DECK WELDMENT REPLACEMENT PARTS ITEM NO.
PART NO.
DESCRIPTION
LOCATION
NO. REQ’D
NOTE: All parts listed in this section are for Weld-On Repair; Cutting, Grinding, and Welding are required to replace these parts. DSD52 & DSD62 Weldments 1 2 3 4 5 6 7
8733-3 8751-2 8760-2 8733-63 8751-3 8733-5 8751-4 8760-1 8733-61 8751-5 8733-10 8751-6
Rim Rod, RH Rear (20-3/4) Rim Rod, RH Rear (28-3/8) Rear Deck Pin (3/4 x 5-3/4) Rim Rod, LH Rear (28-3/4) Rim Rod, LH Rear (34-3/8) Rim Rod, LH Front (22-7/8) Rim Rod, LH Front (28-5/16) Front Deck Pin (3/4 x 7-5/8) Rim Rod, Front Center (26-5/8) Rim Rod, Front Center (29-1/4) Rim Rod, RH Front (16-1/4) Rim Rod, RH Front (19-1/4)
DSD52 DSD62 DSD52 and DSD62 DSD52 DSD62 DSD52 DSD62 DSD52 and DSD62 DSD52 DSD62 DSD52 DSD62
1 1 2 1 1 1 1 2 1 1 1 1
Deck Cap Strip, 54SD Rear (33-5/16)* Rear Deck Pin (5/8 x 5-3/8)** Deck Cap Strip, 54SD LH (39”)* Front Deck Pin (5/8 x 5-3/4)** Deck Cap Strip, 54SD Front (42")*
DSD54 All Decks Except DSD52 & DSD62 DSD54 All Decks Except DSD52 & DSD62 DSD54
1 2 1 2 2
Rear Deck Pin (5/8 x 5-3/8)** Front Deck Pin (5/8 x 5-3/4)** Deck Cap Strip, GHS LH (43-3/4) Deck Cap Strip, GHS LH (49-3/8) Edge Stiffener, Side (42-3/8)*** Edge Stiffener, Front (21-7/8)*** Deck Cap Strip, GHS RH (47-5/8) Deck Cap Strip, GHS RH (49-3/8)
All Decks Except DSD52 & DSD62 All Decks Except DSD52 & DSD62 DGHS36 DGHS42 DGHS48 DGHS48 DGHS36 DGHS42
2 2 1 1 2 1 1 1
All Decks Except DSD52 & DSD62 All Decks Except DSD52 & DSD62 DSD36 DSD42 DML42 DML42 DSD42
2 2 1 1 2 2 1
DSD54 Weldments 8 9 10 11 12
6752-1 5760-4 6752-3 5760-3 6752-2
DGHS Weldments 9 11 13
14 15
5760-4 5760-3 5751-3 5751-1 7701-10 7701-11 5751-4 5751-2
DSD & DML Weldments 9 11 16
17
5760-4 5760-3 5702-6 5751-5 5793-14 5793-15 5751-6
Rear Deck Pin (5/8 x 5-3/8)** Front Deck Pin (5/8 x 5-3/4)** Deck Cap Strip, (47") Deck Cap Strip, 42" SD LH (47") Rolled Edge, DML42 (37-3/8) Straight Edge, DML42 (18-9/16) Deck Cap Strip, 42" SD Front (3-9/16)
* Used only on models manufactured in 1992 and later. ** Used only on models manufactured in 1987 and later. *** Used only on models with Serial Number D7-26482 and later.
