22-0 Lubricating and Oil System, General
22-0 Lubricating and Oil System, General Engine Oil Pressure, Check 1678297 Spacer 9990124 Nipple 9996398 Manometer 9996666 Nipple 1
Measure the lubricating oil pressure on the engine's "fuel pump side" as illustrated, using a pressure gauge, nipple and spacer. Min. oil pressure in hot conditions and at idle: TAD734GE: 80 kPa (0.8 bar)
2
Check the oil pressure at engine oil operating temperature (120° C). At rated engine speed: Automatic stop, with pressure less than:
7747622 05-2008
420-450 kPa 100 kPa
155
