INNOVATION DIGEST
50 innovations unveiled at the EPHJ trade fair that are shaping the future of high precision!
Watchmaking/Jewellery
AdTime: New AR20 Roller
Microscopic accuracy and unmatched versatility: The AR20 Roller revolutionizes pinion rolling with programmable automation and custom loading options.
The new AR20 Roller is a revolution for the pinion rolling industry. It is not only very precise (+/- 1 micrometre of precision after running), it is also equipped with a programmable NC PLC and assisted byasystemofmeasurementruleswithpositioningoftheaxesonthescreenforgreatercomfortduring start-up and use. To optimally adapt to the varied needs of customers, the new AR20 Roller also features different loading systems, including conventional manual loading with notched targets (Ø 8 mm and Ø 27 mm) or in combination with a W20 type charger, as well as automatic loading with a vibrating bowl. A modular version of the machine is also available to alternate manual and automatic modes according to the sizes of the batches of parts to be produced.
https://www.adtime.ch/decors
Anotherbrain: Blue Phosphor
Blue Phosphor®: AI inspired by the brain and social insects for revolutionary visual quality control, reducing waste and improving working conditions.
AnotherBrain, a French start-up, offers a visual quality control solution in HBJO based on artificial intelligence called Blue Phosphor®. This solution aims to reduce waste and eliminate arduousness at work by increasing the operator'scapacitiesthroughAI.Thetechnologydeveloped by AnotherBrain is inspired by the functioning of the brain and thecollectiveintelligenceof socialinsectsto reproduce the equivalent of a part of the cortex on a microchip. This 3rd generation of AI is able to learn in real-time, without supervision, and can explain its decisions. The Blue Phosphor® solution consists of two applications, Vision and Pilot, and configures tailor-made solutions for quality control. Renting an annual license from €15k and allows companies of all sizes to reduce waste.
AnotherBrain supports production by offering human intelligence enhanced by artificial intelligence. https://anotherbrain.ai/en/blue-phosphor
Acsys: Multishift Laser Processing System
MULTISHIFT® combines fully automatic processing with high-precision robotic handling.
The system can accommodate up to 20 pallets containing loose or placed parts. The integrated robotic system routes them to laser machining with precision through high-resolution camera systems and optical part recognition from ACSYS. Fully automatic machining of parts on multiple faces is possible with maximum precision because the body of the MULTISHIFT® machine is also composed of highstrength steel and granite. This ensures excellent results.
https://acsyslaser.com/en/products/multishift/
Beckhoff: MX-System
The MX system includes base plates in three sizes, equipped with standardized interfaces for direct attachment to the machine and visual and functional integration into the installation space.
The base plates serve as an electrical and mechanical interface forhousingthemodules.Theyhave data and power interfaces depending on the size. Base plates are available with a minimum of six and a maximum of 24 slots, configurable in steps of two slots. Compatible modules depend on the size of the base plate and its connectors. All three sizes are available in variants for maximum flexibility and application optimisation.
https://www.beckhoff.com/fr-ch products/mx-system/
Bruker Alicona: µCMM
The new µCMM Alicona is the most accurate optical three-dimensional measuring machine in its class.
Based on Focal Variation technology, it has all the advantages of optical technology, especially for the high-resolution measurement of components with steep sides and high reflectivity. Insensitive to vibrations,itallowsacquisitionswithahigh density of measurement points. It allows operators to take fully automated dimensional, position, shape and roughness measurements of their parts.
https://www.alicona.com/fr/produits/ucmm
Chiron: Micro5
The Micro5 from Chiron: A revolutionary industrial micromachine for machining watch components, offering unparalleled autonomy thanks to its 5-axis machining centre, its 60-tool changer and its integrated Yaskawa robot, all in less than one square metre.
Swiss manufacturer Chiron presents its latest version of the Micro5, an industrial micromachine for machining watch components, at the EPHJ 2024 trade fair. This version is more autonomous and can finish all the milled watch components. The Micro5 is equipped with a 5-axis machining centre in less than one square metre, a 60-tool changer with a chip-to-chip time of 4.5 seconds and an indexable tool holder for precision bores. The machine's autonomy has been significantly increased thanks to Feed5 and the integration of a Yaskawa robot, allowing for the completion of the sixth face of the parts during downtime and optimising production. The Micro5 evolves into a true machining cell, demonstrating that the basis of a micromachine can adapt to specific market needs. These innovations will mark all sectors of micromechanical machining.
https://chiron-group.com/products/micro5¨
Codatic: Watch 512
A revolutionary watch design interface that uses AI to quickly and accurately bring design ideas to life, adhering to the aesthetic codes and functions of a base model, while providing complete confidentiality through a dedicated server.
