Advanced Architecture Design 2, Spring 2024

Devon Duch, Sam Ferguson

West Elevation

Final Review

Elevations

Arch 7420 Advanced Architecture Design 2, Spring 2024

Devon Duch, Sam Ferguson

South Elevation

North Elevation

Final Review

Relationship between existing and addition

Arch 7420 Advanced Architecture Design 2, Spring 2024

Devon Duch, Sam Ferguson

East Elevation

South Elevation

Structural System

W12”)

(12” x 12”)

(18” x 18”) New Columns (18” x 18”)

Existing Columns (16” x 16”)

W12”) New Truss Elements (D18”, W12”) New

Bracing

(12” x 12”) New Beam Elements (D36”, W12”)

W12”)

Final Review

Structural System

Devon Duch, Sam Ferguson

Floor Plans - Basement and Ground Level

Final Review

Sections

Arch 7420 Advanced Architecture Design 2, Spring 2024

Devon Duch, Sam Ferguson

Final Review

Sections

Arch 7420 Advanced Architecture Design 2, Spring 2024

Devon Duch, Sam Ferguson

Final Review

Envelope Strategy / Environmental Systems

Devon Duch, Sam Ferguson

Arch 7420 Advanced Architecture Design 2, Spring 2024

Southeast Axon

Envelope Stategy

Envelope Section

Final Review

Envelope Strategy / Environmental Systems

Devon Duch, Sam Ferguson

Arch 7420 Advanced Architecture Design 2, Spring 2024

Diagram of Small, Medium and Large Spaces Adjacent to Operable System

Envelope Stategy

Final Review

Envelope Strategy / Environmental Systems

Devon Duch, Sam Ferguson

Arch 7420 Advanced Architecture Design 2, Spring 2024

Small Group Study Space with Operable Facade

Envelope Stategy
