TROUBLESHOOTING No.
Problem
Possible Cause
Action
1
Remote Control Operates Hard, Binds, Has Excessive Free Play or Makes Unusual Sounds
Insufficient lubrication on the shift and throttle (if applied) linkage fasteners.
Lubricate.
44
Obstruction in the shift or throttle (if applied) linkages.
Remove the obstruction.
44
Loose or missing shift and throttle linkages.
Check all throttle linkages. If any are loose or missing, see your authorized Yanmar Marine dealer or distributor immediately.
Shift or throttle (if equipped) cable is kinked.
Straighten the cable or have your authorized Yanmar Marine dealer or distributor replace the cable if damaged beyond repair.
44
Low power steering pump fluid level.
Check for leaks. Refill the system with fluid.
—
Stern-drive belt is loose or in poor condition.
Replace and / or adjust.
—
Insufficient lubrication on the steering components.
Lubricate.
Insufficient lubrication on the transom gimbal housing assembly and swivel shaft.
Lubricate.
42
Loose or missing steering fasteners or parts.
Check all parts and fasteners. If any are loose or missing, see your authorized Yanmar Marine dealer or distributor immediately.
42
Contaminated power steering fluid.
See your authorized Yanmar Marine dealer or distributor.
—
2
Steering Wheel Turns Hard or Jerky
ZT350 Operation Manual © 2008 Yanmar Marine International Downloaded from www.Manualslib.com manuals search engine
Reference Page
51