Watch512 is an innovative interface that uses an algorithm combining multiple artificial intelligences to quickly and intuitively create watch images and preproject aesthetics. This simplified interface can be configured specifically for each brand, integrating its DNA markers, aesthetic codes and designs, enabling the realization of ideas and shortening the exchange phases between the various stakeholders involved in the creation of new collections. Watch512 offers unique precision and quality results, faithfully retaining the shape and functions of a starting model while providing a deliberately different style from or variations of an existing model. The possible inputs are multiple, ranging from a simple photo to a 3D technical drawing or a sketch. Watch512 is developed by Codatic, a pioneering company in continuous R&D mode that guarantees total confidentiality via a "home" server. https://www.watch512.com/
Dixi Polytool: Dixi 1137 Drycut 5D and 8D
Innovation for the machining of lead-free brass, offering a reduction in cutting forces of more than 30%, negligible wear and superior hole quality, compliant with European Reach directives.
The new series of Dixi 1137 Drycut 5D and 8D drills has been developed specifically for machininglead-freebrass.Testresultsshow a reduction in cutting forces of more than 30% and negligible wear after 900 holes in 170Hv CuZn37 brass. The quality of the holes is higher than that of
conventional drill bits, with no burrs and no sticking. This innovation is important because the European reach directives threaten the use of lead in brass alloys, especially in the jewellery sector. Alloy producers are reducing lead levels and cutting tool manufacturers are having to adapt to more difficult machining conditions. Dixi 1137 Drycut 5D and 8D drill bits are effective in non-ferrous materials, and stainless or high-alloy steels.
https://dixipolytool.ch/dixi/dixi-1137-le-choix-incontournable-2/
EllistatMed: Innovative additional modules
Software innovation for quality in production, with machine learning and automation modules for the adjustment process of machine tools, meeting the strict standards of the watch and medical industry, and offering a significant reduction in workshop returns through traceability and the detection of non-conformities in real-time.
Ellistat offers innovative additional modules, including Data Analysis in a web version and APC (Automated Process Control). Data Analysis machine learning algorithms enable an understanding of the origin of machine drifts or to statistically differentiate suppliers. The APC module automates the machine tool adjustment process to achieve compliance from the first machined part. Faced with strict standards, such as ISO 13485 and the American standard CFR21 part II, the Ellistat software meets the strictest requirements, in particular in terms of traceability, real-time production monitoring and detection of non-conformities. According to David Scarpino, co-CEO of Bien-Air Surgery, the use of Ellistat software has resulted in a 50% reduction in workshop returns. He aims for 0% return through the total implementation of the APC module. The artificial intelligence in the software controls only and automatically what is necessary, thereby optimizing control efficiency within the company. https://www.ellistat.com/solutions-apc/
ERM Fab&Test: Redon Technology precision machining
Compact machining without compromise.
https://www.erm-fabtest.com/brand/9-redon
Redon Technology solutions represent the ideal solution for machining a wide variety of materials up to the hardest (Chrome Cobalt, Titanium) in a reduced footprint.
These machines can all machine on 5 axes and under water, and benefit from automatic tool changers. They have pins up to 3700W and the all-new BestMill can be equipped with an automatic disk loader. Originally dedicated to dental applications where they excel, ERM Fab&Test has developed a solution to make them compatible with industrial applications.
Eurofins Materials Science: Materials analysis
Multidisciplinary expertise in materials analysis to detect and solve contamination and corrosion problems, and optimise the processes and functional properties of materials through advanced analytical techniques and custom support.
Eurofins Materials Science offers a reactive analysis service to detect the origin of problems, such as contamination or corrosion on materials, and implement corrective actions. Their consultative and multidisciplinary approach enables the selection of the most appropriate analytical techniques to probe the material down to its structure, beyond the limits of the naked eye or optical microscope. Eurofins Materials Science teams also offer personalised support to help customersoptimisetheirprocessesandimprovethe functional properties of their materials or parts. Their expertise and state-of-the-art equipment meet the challenges of purity of materials in different sectors of activity.
Fatcarbon: Dark Matter GOLD
Gold composite sheets made from recycled carbon fibre for an incredibly fine, lightweight and durable result.
At the heart of humanity's many mysteries and unanswered questions lies the enigma of dark matter. All we currently know is that it is present everywhere inour galaxy. For the rest, it's a complete mystery. This captures our imagination and we would like to invite you to step into the unknown with us. Fat
Carbon "Dark matter" GOLD Composite Sheets are made from recycled carbon fibres, bio-based epoxy resin, organic pigments and renewable energy. The end result is an incredibly fine, lightweight (1.5g/cm3) and durable composite. The possible applications of this material are endless - from knife scales to watch cases and jewellery. https://fatcarbonmaterials.com/shop/carbon-fiber-dark-matter-gold/
General Springs: Lead-free barrel and bioflex spring
An ecological and sustainable revolution in the watch industry, offering increased product reliability and longevity while ensuring customer safety and preserving the environment.
