SPECIFICATIONS 4JH4AE Marine Gear or Sail Drive Specifications Model
KM35P
Type Reduction ratio (Forward / Reverse) Propeller speed (Forward / Reverse) *
ZF30M Mechanical cone clutch
2.36/3.16
2.61/3.16
1232/921rpm 1114/921 rpm
Lubrication system Lubricating oil capacity (Effective) Cooling system Weight
**
2.70/2.64
1353/1103 rpm
1078/1103 rpm
Splash
Lubricating oil capacity (Total)
*
2.15/2.64
0.5 L (0.5 qt)
1.1 L (1.2 qt)**
0.05 L (0.05 qt)
0.2 L (0.2 qt)
Air cooling by fan
Seawater cooling
12 kg (26 lb)
27.5 kg (61 lb)
At continuous power engine speed 2907 rpm ZF30M Lubricating oil: ATF
Model
KM35A2
Type
KM4A1
SD50 (coupled at boat builder)
Mechanical cone clutch
Reduction ratio (Forward / Reverse)
2.33/ 3.06
2.64/ 3.06
1.47/ 1.47
2.14/ 2.14
2.63/ 2.63
3.30/ 3.30
2.32
Propeller speed (Forward / Reverse) *
1246/ 955 rpm
1103/ 955 rpm
1983/ 1993 rpm
1360/ 1360 rpm
1106/ 1106 rpm
882/ 882 rpm
1253 rpm
Lubrication system
Splash
-
Oil bath
Lubricating oil capacity (Total)
0.65 L (0.69 qt)
2.3 L (2.4 qt)
SD50: 2.1 L (2.2 qt)
Lubricating oil capacity (Effective)
0.15 L (0.16 qt)
0.20 L (0.21 qt)
SD50: 0.5 L (0.6 qt)
Cooling system
Air cooling by fan
Seawater cooling
-
Weight
13 kg (28 lb)
29.0 kg (64 lb)
40 kg (88 lb)
*
94
At continuous power engine speed 2907 rpm
