IN-LAB TASK#3
from portfol
by Mariamkamel1
Two Level Guest Studio
Task Description: Creating a three dimensional model for a two stroy guest cottage on Revit
Advertisement
Goals Given: Enhancing skills learned in in lab task two and learning two new architecture components on Revit: stairs and slanted roof
Learned Skills: How to connect a multi story building, how to build stairs and how to draw a sloped roof or slanted roof, shaft, and railing
Commands: Grid, wall, columns, floor and roof by face, shaft, stairs, and railing
Challenges: This assignment was definitely not as easy as the previous one however i managed to start it early in order to bar any complications
How i overcame challenges: I Made sure to attend zoom meetings and finish my work early to have time to fix dimenions
Personal assignment feedback: i enjoy working on revit and i think i like this assignment alot
