Repairing & Rebuilding Christchurch | Trade Organisation Perspectives
Case Studies Re-roofing using Skellerup Hatteras asphalt shingles A Mellons Bay residence with an existing decramastic tile (metal tile with a mineral chip), roof had lost a considerable amount of its chips, leading to corrosion and popping nails. This resulted in an unsightly but worse still, leaking roof. The roof was skillion style with no insulation installed in its tiny roof cavity, resulting in insufficient ventilation of internal moisture. The home owners needed to reroof with a durable system that would also incorporate insulation and ventilation. It was also important to them that the very steep roof had a defining look as it was a major feature of their home. The BRANZ appraised Skellerup “Hatteras” tile (pictured right), was selected for its traditional slate-like
appearance which complemented the building’s architecture. Viking Roofspec recommended that its Approved Applicator install the plywood substrate onto the existing purlins to promote airflow throughout the roof; thus maximizing ventilation. The home owners were thrilled with the result; commenting that out of all the renovations they had completed on their home, the roof was the one that had provided the most aesthetic impact. With 40 years of warranted protection from a shingle installed only by an approved applicator and designed for maximum ventilation and extreme weather conditions, the owners now have a warm, dry home and peace of mind all year around.
Coverage
Skellerup Warm Roofs During the design stage of a large Tauranga Home the owner was focused on reducing the energy consumption within the home; future-proofing it to ensure ongoing energy savings and achieving a complete waterproofing solution. As a result, a ‘warm roof’ was specified. A warm roof takes the dew-point (condensation) to the outside of the building envelope by insulating a building from ‘the outside in’ using rigid insulation panels on top of the roof substrate. But the owner also wanted a waterproofing membrane that was high in solar reflectivity to add to the existing cooling properties of the insulation resulting in further energy savings. Skellerup’s Warm Roof solution was specified using Skellerup Enviroclad as the roofing membrane system. This combination of membrane and rigid insulation panels (called polyiso) met the solar reflectivity
and thermal efficiency needs of the owner. This warm roof system achieves higher R-values per inch than its competitors.
for all conditions
The Skellerup Warm Roof solution uses a polyurethane foam-based adhesive system called FAST Adhesive to adhere the insulation to the substrate which has wind uplift properties that rival mechanical fasteners, but negate the thermal bridging that can result from them. The Skellerup Warm Roof Solution with Skellerup Enviroclad membrane offered an effective solution in driving energy efficiency within the building while ensuring a watertight finish. (Since completing this project, the Skellerup Warm Roof has become BRANZ Appraised, No. 713).
Skellerup EcoStar Roof Tiles Wellington’s St Andrews Church underwent an extensive three phase upgrade. The first phase (completed in early 2009), involved renovating the external structure and roof. Due care and attention were the order of the day as the church dates to 1923, is a category one Historic Places Trust Building, the only English Baroque church in the country and a significant Wellington landmark. The roof needed to be replaced, the structure strengthened for earthquakes and concrete repair
and treatment undertaken. It was vital that the new roof was sympathetic to the building’s architectural era. With the green light from the Historic Places Trust, the Wellington City Council and architects, Skellerup EcoStar Majestic Slate roof tiles were selected. The tile provided a watertight solution on the new plywood substrate which braced the building. The finished look complemented the exterior of this outstanding and important piece of historical architecture.
48 | December 2011/January 2012 www.canterburytoday.co.nz
The importance of a good roof simply can’t be understated because it’s the most important part of a building’s structure.
system for the most demanding of new roof, deck, re-roof or overlay applications.
The Skellerup roofing range includes worldclass, single-ply and two layer membrane systems for low pitch areas, and premium pitched roofing systems. Being such a vital New Zealand homes, commercial and industrial properties are subjected to best and component to any building, quality assurance is key, so Viking’s most widely used products worst nature can throw at them. are ‘BRANZ Appraised’ to ensure they meet Unfortunately, Christchurch has involuntarily the demands of New Zealand’s uniquely unearthed additional requirements… the need varied weather conditions. for light-weight roofing and strong substrates There’s another important aspect designers that will brace the entire building — both factors maximising the longevity of a building and builders need to factor in — sustainability. Environmentally unfriendly doesn’t cut it any and more importantly, its inhabitants. more, so operating in a sustainable manner And nobody needs reminding about how is a key priority for Viking Roofspec. The damaging and costly the leaky homes debacle company is an active member of the NZ Green has been. Poor standards across all facets of Building Council and is committed to offering the construction sector have laid waste to environmentally-friendly, practical solutions. not only homes up and down the nation, but But a roofing system is only as effective as its to the dreams and financial security of their installation. Viking Roofspec’s stringent three owners as well. stage internal licensing programme ensures Your roof is something you cannot leave to Skellerup approved applicators will install your chance. You should seek the advice, help roof or deck to the highest standards from and systems endorsed by specialists like the waterproofing and aesthetic perspectives. people at Viking Roofspec. The company offers an exclusive This company specialises in the supply Viking Full System Warranty for specific and distributes a wide range of Skellerup projects where both the workmanship and roofing and waterproofing systems for both materials will be warranted under a single residential and commercial buildings. document for 20 years, no matter what may happen to the applicator in due course. The Skellerup is a name familiar to Kiwis and its buck stops with Viking Roofspec. roofing systems have been keeping New Zealanders dry for 42 years. Today, its diverse range of pitched and low-slope roofing solutions ensures there is an appropriate
T 0800 729 799 www.vikingroofspec.co.nz
