S5731-S24N4X2Q-A (02354VBY)

Datasheet

deployment indicator

● The USB port is damaged.

● The indicator is damaged.

● The USB flash drive does not have any configuration file and cannot be used for deployment.

● The switch has been upgraded using the USB flash drive and is restarting.

Green Steady on A USB-based deployment has been completed.

Green Blinking The system is reading data from a USB flash drive.

Yellow Steady on

Get More Information

Red Blinking

Do you have any question about the S5731-S24N4X2Q-A (02354VBY)?

Contact us now via info@hi-network.com

Specification

S5731-S24N4X2Q-A Specification

Model S5731-S24N4X2Q-A

The switch has copied all the required files and completed the file check. The USB flash drive can be removed from the switch.

An error has occurred when the system is executing the configuration file or reading data from the USB flash drive.

Part Number 02354VBY Description S5731-S24N4X2Q-A (24*100M/1G/2.5G Ethernet ports, 4*10GE SFP+ ports, 2*40GE QSFP ports, AC power, front access) Dimensions mm x 547 mm x 357 mm (3.54 in. x 21.54 in. x 14.06 in.)

Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.

Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 236.0 mm (1.72 in. x 17.4 in. x 9.29 in.)
