S5731-S24N4X2Q-A (02354VBY) Datasheet deployment
● The USB port is damaged.
indicator
● The indicator is damaged. ● The USB flash drive does not have any configuration file and cannot be used for deployment. ● The switch has been upgraded using the USB flash drive and is restarting. Green
Steady on
A USB-based deployment has been completed.
Green
Blinking
The system is reading data from a USB flash drive. The switch has copied all the required files and
Yellow
Steady on
completed the file check. The USB flash drive can be removed from the switch. An error has occurred when the system is executing
Red
Blinking
the configuration file or reading data from the USB flash drive.
Get More Information
Do you have any question about the S5731-S24N4X2Q-A (02354VBY)? Contact us now via info@hi-network.com.
Specification
S5731-S24N4X2Q-A Specification Model
S5731-S24N4X2Q-A
Part Number
02354VBY S5731-S24N4X2Q-A (24*100M/1G/2.5G Ethernet ports, 4*10GE SFP+ ports, 2*40GE QSFP ports,
Description AC power, front access) Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in. Dimensions without packaging (H x W x D) [mm(in.)] Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 236.0 mm (1.72 in. x 17.4 in. x 9.29 in.) Dimensions with packaging (H x W x D) [mm(in.)]
90 mm x 547 mm x 357 mm (3.54 in. x 21.54 in. x 14.06 in.)
Chassis height [U]
1U
Weight without packaging [kg(lb)]
4.76 kg (10.49 lb)
Weight with packaging [kg(lb)]
5.4 kg(lb)
Typical power consumption [W]
106 W
Typical heat dissipation [BTU/hour]
361.69 BTU/hour
Maximum power consumption [W]
134 W
