6 Maintenance
Gearbox oil level check
Vetus engines are normally equipped with Technodrive or ZF-Hurth gearboxes. Consult the supplied Owners Manual for more details about care and maintenance. In case your engine is equipped with another brand of gearbox follow the instructions given in the supplied owners manual for changing oil and other care and maintenance.
54
17
VD01038
VD01032
Every 100 operating hours.
24 Oil level check (Technodrive)
25 Oil level check (ZF-Hurth)
• Take the dipstick out of the gearbox housing by pulling or unscrewing.
The oil level must between the two marks on the dipstick
• Check the oil level by lowering the dipstick (cleaned) into the hole.
• If necessary top up by pouring oil into the filler hole or the dipstick hole. For oil type and specification see page 108.
