Operation 1.4
Type labels and component numbers Serial number The serial number is stamped on the machine chassis. It is also located on the type label. The type label is located at the front left on the machine chassis, under the control stand.
Fig. 1:
Type label: location
HYDRAULIC EXCAVATOR
Fig. 2:
Type label
Type label information Field below Wacker Neuson logo:
HYDRAULIC EXCAVATOR
Fahrzeug Seriennummer/serial no./no. de série:
Serial number of machine
Fahrzeug Modell/model/modèle:
Machine designation
Leistung/performance:
Engine output
Typ/version:
Machine type
Betriebsgewicht/operating weight/poids en charge:
Operating weight
Transportgewicht/transport weight/poids en transport:
Transport weight
G. Gew./GWR/PTAC:
Gross weight rating (admissible)
Max. Nutzlast/max. payload/max. charge utile:
Maximum payload
Zul. Achslast vorne/front GAWR/PNBE AV:
Front gross axle weight rating
Zul. Achslast hinten/rear GAWR/PNBE AR:
Rear gross axle weight rating
Option EWG Nr./CEE no.:
EEC check number
Baujahr/model year/année fabr.:
Year of construction
Other information – see chapter 2 Specifications on page 2-2 Cab number The type label (arrow) is located on the chassis of the cab, at the upper left beside the door.
Fig. 3:
Cab type label
SHB 28Z3 EN – Edition 2.0 * 28z3s110.fm
1-5
