PRODUCT OVERVIEW Electrical System
The power trim pump's electrical system is protected by either a 1A in-line fuse (Figure 11, (1)) or an auto-reset circuit breaker (Figure 11, (2)) located within the trim motor. In the event of an electrical overload, the fuse will blow out or the circuit breaker will shut off. Correct the cause of the electrical overload before operating the trim system. If the electrical overload problem still exists, contact your authorized Yanmar Marine dealer or distributor.
(2)
(1)
0006011
Figure 11 1 – 1A Fuse Holder 2 – Auto-Reset Circuit Breaker
