CONTENTS

THISISSUE... P6

P26 THE ROLE OF WOOD IN HEALTHY BUILDINGS

Health and wellbeing is an umbrella term that refers to the indistinct categories of physical, mental and social health. Timber can potentially improve all three, TRADA’s Rupert Scott explains more.

COVER STORY - CUNDALL Barney Jordan, Structural Engineering Partner at multidisciplinary engineering firm, Cundall, discusses the triumph of timber in musical education and how the award-winning King’s College School, Wimbledon’s state-of-the-art new music school is an achievement of client vision, innovative architecture and structural design.

P28 COMPETENCY IS CRUCIAL IN ACHIEVING FIRE SAFETY

Andrew Orriss, Director of STA Assure for the Structural Timber Association (STA) outlines the many ways to mitigate risk in timber construction and the role of quality management systems.

P32 CHAMPIONING THE WORLD OF WOOD

Stora Enso recently started production at its new €45million CLT facility at Grüvon in Sweden. Eve Dennehy reports on how Stora Enso maintains leadership in the global mass timber industry.

P08

P22

A quick round-up of some recent news stories from the timber and construction sectors that you may have missed including a new EU consortium targeting the reduction of CO2 emissions through increased use of timber, the BWF appoints a new President and BoKlok targets Bristol.

The inaugural Offsite Expo launched in Coventry to universal acclaim with positive feedback from exhibitors, visitors and speakers. With timber well represented, all agreed this was the offsite event that the construction industry has been waiting for.

UK INDUSTRY NEWS

OFFSITE EXPO 2019

P36 STA ADVICE NOTE 18 – WHAT DO SPECIFIERS NEED TO KNOW?

John Mellor, Product Manager at Protect Membranes, explains the STA’s new Advice Note 18 and the key recommendations for breather membranes installed to structural timber walls.

P44 STRUCTURAL TIMBER AWARDS 2019

Officially sold-out and packed to the rafters, the 2019 Awards took place once again during UK Construction Week at the National Conference Centre, Birmingham. Who was a class above?

P56 A TRIUMPH IN TIMBER

P24

Featuring at the Timber Talks event – The Import Building in East India Dock, London is an exceptional example of the use of cross laminated timber (CLT) and glulam.

A NEW PARTNERSHIP: A LONG-TERM VISION

P58 ENERGY EFFICIENT TO THE CORE

Earlier in 2019 Urban Splash announced a deal to bring Japan’s biggest housebuilder – Sekisui House – to the UK, helping the developer create more modular timber homes. Urban Splash’s Director of Delivery Chris Shaw talks through the partnership, the company’s adoption of modular and plans for the future.

P60 LOW ENERGY LEARNING

• Members of Structural Timber Association. • Extensive experience of applying STA guidance and research. • Determination of category of frame needed. Protecting people and property since 1982

FIRE ENGINEERING CONSULTANTS

• Advice on appropriate solutions to reduce the risk of fire spread to surrounding buildings. • Use of advanced computer modelling techniques to analyse timber frame proposals and provide a cost effective solution.

The 2019 RIBA Stirling Prize was recently awarded to a revolutionary social housing development for Norwich City Council with a highly insulated timber frame structure. The UK’s first Passivhaus secondary school – the £40 million state-of-the-art Harris Academy has opened its doors and sets a precedent for low carbon, sustainable buildings.

The multi-disciplinary team comprises both chartered and graduate engineers, with specialist experience in fire protection and fire engineering, and experienced fire safety professionals with backgrounds in local authority fire and rescue services. For further information visit our website:

www.cstodd.co.uk Tel: 01252 792088

Certificate Number 860 ISO 9001

Email: office@cstodd.co.uk


COVER STORY CUNDALL

HITTING THE TIMBER HIGH NOTES

01 Barney Jordan, Structural Engineering Partner at multi-disciplinary engineering firm, Cundall, discusses the triumph of timber in musical education and how the award-winning King’s College School, Wimbledon’s state-ofthe-art new music school is an achievement of client vision, innovative architecture and structural design.

