4.12
Cam angle sensor
Make sure that the ignition key is in the OFF position, then disconnect the battery terminal (-). Disconnect the electrical connection from the cam angle sensor. Undo the bolts (2 a) and remove the cam angle sensor (2b).
Position the cam angle sensor (1 a) in its housing and secure it tightening the bolt (1b) to the recommended torque. Cam angle sensor Bolt M6 (daNm)
0.8 ÷ 1.0 (cylinder head extension side)
Connect the electrical connection to the cam angle sensor. Connect the negative battery terminal (-).
Service manual VF4 VF5
Downloaded from www.Manualslib.com manuals search engine
402102.01 69