The development of a complete barrel for watchmaking that is completely lead-free, accompanied by the use of the Bioflex barrel spring, represents a real revolution in the watchmaking industry. Bioflex is an innovative material, environmentally friendly and free of Beryllium, an element that may be banned in the future by the Reach standard due to its harmful effects on health. Lead is known for its tendency to oxidize and corrode over time, which can alter the appearance of components. Replacing it with other materials, such as stainless steel and lead-free brass, improves the reliability and longevity of the products. By adopting these advancements, watch manufacturers guaranteethe safety andsatisfactionof their customers, and alsocontributeto the preservationofthe environment and the sustainability of their industry. These innovations also provide opportunities for differentiation and positioning in the market. https://generaleressorts.com/wpcontent/uploads/2020/02/generale-ressorts-fiche- technique-bioflex-fr.pdf
GF Machining Solutions: Laser S 500
High-precision laser micromachining for hard and brittle materials, without thermal assignment, with an intuitive interface and complete software to provide a durable and energy-efficient solution.
The S 500 LASER (U) is a high-precision laser micromachining machine for hard and fragile materials, such as ceramics, zirconia, sapphire, SiC, SiN and alumina. It uses femtosecond laser sources for exceptional quality without thermally affecting the machined area. The machine incorporates a new intuitive human-machine interface and a LaserSUITE360 software suite for laser engraving and texturing. The S 500 (U) LASER is durable, reduces maintenance costs and improves energy efficiency by substituting chemical or traditional techniques for micromachining and decorating parts.
https://www.gfms.com/com/en/machines/laser/lasermicromachining/laser-s-500.html
Grindosonic: MK7
Instant measurement system of the mechanical properties of a sample by frequency imprinting, for ultra-precise defect detection, consistent quality and optimised manufacturing processes in the high-end watch industry.
The GrindoSonic® MK7 is a measurement system that instantly calculates the mechanical properties of a sample based on its frequency footprint. It can be used manually or automatically on a production line. The system measures the sample's natural resonance frequency to determine its hardness, composition, and dimensions, as well as the damping to detect any existing cracks. It also measures the asymmetry of a circular part. The GrindoSonic®MK7 guarantees optimal mechanical performance, consistent quality and optimised manufacturing processes for high-end watches, detecting defects of the order of one part per million. https://grindosonic.com/mk7/
Humard: AV7
Hummink: Nazca
This collaborative 6-axis robot is mounted on a mobile AMR (Autonomous Mobile Robot) and features a part placement function using camera re-centering.
It is the ideal tool for industry players in need of high modularity and efficient automation. Through its 6 axes, the robot can perform complex tasks with great precision. Thanks to the camera re-centering, the robot can easily reposition parts with great precision, ensuring optimal work quality regardless of environmental conditions. In addition, its ability to learn quickly and adapt to different work contexts can respond effectively to the specific needs of each company.
https://www.humard.com/robothumard/
High-precision, direct nano-printing for micron and submicron additive printing using high-viscosity inks and various solvents for printed electronics without using an external power source.
Hummink's patented technology is basedon a unique method of direct nano-printing. It is directly derived from AFM (Atomic Force Microscope) technologies, replacing scanning probes with microtips that oscillate at a controlled frequency using highprecision electronics. Inks with high viscosity (up to 100,000 cP), high concentration and various solvents can be deposited without difficulty and without any need for an external energy source. NAZCA is an additive tabletop piece of equipment designed to print at the micron and submicron scale, with unprecedented resolution and precision to design and assemble new objects in the printed electronics field. https://hummink.com/
Ictyos: LUNA, SQUAMA, NOVA
Eco-responsible and innovative marine leather for watchmaking, cladding and leather goods, transforming fish skins into high-quality, resistant and easy-to-use materials.
Ictyos combines the traditional know-how of a French tannery and an eco-responsible approach by transforming fish skins from the agri-food industry into very high-quality marine leathers. The LUNA is a high-quality scaled trout leather, a remarkable material embodying the strength of France's rivers. With a very fine and regular grain, trout leather is an easy-to-use material. The fine size of the scale makes this leather an innovative material. The SQUAMA is high-quality scaled salmon leather. Its tight and perfectly symmetrical grain over the entire surface makes it easy to use for watchmaking, sheathing and leather goods. Very resistant, the different finishes can give it a light, perfectly flattened or soft appearance. NOVA is a unique high-quality sturgeon leather with star-shaped spicules. It has its own signature inspiring creations of unique refinement. Its exclusive origin from French caviar producers makes it a rare product. https://www.ictyos.com/
Incaptek: Composite materials with extreme performance
Winner of the EPHJ 2024 Exhibitors' Grand Prix
Ultra-resistant and durable composite materials for aerospace, automotive and medtech, compatible with additive manufacturing and injection moulding, for lightweight and 3D customisable implants.
Incaptek has developed a new cutting-edge technology to produce high-strength composite materials using elongated fibres with a uniform coating. This new technology increases the material's strength by more than 1.5 times. These composite materials are remarkable because they are extremely resistant and durable, with great technological flexibility, and compatible with additive manufacturing and injection moulding. Their composites can be used as high-performance materials for aerospace, automotiveandotherindustries.Theycanalsobeusedinmedtechtoreplaceheavytitaniumimplants. Lightweight and similar to bones in terms of mechanical properties, implants produced from their composites are easier to manufacture and can be customised using a 3D printer. https://incaptek.com/high-performance-materials/
Injector: ITR2®
A chemical solution to bond itr2® and metal.
