23-8 Control System, ECM, Data Sets
23-8 Control System, ECM, Data Sets Control Valve, Change 885510 Plugs Clean the control valve and fuel connections with cold degreaser and blow clean with compressed air. 1
Remove: - the cable from the control valves ”Mprop” (1) (cut the cable tie) - feed line (2) - the feed line from the fuel filter (3) - return line (4) - the control valve's two bolts
Remove the control valve 2
Check the control valve for damage. NOTICE! Plug all connections to exclude dirt (885 510).
7747622 05-2008
193
