QUY80B Operation Manual
Chapter Nine Transportation
Chapter nine
Transportation
When the work is finished and machine is to be transported to other site, disassemble the attachment, counterweight and both tracks for transport. 9.1 Disassembly of Crane There are two schemes of transport available. 9.1.1 Transport with crawlers on the machine 1. Place the machine on solid and level ground. Turn the boom in the lengthwise of the crawlers. 2. Lower the boom onto the ground.
Fig. 9-1 3. Remove all counterweights.
Fig. 9-2 4. Fully lower down the A-frame and keep the derricking pulley block on the A-Frame and then disconnect the pendants.
9-1 / 13
