Annual Green Supplement
6
2015
Staples Uses Gensler’s WPI
The Green Trend of the Year
Framingham, MA – Aware of a shifting workforce demographic, in 2010 Staples charted a course towards a workplace of choice. The Framingham-based company partnered with Gensler, a global design firm grounded in the belief that great design optimizes business performance and human potential. Using Gensler’s proprietary Workplace Performance Index (WPI), which measures workplace effectiveness from the viewpoint of the employee, the team discovered a number of important issues. “Since our initial campus master plan strategy work, we have evolved our Framingham facility from a home office to a global headquarters campus,” notes John Lynch, Staples’ vice president of facilities, construction, and support services. With an existing parking shortage and plans to increase campus capacity, Staples needed a solution. The result? A four-level 950-car structure with electric vehicle charging stations that better uses the limited space that was previously occupied by a parking and drop-off area. A large PV array on the upper deck produces 10% of the entire campus’ annual energy needs, creating positive environmental and financial changes. This high-performing structure also
by Suzanne Robinson
The 950-car structure has electric vehicle charging stations.
creates a place for employees to gather. Staples associates use the adjacent patio and green space for socializing, dining, fitness activities, and more. “A best-in-class corporate campus helps attract, engage, and retain the best people and embodies your brand personality,” noted Arlyn Vogelmann, a principal in Gensler’s Boston office. “In the case of Staples, that brand includes a healthy and environmentally friendly work environment.” This garage is just one piece of a larger Staples strategy to minimize the company’s environmental impact through integrated sustainable technologies and a reduced structural footprint. In October 2014, the six-time Green Power Leadership Award winner announced that it was named to the Dow Jones Sustainability Index for the 11th consecutive year.
Independent ArchItecturAl hArdwAre SpecIfIcAtIonS
LEED Since 2003
BOSTON • SAN DIEGO • LOS ANGELES T: 781-899-8822
E: smessier@campbell-mccabe.com
www.campbell-mccabe.com
Independent Experts - Integrated Openings Consulting Specifications/Construction Documents
Total Openings • Architectural Door Hardware • Security Pre-schematic to Construction Administration
Serving World Class Architectural Teams Since 1866 Specifications • All Building Types • Code Compliance, Life Safety, ADA • Access Control Interface • Local, National, Global • Member: CSI, DHI, IBC, NFPA, SCUP • Certification Programs
111 Huntington Ave. in Boston
www.high-profile.com
I get asked all the time what’s the latest and greatest in the world of sustainability, especially with energy. The biggest trend of this year is total energy for the building, Suzanne Robinson specifically Zero Net Energy (ZNE), Energy Positive (E+), Passive House, and Zero Energy Buildings (ZEB). ZNE is not new. It has been around for years, but this last year, clients who wanted to showcase a sustainable building gravitated towards a ZNE project. ZNE is the new LEED. Design for ZNE has gone through an evolution these past few years. Personally, I loved the concept of ZNE buildings when I first came across the concept years ago: to produce the energy you consume on-site. I loved working on my first project that strived for ZNE with an owner who was up to exploring different concepts for occupying and operating the building, with an architect who fully embraced a design informed from energy decisions, and with a contractor who was involved during design. We had a truly integrated team. I didn’t realize I lucked out. For the next series of projects, too often they were interested in ZNE without a full understanding, education, and mindset shift for all parties involved. To get to ZNE you have to let go of some of the old habits, thinking, rules of thumb, and expectations. We would go through the exercise of finding the path to ZNE design and then see other project agendas dominate. I took away a personal mindset shift from the experience. The practice of designing to ZNE should be inherent on every project we work on, regardless of the energy targets. It provides the opportunity for true informed design decisions. Instead of tacking on extras from a baseline and building up your energy reduction number, start at ZNE. Even if the project does not end up being ZNE, you still will have a much better energy-performing building. All the projects that we were striving for ZNE are better for the process we went through even if they ultimately didn’t make it to ZNE. There are two drivers that are emerging in this new wave of ZNE. The first driver is operation. True sustainability is designing and constructing a building that can actually be operated during its lifetime as a sustainable building. As we push our designs to
be more high performance, we add layers of controls to only use energy when needed. A backlash has resulted because most high-performance buildings do not invest in high-performance operators. The more moving parts and complicated a system you have, the more risk you have for failure. The mantra Keep it Simple Stupid (KISS) is gaining ground. ZNE refocuses design back to reducing the loads. For example, right-sizing the envelope shell should mean it is near energy-neutral and allows for the HVAC system to focus on the cooling and heating loads related to ventilation and internal load needs and not have to make up for the heating losses through the envelope. This results in smaller HVAC systems with simpler controls, and proper operation is more likely achieved.
The biggest trend of this year is total energy for the building, specifically Zero Net Energy (ZNE), Energy Positive (E+), Passive House, and Zero Energy Buildings (ZEB).
The second driver is that ZNE is gaining legislative ground. There is a growing list of adoptions of ZNE requirements, from the European Union to California. In Massachusetts, the senate is reviewing Bill S.1587 that would establish ZNE building standards for new commercial buildings by 2030. There would be incremental increases of 30% better than the most recent international energy conservation code (IECC) to reach this 2030 requirement. ZNE is not a fad. Between owner and legislative demands, we are shifting our practices as an industry. There are certainly growing pains, but the growing awareness, education, and energy intuition to effectively design and construct ZNE buildings is gaining momentum. Suzanne Robinson, PE LEED AP, BD+C, is the director of sustainability at Vanderweil Engineers.