Until now, bonding a composite resin to a metal was only done by mechanical bonding. This solution is completely transparent and leaves no visible traces on the metal surface. It enables the creationof a fully monolithic "bi-component" with a perfectitr2®-Metalbond,regardlessofthe metal's surface condition (machined, microfinished, satin, or mirror-polished). This connection is completely invisible and allows perfect revelation of the surface and shapes of the metal without any mechanical attachment.
https://www.injector.ch/Injectorevolution/itr
Isoma: ISI-X-Scan
Revolutionised mobility control of small parts. This sophisticated device is expected to revolutionise the control of the mobility of small parts in the watch, jewellery and electronics industry. “The ISI-X-Scan determines efficiently and accurately whether, for example, tiny diamonds are properly fixed in watch frames or electrical components on printed circuits”, explains Thomas Reber, CEO of ISOMA Sàrl. The device uses a magnetic field to periodically shake and vibrate the examined objects.
Two high-resolution cameras allow for quick and easy control. Thomas Reber adds: "Images are taken before and after oscillation, and then superimposed using an image processing device to quickly identify differences". Parts that are not properly attached light up on the screen, whether they are screws, diamonds, electrical components or other precision parts. The examined objects are vibrated. It quickly and accurately determines whether the parts are properly fastened or not. https://ticketing.ephj.ch/fr/exposantsproduits-app/isi-x-scan
Jag and Criva: AI-Assisted Robotic Quality Control
A quality assurance system for precision manufacturing using robotics, AI and an MES to optimise quality control, increase anomaly detection, and reduce inspection time and production costs. Easy to use.
The concept proposed by Criva and JAG is based on the use of three technologies: robotics, unsupervised artificial intelligence from Criva, and an MES to guide the user in program creation and production management. This comprehensive system optimises all aspects of the quality assurance process in precision manufacturing by ensuring objective quality control, increasing the rate of anomaly detection, reducing the time required to inspect batches, reducingproductioncostsandallowingvisitorstofocuson value-added tasks where human judgment is needed. The system is easy to use and accessible to all, without the need for special technical expertise.
https://www.jag.ch/fr/newsletter/jagletters/JAGNews_2405.php?highlight=criva
Keris: WOW!
Multi-layer LED lighting for striking projections of enlarged timepieces, with a 12-megapixel camera and a matte 27'' 4K display for precise exploration from all angles. Global patent pending.
The WOW! innovation features internally developed multi-layer LED lighting technology and creates striking projections and iridescences that highlight every detail of timepieces and microtechnology components magnified between 7 and 22 times. Equipped with a very highsensitivity sensor and a 12
megapixel camera, WOW! captures every nuance with exceptional precision. The heart of this innovation liesin itsmatte27’’4Kdisplay,whichoffersunparalleledresolution and sharpness, allowing users to truly 'fit' into rooms and explore them from all angles. A worldwide patent is pending for this unique concept.
https://www.keris-time.com/wow-1
Keyprod: Keynetic
Advanced production tracking using AI to turn vibration into key performance indicators, compatible with all machines and providing real-time access to data for production management optimisation.
KEYNETIC, a major innovation of KEYPROD, but also a real revolution in production monitoring. This cutting-edge technology is designed to precisely drive industrial production operations. By leveraging advanced algorithms and artificial intelligence, KEYNETIC transforms machine vibrations into key performance indicators. It works with all machines, regardless of their age or automaton. As a next-generation IoT solution, KEYNETIC provides real-time access to performance data, making it not only available, but also fully actionable for production management optimisation.
https://www.keyprod.com/fr/keynetic
Konica Minolta: CF-300
Konica Minolta: CF-300 non-contact spectrophotometer for accurate colour evaluation, measuring small target areas and improving quality control procedures with up to 5 measurements per second.
Konica Minolta Sensing Europe presents the CF-300, the world's first contactless spectrophotometer with a very high measurement rate, featuring an analysis area of 1 mm. This device guarantees pristine colour evaluation with extreme precision for high-precision sectors, such as watch dials, smartphone components, eyeglass frames and cosmetics. The CF-300 can measure target areas as small as 0.75 x 1 mm and is remarkably manoeuvrable, thereby reducing the margin of error.
The revolutionary non-contact measurement through the use of an advanced integration sphere that preserves the integrity of delicate products and streamlines the measurement process. With 0.1 seconds per measurement, the CF-300 enables continuous measurements at intervals as short as 0.2 seconds and can perform up to 5 measurements per second, improving quality control procedures. https://sensing.konicaminolta.us/us/products/spectrophotometer-cf-300/
Laser Cheval: Geode Quartz
Quartz laser machine and Geode palletizer for optimal productivity, offering compactness, precision, modularity, flexibility, energy efficiency and high-machining precision. In-house design and manufacturing, software development and technical support.