6

w

Key to the project’s success has been the integrated approach between the architect, engineers, the school and the wider project team. Showcasing specially designed American white oak-lined ceilings in both the concert hall and rehearsal room, timber was the obvious choice of material in the design of the new music school. The multi award-winning structure, which opened late last year, is part of the school’s ongoing development masterplan and is the result of a clear vision by both the school and the architect, supported by superb engineering. The Hopkins Architect’s designed music school is arranged over three floors. The basement level comprises

STRUCTURALTIMBERMAGAZINE.CO.UK

02 loud practice rooms for instruments such as percussion, drums and brass, while the ground floor is home to the stunning 200-seat concert hall which can accommodate a 70-piece orchestra, a new porters’ lodge and staff administration space. The top floor consists of an orchestra rehearsal room, additional practice spaces and the porter’s residence. Both the concert hall and the orchestra rehearsal room have specially designed American white oaklined ceilings, which create a wonderful acoustic and reveal the exposed triangulated structure of the building. The project team, comprising the architect, engineer, fabricator and contractor, went through extensive deliberation before arriving at the choice of timber as the dominant


COVER STORY CUNDALL

03

04

structural material. During the concept design stage, concrete and steel were evaluated for the roof structures but they didn’t meet the structural honesty that Hopkins aimed for in their vision for the buildings and would not have been as aesthetically pleasing.

the pieces together and designing each diagrid to withstand the different forces across the roof. This meant close collaboration with both the contractor and fabricator to ensure each piece was built to the correct requirements and assembled appropriately.

In the end, timber was chosen for its good compression qualities, which suited the requirements of the triangulated roof design, its sustainability credentials and its ability to achieve the architect’s aesthetic requirements to integrate the structure with both the interior and exterior finishes.

To keep the overall thickness of the roof to a minimum, some of the glulam elements are designed to be working close to their strength capacity, which made the connection details even more challenging. The roof design and the node connections are just one part of a very well-conceived and engineered project, but they exemplify the collaborative and detailed design process that was experienced by the whole project team.

The shape of the main concert hall roof and the smaller orchestra rehearsal room roof – affectionately known by the design team as ‘the baby roof’ – are governed by the acoustic requirements of the spaces. The elegant glulam diagrid structures of these roofs not only result in a very efficient way to create the required geometry but also provide a support system for the integrated timber acoustic panels. American white oak soffit lamella glulam beams were selected to match the American white oak veneer of the acoustic panels. The diamond structural grid matched both the interior acoustic panels and the external tile pattern, providing a cohesive and ultimately quite beautiful design, which contributes to the space functionality. The main challenge Cundall faced was joining the timber diagrid members together, as the design required the six pieces of timber to come together at a single point. Both Cundall and Hopkins spoke to multiple timber fabricators to find an appropriate solution, eventually selecting a steel node to join each of

The timber components were prefabricated offsite following close collaboration between the engineer, architect and timber contractor to ensure fine tolerances, low wastage and a cohesive and resilient design and installation. This meant less waste, as materials are not being cut down or amended on site. The timber selected was also PEFC and FSC-certified, meaning the construction material has a lower embodied carbon, compared to other standard materials and has been responsibly sourced from well-managed forests. Close liaison was required with the timber contractor from tender through to construction, to make sure the components met the requirements and allowed for the triangulated timber diagrid design to have structural integrity and match the design details of the rest of the structure. Since the timber was prefabricated, the design could not be altered once construction had begun.

w

Timber is a natural insulator, and it provided a thermally efficient structure and building envelope for the music school. This meant lower running costs and increased resistance to the unregulated changes in air, water, heat, light and noise transfer from the outside environment. Using timber to satisfy the acoustic requirements in this way meant it could be integrated into the build-up of the envelope and resulted in an elegant and environmentally efficient design. The entire design team worked hard to meet the vision of both King’s College School and the architect, to ensure the design was fully co-ordinated ahead of fabrication. The process was collaborative through to final completion and has resulted in a beautiful and functional structure that will nurture a love of both music and building design for generations to come. www.cundall.com

AWARDS RIBA London Award 2019 RIBA National Award 2019 Structural Timber Awards 2019 – Education Project of the Year New London Architecture Award 2019 – Commended Education Acoustics Award 2019 The Institution of Structural Engineers Awards 2018 – Regional Winner

IMAGES: 01-02. The Concert Hall 03. Interior acoustic panels with diagrid node connections 04. The new music school at King’s College School, Wimbledon. All images courtesy Janie Airey

STRUCTURALTIMBERMAGAZINE.CO.UK

7
