7. WIRING DIAGRAMS 7. WIRING DIAGRAMS See Appendix B. at the back of this manual. Color coding
1
Starter switch
R
Red
2
Stop switch
B
Black
3
Tachometer hour meter
W
White
4
Buzzer
L
Blue
5
Lubricating oil low pressure alarm
RB
Red/Black
6
Coolant high temperature alarm
LB
Blue/Black
7
Water in sail drive seal alarm
YW
Yellow/White
8
Battery low charge alarm
YB
Yellow/Black
9
Relay (for 2 station: Option)
YG
Yellow/Green
10
Fuse (3A)
WL
White/Blue
21
Glow plug
WB
White/Black
22
Engine stop solenoid
WG
White/Green
23
Stop relay
GR
Green/Red
24
Starter relay
O
Orange
25
Starter
WBr
White/Brown
26
Coolant high temperature switch
27
Lubricating oil low pressure switch
29
Alternator
30
Water in sail drive seal sensor (on sail drive)
31
Water in sail drive seal sensor amplifier (Sail drive only)
33
Battery
34
Procured by customer
35
Battery switch
36
Earth bolt
37
Key switch
38
Only for sail drive
39
Wire harness. Option.
40
Instrument panel
41
Diodes
42
Alarm lamps
EN
53