Laser Cheval presents its new laser machine and palletizer for optimal productivity at the EPHJ 2024. Quartz is an innovative laser machine that can integrate any type of laser source, from continuous to femtosecond. It is distinguished by its compactness and precision. It can be coupled at any time with the Géode, a large-capacity palletizer that manages the various references of loaded parts and ensures the transfer of trays between the Géode and the Quartz using its robotic arm. This dual unit stands out for its modularity, flexibility, energy efficiency, small footprint and high-machining accuracy of the order of a few micrometres. LaserChevalis amemberof theLaseagroup and hasin-house expertise inthe design and manufacture of its machines, as well as the development of its own software and technical support to ensure the sustainability of its machines. https://geode.lasercheval.fr/
Legor: 3D Metal Binder Jet
3D printing Metal Binder Jet for precious or non-precious metal components, creating complex models previously unachievable or expensive, environmentally friendly and cost-effective, with complex geometries or hollow structures thanks to digital reproducibility.
Legor, a company specialising in the manufacture of high-quality metal alloys,platingsolutionsandpowdersfor the jewellery, luxury goods, fashion and decoration sectors, has developed an innovative3Dprintingtechnologycalled the3DMetalBinderJet.Thistechnology uses ultrafine metal powder to create valuable or non-precious steel, bronze, silver and platinum components, and soon in 18k gold. The three-phase process, printing, curing and sintering, creates complex models that were previously nearly impossible or excessively expensive to produce using traditional machining methods. This technology also reduces material waste and refining, making it an environmentally friendly and cost-effective process. The reproducibility derived from numerical models renders lost-wax casting obsolete and allows designers to create complex geometries or hollow structures. https://legor.com/fr/3d-metal-hub/
Louis Belet: Tornado
ToolFinder© 2024 digital solution and Expert drill bit 376H-10 for fast and efficient drilling of stainless steel with an exceptional lifespan and quality thanks to a specific micro-grain carbide, a high-performance TISI coating and specific lubrication channels.
The Swiss cutting tool manufacturer Louis Belet presents its digital solution ToolFinder© 2024 and its range of Tornado drilling and milling tools with central watering.
The ToolFinder© 2024 solution is a simple, efficient and fast digital tool to choose the right tool from the manufacturer's ranges. The new Expert Drill Bit 376H-10 has been designed to reduce stainless steel drilling cycle times with a speed three to four times faster than the manufacturer's previous range. The drill bit is equipped with a micro-grain carbide specifically designed for drilling ferritic, martensitic, and austenitic stainless steels, and it features a special sharpening process to ensure the durability of the cutting edges over time. The application of a high-performance TISI coating reduces the coefficient of friction, thereby minimizing heat buildup and edge build-up. The specific shape of the lubrication channels increases the oil flow and to guarantee the uniformity of the performance of the drills according to their dimensions. Manufacturer tests show an excellent drill lifespan and exceptional drilling quality with suitable viscosity oil and watering pressure between 50 and 100 bars. https://www.louisbelet.ch/en/news/forets-a-lubrification-interne-expert-inox/ref.-376h-10-foretexpert-inox.html
Maclef: MC2127 and MC2129
Two new top-of-the-range mechanical and self-winding horological calibres, with superior finishes and parts sourced in Switzerland for an optimal performance.
Maclef offers two new watch calibres: MC2127, a hand-wound mechanical calibre, and MC2129, an automatic calibre. The hand-wound calibre is available in two iterations: the class range, aimed at high-end production, and the Haute Horlogerie range, featuring a "hand-grained" finish. The MC2129automaticcalibreincorporatesthesemainfeatures.Itstwopart oscillating mass is composed of a heavy sector at its periphery and a brass body, allowing the centre of gravity to be furthest from its centre of rotation, thus improving the potential for centrifugal energy.
For its two new calibres, all the parts used were sourced in Switzerland and more particularly, in the Jura arc, the canton of Neuchâtel and the canton of Vaud.
https://maclef.ch/
Microqubic: MRCL700 3D Imager Pro
An innovative MRCL700 3D imaging system for precision research and manufacturing, offering compactness, modularity, programmability, curved lighting technique for high-resolution 3D imaging and advanced functions for accurate measurements.
Microqubic AG designed the MRCL700 3D Imager Pro, an innovative 3D imaginary system for scientific researchand precisionmanufacturing. It standsout for its compactness, modularity, "programmability" and affordable price. Its innovative curved lighting technique enables 3D imaging of difficult samples, such as silicon microchips, complex mechanical parts and3Dprintedstructures,withmicrometreresolution. This system offers advanced features, such as autofocus stacking, time lapse, HDR imaging, the integration of dynamic scale bars, and other essential features for microscopy and macrophotography. Using dedicated software, it takes accurate measurements ranging from centimetres to micrometres.
https://www.microqubic.com/_files/ugd/e89aef_8a6006b5d147476dabe110d67410387e.pdf
Mister Laser: Forbeam Pathabene
An AI tool for precise and adaptive welding from a few milliseconds to a few seconds, avoiding deformations and waste for efficient laser welding.
Pathabene is an artificial intelligence tool that observes the welding area to automatically define the weld bead, adapting to any changes in shape. The algorithm was developed in-house using a resnet18 model and can take anywhere from a few milliseconds to a few seconds to perform the calculation, depending on the computational strength available. Pathabene is particularly useful in applications where parts have high tolerances and where traditional visual recognitions are ineffective, which can result in deformations and waste. Pathabene avoids these problems by adapting the weld bead to the reality of the surface to be welded, making Forbeam driver software even more attractive for scanner and vision laser welding.
https://www.mister-laser.com/brochures/KallpaF/index.html
MPS Watch: BCube
Ball Bearing Builder Configurator for custom adaptation, feasibility check and automatic generation of 3D step file, reducing development time and allowing focus on innovation and creation.
This scalable system allows customers to selfconfigure the geometries, dimensions and terminations of their ball bearings using an algorithm specifically developed to verify feasibility and operating characteristics. If everything is compliant, the step 3D file is automatically generated and sent to the customer. This solution allows teams to focus on innovation and creation, while reducing development time.
The time saving is undeniable since development work always requires many back and forth trips. The configurator also an offer to be requested directly on the platform, including all the parameters entered. It took several years of development and programming to achieve such an outcome.
https://www.mpsag.com/fr/horlogerie/bcube/
Neo-Logix: Neo-Fugu
A comprehensive management software for jewelry workshops, providing performance optimization and ensuring financial stability.
It addresses several crucial aspects of managing a jewelry workshop, such as weight accounting, the police book, hallmarking, traceability of metals and stones, and precious metal fixing. The software also allows precise control of the workshop with the capture of the workingtimesofeachcraftsmanateach stage of production for a reliable and accurate cost calculation. NEO-FUGU® helps workshops to finely calculate the loss of precious metals at each stage of production and to follow the evolution of the weight of the part during each of its manufacturing stages.
The software meets the requirements of the RJC CoC (Responsible Jewellery Council Chain of Custody) and major luxury houses by clearly and accurately presenting the traceability of precious stones and metals. This allows workshops to justify the originof gold and gemstones and to track their production journey. https://www.neofugu.com/fr/logiciel-joaillerie/
Objectis: InstantUX
InstantUX is a user-friendly configuration interface that offers a variety of tools to quickly create views and establish intuitive navigation for efficient information transmission to operators.
It also allows customisation of the visual style to reflect the company's identity, while providing a professional and standardised user experience. Once the configuration has been made, the InstantUX interface is deployed on all the machines in the workshop, thus offering a homogeneous experience in terms of ergonomics, visual style and principles of use. InstantUX represents a major advance in the field of HMI for production machines and factories, allowing machine manufacturers to quickly design modern and professional interfaces, perfectly adapted to the needs of their customers. https://objectis.com/nos-
products/instant-ux-atelier/
Ocode and Phasis: Digital punch
Ocode and Phasis are two companies that have joined forces to fight counterfeiting and ensure the traceability of valuables. Ocode, a start-up from Nantes, has developed a technology of hexagonal codes in the form of point clouds, which uniquely identify an object and its life cycle. These codes are stored on a private blockchain for maximum security. Phasis, a spin-off from the University of Geneva, has developed a non-contact nano-engraving system that marks objects accurately and aesthetically, without damaging the material. By combining their technologies, Ocode and Phasis offer a complete traceability and authentication solution for the jewellery, watchmaking, leather goods, defence, medical, automotive and aerospace sectors.
https://www.ocode.fr/poincon-numerique
Patric Concept SA: ATEX hot air dryer
The first ATEX hot air dryer, offering high-speed and excellent drying quality, through air circulation turbines and an air recirculation system.
The dryer is equipped with an energy-saving module, an automatic pre-heater and a servomotor to control the acceleration and rotation phases, thus avoiding any impact on the parts during the drying cycles.
The user interface has been improved with a 15-inch touchscreen for simple recipe programming, which can be transferred to another machine by USB key, and all accessories of existing dryer models are compatible with this new dryer. A pneumatic assist has also been integrated for opening the lid.
https://patric.swiss/wpcontent/uploads/2024/04/Flyer-2024-05-13-SecheurATEX-FR-1.pdf
Pelico: Pelico
The Pelico factory operations comanagement platform gives manufacturing teams the agility and resilience to respond quickly to any supply chain disruption and mitigate its impact.
By giving teams access to a single data source, Pelico allows them to anticipate bottlenecks, prioritise corrective actions, accelerate the collaboration of all actors in the flow and simulate new production plans in order to ultimately increase the coverage rate. https://www.pelico.ai/
https://www.pelico.ai/
Petitpierre: Drop & Lumen
By envisioning two independent, compact modules to be placed directly near the turning machines for cleaning and measuring parts in the demanding environment of workshops, Petitpierre SA offers a truly innovative added value that provides time savings, logistical efficiency and increased reliability.
Lumen, the solution for optical measurement directly at the machine's output enables instant measurement of parts between 0.1 and 15 mm in size through a simple and fast vertical or horizontal setup. Lumen now allows you, for example, to control your axes, balance springs, gauges, wheels and screwsaccordingto NIHSstandardswithoneclick.Tobemeasuredcorrectly,partsmustbethoroughly cleaned. Drop, the ATEX-certified automatic unit cleaning module, guarantees the repeatability of the cleaning quality, the perfect synchronisation of the cleaning and measuring processes with a quantity of solvent adapted to the part and a single use of benzine. The patented combined package of Drop + Lumen represents a significant advancement in bringing optical measurementofmicro-technicalpartsdirectly at the machine's output, enabling closed-loop production.
https://petitpierre-19e5d.kxcdn.com/wpcontent/uploads/2023/12/PEP-sheetdescriptif-lumen.pdf
Promotion Group: One-Of-Onetm
ONE-OF-ONETM is a patented identification and authentication technology that uses nanotechnology to integrate synthetic DNA into any product.
This technology offers a secret and unique identification code, undetectable and tamper-proof, which protects items from counterfeiting and builds consumer confidence. ONE-OF-ONETM is certified and can be tailored each customer through a partnership with a European Advanced Nanotechnology Laboratory.Luxurybrandscanusethistechnologytoimprovetransparencyandcertifytheauthenticity of their products by fighting counterfeiting and controlling the flow of manufacturing and supply chain operations. Synthetic DNA tag offers unparalleled security because it is indecipherable and nonreproducible, unlike other systems like NFC or QR codes that are visible and removable.
https://promotion-group.ch/
Pureon: Squadro-G2
Pureon presents the second generation of its Squadro-G2 diamond abrasive discs at the EPHJ, specifically designed for crystal grinding.
Founded in 1952, Pureon is a Swiss family-owned company that is a world leader in extreme precision polishing solutions, with five production units spread over three continents and more than 150 employees. The company specialises in the micronization of mono- and polycrystalline diamond powder, and covers applications in mechanical, chemical and conventional polishing. Pureon's R&D unit, composed of six doctors in chemistry, has developed the Squadro range based on the experience accumulated with the ten industries that are customers of the company. The Squadro-G2 disc is designed with a 50% higher abrasive layer thanthe previousone, resulting from a revolutionary manufacturing process. Combined with Squadro-Lub+ lubricant, the disc achieves superior material removal rates in an environmentally friendly manner, while providing an exceptionally flat surface quality with sharp angles.
https://pureon.com/products/grinding-pads/squadro-g2/
RC Tritec and Thyssenkrupp Materials: Swiss Super-LumiNova
A collaboration to produce a super lightweight aluminium alloy in which SLN is incorporated to give significant eye-catching effects.
With its unmistakable pattern, this high-end solution will make your eyes shine. In addition to the different brightness qualities, the Swiss Super-LumiNova is also availableindifferentparticlesizes.Forspecialapplications, pigments finer than the standard particle size can be produced.
https://www.rctritec.com/superluminova/qualitaeten
Rimann: Precious metals vacuum cleaner
Specialising in chip centrifuges since 1945, the company offers global chip processing solutions for the luxury industry, especially for precious metals.
At the EPHJ trade fair, the Goldvac liquid and precious metalchipvacuumcleaner,developedbyitsFrenchpartner Siebec-Sofraper, aroused great interest. Available in two sizes and with two suction heads, the vacuum system includes a range of 90 to 170 litres and is used in the watch and jewellery industry. The Goldvac can pay for itself injust a few months and allows for the recovery of up to 3 kilograms of gold from an 800-litre bath of cutting oil for this metal. Rimann AG also offers to handle the separation of precious metal chips. In addition to chip processing solutions, Rimann has a basket manufacturing workshop to collect very small parts in the free-cutting sector, using very fine meshes to make custom collection baskets. https://www.rimann-ag.ch/fr/produits/metaux-precieux/aspirateur-a-liquides-et-copeaux-sofraper
Schaublin: S19-15V
The S19-15V transfer machine is designed for the production of timepiece parts with high productivity and greater flexibility.
The S19-15V has 15 3-axis workstations, 12 of which are protected in the machining area and 3 others deal with the loading, unloading and control of parts. The machine is equipped with a Fanuc 30iB control system, spindle and drive motors from the same supplier, and a direct-drive C-axis for diamond chamfering operations on watch components. The S19-15V also features intelligent AI functionality. Fanuc Contour Control and a variety of spindles to enhance torque or rotational speed. The indexing time of the rotary table is only 1.5 seconds, guaranteed by a Hirt toothing. The programming of the machining stations is completely independent from one unit to another, thus facilitating its use. The S19-15V offers the capability to machine both metallic and non-metallic materials, with or without coolant, and also features an internally developed robotic and palletized integration. The machine configurations are highlymodular and adaptable to the various needs of investors, and can also evolve over time. Schaublin Machines SA uses all the advantages of current technology to make the productivity of transfer machines more flexible.
https://public.smsa.cloud/ProsS19-15V.pdf
Silmach: PowerMEMS
Designed after more than 20 years of research, PowerMems micromotors offer innovative key points
These benefits stem from their compactness (twice as compact as the smallest Laver stepper motor), their SMT compatibility (allowing them to be soldered directlyonto the circuit board like any electronic component), and their unprecedented motor control capabilities intermsofspeed,acceleration,directionof rotation, and position accuracy. These characteristics could, in particular, be used inthemedicalfield,tominiaturizeimplants and thus contribute to the improvement of patients' living conditions, or even open up new therapeutic possibilities.
To celebrate this milestone, the company has developed a concept watch. "TheTimeChanger", the world's first watch powered by "Silicon Machinery" (micromotors).
https://www.silmach.com/powermems
Techniwatch: Comparator of luminescent materials
Uniqueonthewatchmakingmarket,this case can simultaneously control the luminescent materials of ten watch heads or 10 dials under UV and white light. It also has a touch screen with an intuitive menu.
https://www.techniwatch.ch/fran%C3%A7ais/nouveaut%C3%A9s-ephj-2024/d%C3%A9tecteur-depoussi%C3%A8re/
Techniwatch: Dust detector
This detection tool facilitates control and decreases eye strain. Using UV LEDs specially designed for this application, even the finest particles can be highlighted and easily removed. This helps to reduce the aesthetic and sealing problems associated with the presence of unwanted dust. In addition, our detector is equipped with an adjustable UV filter to protect the operator's eyes from possible optical reflections. All necessary security measures have been integrated during its design and development. Its compact and space-saving design allows easy installation on workstations, offering optimal ergonomics for watchmakers.
https://www.techniwatch.ch/fran%C3%A7ais/nouveaut%C3%A9s-ephj-2024/d%C3%A9tecteur-depoussi%C3%A8re/
Urma: Microone
Microone is a CNC machining centre for the high-precision machining of very small workpieces. The micro machining centre is developed and manufactured by ZORN in Germany and distributed exclusively by URMA in Switzerland.
This compact unit stands out for its spacesaving design, high manufacturing quality, and interchangeable modular construction, providing great flexibility for automation or customisation on a case-by-case basis. The microone is particularly suitable for the watchmaking and medical sectors, thanks to its exceptional rigidity and stability resulting from a granite block and tempered axes, allowing ultra-precise machining with lowenergy consumption.
https://www.urma.ch/fr/machines/CNCzorn-microone.php
Vulkam: VULKALLOY NI
The Vulkalloy-Ni is particularly suitable for micromechanical parts such as those found in watch movements.
The parts produced with this material are non-magnetic, 2x stronger than NiP and wear 5x slower than Durnico. This innovation consists of more accurate and reliable miniaturized components. It also ensures preserved functionality over time, allowing for a simplified and controlled production chain from pure metals to finished parts.
https://www.vulkam.com/vulkalloy-niun-alliage-innovant-horlogeriemecanism
Witschi Electronic AG: WAIO
A revolutionary solution for the control of mechanical and quartz watches, offering an improved customer experience in store and at repair centres.
WAIO offers fully automatic measurements, including leakage and precision testing, and allows sales staff to demagnetize watcheson-site. The device is easyto use thanks to its intuitive software and user-friendly interface. It is integrated with Witschi's database solution, allowing centralized access to complete parameters and measurement programs for movements and watches. The user-friendly search function allows for the required program to be loaded inamatterofseconds,andtheresultsarestoredinthe database and can be accessed globally. WAIO promotes sustainability by improving process efficiency, which saves time and manpower.
https://www.witschi.com/products/waio/
Zeiss: Metrotom 1
A compact and easy-to-use system to capture the data needed for your tasks.
The ZEISS METROTOM 1 is a compact and user-friendly system for capturing accurate 3D data. Thanks to computerassisted tomography, it allows for the non-destructive scanning and inspection of internal structures and hiddendefectsinparts.Combinedwith ZEISS INSPECT software, it simplifies quality control and offers the simultaneous measurement of multiple parts, thus saving time.
The METROTOM 1 is suitable for 3D scanning of small- and medium-sized components, accurate measurement, quality controland assurance, in-depth analysis of rejections and verification of components against their CAD. It provides automated determination of important metrics for CAT, reducing the complexity of configuring the scan.
Easy to use, the METROTOM 1 allows different users to start the measurement process and capture accurate data. Its compact dimensions integrate easily into the workspace and its closed X-ray tube limitsmaintenance. Start internal measurements and inspections at the pressof abutton. Inshort, the METROTOM 1 combines ease of use, quick acquisition and intuitive evaluation functionalities.
https://www.zeiss.fr/metrologie/produits/systemes/solutions-industrielles-de-tomographie-arayons-x/metrotom1.html
